DOUBLE OVEN DUAL FUEL RANGE
VCLFSGE 365 D..
Models:
INSTALLATION INSTRUCTIONS
IMPORTANT - PLEASE READ AND FOLLOW
• Before beginning, please read these instructions completely and carefully.
• Do not remove permanently affixed labels, warnings, or plates from the product. This may
void the warranty.
• Please observe all local and national codes and ordinances.
• Please ensure that this product is properly grounded.
The installer should leave these instructions with the consumer who should retain
•
for local inspector's use and for future reference.
Installation must conform with local codes or in the absence of codes, the National Fuel Gas
Code ANSI Z223.1/NFPA 54 - Iatest edition. Electrical installation must be in accordance
with the National Electrical Code, ANSI/NFPA70 - latest edition and/or local codes. IN
CANADA: Installation must be in accordance with the current CAN/CGA-B149.1 National
Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code and/or local codes.
Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical
Codes Part 1 and/or local codes.
INSTALLATION IN MANUFACTURED (MOBILE) HOME: The installation must conform with
the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 [formerly
the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD (Part 280)]
or, when such standard is not applicable, the Standard for Manufactured Home Installations,
ANSI/NCSBCS A225.1, or with local codes where applicable.
INSTALLATION IN RECREATIONAL PARK TRAILERS: The installation must conform with
state or other codes or, in the absence of such codes, with the Standard for Recreational
Park Trailers, ANSI A119.5.
Installation of any gas-fired equipment should be made by a Iicensed plumber. A manual
shut-off valve must be installed in an accessible location in the gas line external to the
appliance for the purpose of turning on or shutting off gas to the appliance (In Massachusetts
such shutoff devices should be approved by the Board of State Examiners of Plumbers &
Gas Fitters).
If an external electrical source is utilized, the appliance, when installed, must be electrically
grounded in accordance with local codes or, in the absence of local codes, with the national
Electrical Code, ANSI/NFPA 70.
Some models are supplied with a protective film on steel and aluminium
parts. This film must be removed before installing/using the appliance.
THIS RANGE IS FOR RESIDENTIAL USE ONLY
FOR INSTALLER ONLY
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCLFSGE 365 D and is the answer not in the manual?

Questions and answers

Related Manuals for Verona VCLFSGE 365 D

Summary of Contents for Verona VCLFSGE 365 D

  • Page 1 DOUBLE OVEN DUAL FUEL RANGE VCLFSGE 365 D.. Models: INSTALLATION INSTRUCTIONS IMPORTANT - PLEASE READ AND FOLLOW • Before beginning, please read these instructions completely and carefully. • Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty. • Please observe all local and national codes and ordinances. • Please ensure that this product is properly grounded. The installer should leave these instructions with the consumer who should retain • for local inspector’s use and for future reference.

  • Page 2: What To Do If You Smell Gas

    WARNING ! To reduce the risk of tipping the appliance, the appliance must be secured by properly installed anti-tip device packed with the appliance. • ALL RANGES CAN TIP • INJURY TO PERSONS COULD RESULT • INSTALL ANTI-TIP DEVICE PACKED WITH RANGE •...
  • Page 3 DATA PLATE CONVERSION LABEL The Governor of California is required to publish a list of substances known to the state of California to cause cancer or reproductive harm and requires businesses to warn customers of potential exposures to such substances. WARNING!: Gas appliances contain or produce substances which can cause death or serious illness and which are known to the State of California to cause cancer, birth defects or other reproductive harm. To reduce the risk from substances in fuel or from fuel combustion, make sure this appliance is installed, operated, and maintained according to the manufacturer’s instructions. This appliance is designed and manufactured solely for the cooking of domestic (household) food and in not suitable for any none domestic application and therefore should not be used in a commercial environmement. The appliance warranty will be void if the appliance is used within a none domestic environmement i.e. a semi commercial, commercial or communal environment.

  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS WARNING! THIS APPLIANCE MUST BE INSTALLED BY A QUALIFIED INSTALLER. Installation must conform with local codes. Improper installation, adjustment, alteration, services, or maintenance can cause injury or property damage. Consult a qualified installer, service agente or the gas supplier. IMPORTANT: The use of suitable protective clothing/gloves is recommended when handling, installing of this appliance.

  • Page 5: General Information

    GENERAL INFORMATION 16. When installing or removing the range for service, a rolling lift jack should be used. Do not push against any of the edges of 1. Installation must conform with local codes or, in the absence the range in an attempt to slide it into or out of the installation. of local codes, with the National Fuel Gas Code, ANSI Pushing or pulling a range (rather than using a lift jack) also increases the possibility of bending the leg spindles or the Z223.1/NFPA 54 - Latest Edition, CAN/CGA-B149.1 or CAN/ internal coupling connectors. CGA-B149.2. 2. Installation in manufactured (mobile) home: installation must conform with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 [formerly the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD (Part 280)] or, when such standard...

  • Page 6: Installation

    installation PROXIMITY TO SIDE CABINETS 2. The range CANNOT be installed directly adjacent to sidewalls, 1. This range may be installed directly adjacent to existing 36" tall cabinets, tall appliances, or other side vertical surfaces (914 mm) high base cabinets. above 36” (914 mm) high. Range dimensions: There must be a minimum of 11” 13/16 (300 mm) side • width: 35” 7/8 (911 mm) clearance from the range to such combustible surfaces TO • depth: 23” 31/32 (609 mm)
  • Page 7 GAS AND ELECTRIC CONNECTION Rif. inch 5” 1/8 ÷ 5” 5/16 (*) 130 ÷ 135 (*) 23” 5/8 5” 1/8 ÷ 5” 5/16 (*) 130 ÷ 135 (*) 12” 1/4 * : Depending on feet regulation Dotted line showing the position of the range when installed Area for GAS connection Area for ELECTRICAL connection Fig. 1.2...
  • Page 8 ( 3 3 0 m m ) PROXIMITY TO SIDE CABINETS 1 3 " m a x . RANGE WITH BACKGUARD Fig. 1.3a 1 3 " m a x . ( 3 3 0 m m ) Fig. 1.3b...
  • Page 9 1 3 " m a x . ( 3 3 0 m m ) PROXIMITY TO SIDE CABINETS RANGE WITH ISLAND TRIM Fig. 1.3c ( 3 3 0 m m ) 1 3 " m a x . Fig. 1.3d...

  • Page 10: Fitting The Adjustable Feet

    Fig. 1.4 Fig. 1.5 FITTING THE ADJUSTABLE FEET The adjustable feet must be fitted to the base of the cooker before use. Rest the rear of the cooker on a piece of the polystyrene packaging exposing the base for the fitting of the feet. ATTENTION: Most important! Pay special attention not to damage the range during this operation. Fit the 4 legs by screwing them tight into the support base as shown in picture 1.5. LEVELLING THE COOKER The cooker may be levelled by screwing the lower ends of the feet IN or OUT (fig. 1.6). It is important to observe the directions of figure 1.6. Fig. 1.6 MOVING THE COOKER WARNING When raising cooker to upright position always ensure two people carry out this manoeuvre to prevent damage to the adjustable feet (fig.

  • Page 11: Assembling The Backguard

    ASSEMBLING THE BACKGUARD IMPORTANT: THE BACKGUARD OR ISLAND TRIM IS NOT PACKAGED OR THE ISLAND TRIM WITH THE APPLIANCE BUT IT IS SUPPLIED SEPARATELY BY THE DISTRIBUTOR. It is mandatory to install the backguard or the WITH RESPECT TO THE FIGURES BELOW, ONE ADDITIONAL BACKGUARD island trim (HEIGHT = 4”) OR ISLAND TRIM (HEIGHT = 2”) IS ALSO AVAILABLE FOR •...
  • Page 12 ANTI-TIP STABILITY DEVICE INSTALLATION INSTRUCTIONS YOU MUST USE STABILITY ANTI TIP BRACKET TO 1. The anti-tip bracket has to be attached as shown on figure below, it has to be fixed on the rear wall by no. 2 (two) suitable screws (supplied with the anti-tip kit). PREVENT UNIT FROM TIPPING. 2. After fixing the anti-tip bracket, slide range into place. Be sure the anti-tip bracket is fully inserted in the slot of the range back. Dotted line showing the position of the range when installed ANTI-TIP STABILITY DEVICE FIXING Anti-tip stability device Slot for inserting the anti-tip bracket Fig. 1.10...

  • Page 13: Gas Connection

    gas connection All gas connections must be made according to national and local codes. This gas supply (service) line must be the same size or greater than the inlet line of the appliance. Sealant on all pipe joints must be resistant to te action of LP/Propane gas. The range is equipped for the use with NATURAL gas. It is design-certified by CSA International for NATURAL and L.P. gases with appropriate conversion.
  • Page 14 PRESSURE REGULATOR INSTALLATION STEP 1 Mount the 1/2” NPT (conical) male connector to the pressure regulator and tighten by using a wrench. Do not over tighten the connector. Over tightening may crack regulator. LOCK Arrow Fig. 2.2a STEP 2 Assemble the “A” bracket to the extension pipe. Fig. 2.2b...
  • Page 15 STEP 3 Assemble the 1/2” NPT connector + pressure regulator group to the extension pipe interposing the gasket supplied. The regulator cover must be ordiented toward the front side of the range. IMPORTANT: use two spanners to tighten the connection. Regulator cover Fig. 2.2c STEP 4 Insert the extension pipe + pressure regulator group in the “B” bracket. Fig. 2.2d...
  • Page 16 STEP 5 Assemble the extension pipe + pressure regulator group to the range manifold interposing the gasket supplied. The regulator cover must be ordiented toward the front side of the range. IMPORTANT: use two spanners to tighten the connection. Fig. 2.2e STEP 6 Fix the “C” bracket on the back of the range by the 2 (two) screws supplied with the kit for gas connection.
  • Page 17 PRESSURE REGULATOR INSTALLATION To range Range manifold Manifold male pipe fitting 1/2” G cylindrical (ISO 228-1) male Gasket 1/2” G cylindrical (ISO 228-1) female Extension Extension pipe female pipe female pipe fitting pipe fitting To mains connection Extension pipe Pressure Extension Gasket regulator...

  • Page 18: Flexible Connections

    c) Any conversion required must be performed by your dealer or a qualified licensed plumber or gas service company. Please provide the service person with this manual before work is started on the range. (Gas conversions are the responsibility TEST POINT ADAPTER of the dealer or end user.) The Test Point adapter is available from d) This range can be used with NATURAL or LP/PROPANE gas. It is shipped from the After-Sales Service.

  • Page 19: Setting The Pressure Regulator

    CONVERSION TO LP/PROPANE GAS (OR CONVERSION BACK TO THE ORIGINAL GAS - NATURAL GAS) Every range is provided with a set of injectors for the various types of gas. Select the injectors to be replaced according to the “INJECTORS TABLE”. The nozzle diameters, expressed in hundredths of a millimetre, are marked on the body of each injector.

  • Page 20: Injectors Table

    INJECTORS TABLE LP/PROPANE NATURAL GAS 11” W.C.P. 4” W.C.P. NOMINAL POWER REDUCED POWER BURNERS BTU/hr BTU/hr Ø injector Ø injector [1/100 mm] [1/100 mm] Semi-rapid (R) 6000 1500 Triple ring (TC) 12000 5000 2800 for NATURAL GAS (*) Inner crown 1000 (*) 3500 for LP/PROPANE GAS (*) (no. 1 central) (no. 1 central) Dual (D) 16000 for NATURAL GAS (#) 6500 for NATURAL GAS (#) Outer crowns...
  • Page 21 SETTING THE BURNER MINIMUM When switching from one type of gas to another, the minimum flow rate must also be correct: the flame should not go out even when passing suddenly from maximum to minimum flame. To regulate the flame follow the instructions below: Semirapid and triple ring burners regulation – Light the burner screw – Set the gas valve to position – Remove the knob – With a thin screwdriver turn the screw "F" until adjustment is correct (fig. 2.7). Fig. 2.7 Inside crown of DUAL burner – Light the DUAL burner – Set the gas valve to position...

  • Page 22: Electrical Connection

    electrical connection ELECTRICAL REQUIREMENTS • This appliance must be properly installed and grounded by a qualified technician in WARNING accordance with the National Electrical Code ANSI/NFPA No.70 (latest edition) and local electrical code requirements. IN CANADA: Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical Codes Part1 and/or local TO AVOID ELECTRICAL SHOCK codes. HAZARD, BEFORE INSTALLING • This appliance may be connected by means of permanent “Hard Wiring” or “Power THE APPLIANCE, SWITCH POWER Supply Cord Kit”. Power supply cord is not supplied, but it is available through your OFF AT THE SERVICE PANEL AND local electric supply house.
  • Page 23 3-Wire Power Cord Installation Fig. 3.1 (See figures 3.1, 3.2 and 3.3) 1. Remove the Terminal Block Access Plate on the back of the range by unscrewing the 6 fixing Screws (fig. 3.1). 2. Insert the Power Cord through the hole in the Power Cord Bracket; then tighten the Power Cord by using a suitable Strain Relief. Allow enough slack to easily attach the cord terminals to the Terminal Block.
  • Page 24 3-Wire Conduit Installation Fig. 3.5 (See figures 3.1, 3.5 and 3.6) 1. Remove the Terminal Block Access Plate on the back of the range by unscrewing the 6 fixing Screws (fig. 3.1). 2. Feed 1/2” (1.3 cm) trade size Conduit through the hole in the Conduit Bracket and secure to the Conduit Bracket with a Conduit Clamp. 3. Remove the 3 wire terminal nuts and washers from the Terminal Block. Counduit Bracket 4. Plug the terminal holes of conductors. The Neutral or Ground Wire of the Power Cord must be connected to the neutral Hole D 7/8"...

  • Page 25: Wiring Diagram

    WIRING DIAGRAM P-E61(1) P-E61(2) P-PR ST-CF P8(2) P8(1) P-PR E61(1) E61(2) EARTH L1 - L2 = 240V L1 - N = 120V L2 - N = 120V P-E61(1) P-E61(2) Cod.0422408 ELECTRIC DIAGRAM KEY Electronic programmer E61(1) Left oven relay E61(2) Right oven ralay P-E61(1) Left oven relay contact P-E61(2) Right oven relay contact...
  • Page 28 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances. Cod. 1104909 - ß1...
