DOUBLE OVEN DUAL FUEL RANGE
VPFSGE365D ..
Models:
INSTALLATION INSTRUCTIONS
IMPORTANT - PLEASE READ AND FOLLOW
•
Before beginning, please read these instructions completely and carefully.
•
Do not remove permanently affixed labels, warnings, or plates from the product. This may
void the warranty.
•
Please observe all local and national codes and ordinances.
•
Please ensure that this product is properly grounded.
The installer should leave these instructions with the consumer who should retain
•
for local inspector's use and for future reference.
Installation must conform with local codes or in the absence of codes, the National Fuel Gas
Code ANSI Z223.1/NFPA 54 - Iatest edition. Electrical installation must be in accordance
with the National Electrical Code, ANSI/NFPA70 - latest edition and/or local codes. IN
CANADA: Installation must be in accordance with the current CAN/CGA-B149.1 National
Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code and/or local codes.
Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical
Codes Part 1 and/or local codes.
INSTALLATION IN MANUFACTURED (MOBILE) HOME: The installation must conform with
the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 [formerly
the Federal Standard for Mobile Home Construction and Safety, Title 24, HUD (Part 280)]
or, when such standard is not applicable, the Standard for Manufactured Home Installations,
ANSI/NCSBCS A225.1, or with local codes where applicable.
INSTALLATION IN RECREATIONAL PARK TRAILERS: The installation must conform with
state or other codes or, in the absence of such codes, with the Standard for Recreational
Park Trailers, ANSI A119.5.
Installation of any gas-fired equipment should be made by a Iicensed plumber. A manual
shut-off valve must be installed in an accessible location in the gas line external to the
appliance for the purpose of turning on or shutting off gas to the appliance (In Massachusetts
such shutoff devices should be approved by the Board of State Examiners of Plumbers &
Gas Fitters).
If an external electrical source is utilized, the appliance, when installed, must be electrically
grounded in accordance with local codes or, in the absence of local codes, with the national
Electrical Code, ANSI/NFPA 70.
Some models are supplied with a protective film on steel and aluminium
parts. This film must be removed before installing/using the appliance.
THIS RANGE IS FOR RESIDENTIAL USE ONLY
FOR INSTALLER ONLY
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPFSGE365D Series and is the answer not in the manual?

Questions and answers

Related Manuals for Verona VPFSGE365D Series

Summary of Contents for Verona VPFSGE365D Series

  • Page 1 DOUBLE OVEN DUAL FUEL RANGE VPFSGE365D .. Models: INSTALLATION INSTRUCTIONS IMPORTANT - PLEASE READ AND FOLLOW • Before beginning, please read these instructions completely and carefully. • Do not remove permanently affixed labels, warnings, or plates from the product. This may void the warranty.

  • Page 2: What To Do If You Smell Gas

    WARNING Tip-Over Hazard A child or adult can tip the range and be killed. Install anti-tip device to range and/or structure per installation instructions. Engage the range to the anti-tip device Installed to the structure. Re-engage anti-tip device if range is moved. Failure to follow these instructions can result in death or serious burns to children and adults.
  • Page 3 DATA PLATE CONVERSION LABEL WARNING: This product can expose you to chemicals including formaldehyde, which is known to the State of California to cause cancer, and lead, which is known to the State of California to cause birth defects or other reproductive harm.

  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS WARNING! THIS APPLIANCE MUST BE INSTALLED BY A QUALIFIED INSTALLER. Installation must conform with local codes. Improper installation, adjustment, alteration, services, or maintenance can cause injury or property damage. Consult a qualified installer, service agente or the gas supplier. IMPORTANT: The use of suitable protective clothing/gloves is recommended when handling, installing of this appliance.

  • Page 5: General Information

    GENERAL INFORMATION 16. When installing or removing the range for service, a rolling lift jack should be used. Do not push against any of the edges of Installation must conform with local codes or, in the absence the range in an attempt to slide it into or out of the installation. of local codes, with the National Fuel Gas Code, ANSI Pushing or pulling a range (rather than using a lift jack) also increases the possibility of bending the leg spindles or the...

  • Page 6: Installation

    installation PROXIMITY TO SIDE CABINETS Gas line opening: From 5” 1/8 (130 mm) to 7” 3/32 (180 mm) [depending on feet 1. This range may be installed directly adjacent to existing 36" regulation] from the floor; 12” 1/4 (311 mm) from the left side (914 mm) high base cabinets.
  • Page 7 GAS AND ELECTRIC CONNECTION Rif. inch 5” 7” 130 ÷ 180 1/8 ÷ 3/32 23” 5” 7” 130 ÷ 180 1/8 ÷ 3/32 12” * : Depending on feet regulation Dotted line showing the position of the range when installed Area for GAS connection Area for ELECTRICAL connection...
  • Page 8 ( 3 3 0 m m ) 1 3 " m a x . PROXIMITY TO SIDE CABINETS RANGE WITH 8" BACKGUARD Fig. 1.3a 1 3 " m a x . ( 3 3 0 m m ) Fig. 1.3b...
  • Page 9 1 3 " m a x . ( 3 3 0 m m ) PROXIMITY TO SIDE CABINETS RANGE WITH 2" or 3" BACKGUARD Fig. 1.3c ( 3 3 0 m m ) 1 3 " m a x . Fig.

  • Page 10: Fitting The Adjustable Feet

    Fig. 1.5 Fig. 1.4 FITTING THE ADJUSTABLE FEET The adjustable feet must be fitted to the base of the cooker before use. Rest the rear of the cooker on a piece of the polystyrene packaging exposing the base for the fitting of the feet. ATTENTION: Most important! Pay special attention not to damage the range during this operation.

  • Page 11: Assembling The Backguard

    ASSEMBLING THE BACKGUARD 8" BACKGUARD It is mandatory to install the backguard • Assemble the backguard as shown in figure 1.8a, 1.8b or 1.8c and fix it by screwing the 5 screws “A” (which are already fixed on the back of the cooktop). •...

  • Page 12: Installing The Anti-Tip Bracket

    INSTALLING THE ANTI-TIP BRACKET The anti-tip bracket has two components: • the adjustable bracket • the stability bracket IMPORTANT! You must install both parts of the anti-tip bracket and ensure they are properly fitted together to prevent the range from tipping. To fit the anti-tip bracket Fig.
  • Page 13 Fix the stability bracket in place. It can be WARNING fixed as follows: Tip-Over Hazard • To the floor OR on the rear wall by #4 screws (supplied). A child or adult can tip the range and be killed. • To the floor AND on the rear wall by #8 Install anti-tip device to range and/or structure per installation screws (supplied).
  • Page 14 INSTALLING THE COOKTOP FRONT GUARD (Only for the models without hob rail) To increase the clearance between the front edge of the cooktop and the burners it is possible to install the cooktop front guard supplied with the appliance. IMPORTANT: To install/remove the guard it is necessary to remove the cooktop. Attempting to install/remove the guard without disassembling the cooktop will result in permanent damage to the appliance.

  • Page 15: Gas Connection

    gas connection All gas connections must be made according to national and local codes. This gas supply (service) line must be the same size or greater than the inlet line of the appliance. Sealant on all pipe joints must be resistant to te action of LP/Propane gas. The range is equipped for the use with NATURAL gas.
  • Page 16 PRESSURE REGULATOR INSTALLATION STEP 1 Mount the 1/2” NPT (conical) male connector to the pressure regulator and tighten by using a wrench. Do not over tighten the connector. Over tightening may crack regulator. LOCK Arrow Fig. 2.2a STEP 2 Assemble the “A” bracket to the extension pipe. Fig.
  • Page 17 STEP 3 Assemble the 1/2” NPT connector + pressure regulator group to the extension pipe interposing the gasket supplied. The regulator cover must be ordiented toward the front side of the range. IMPORTANT: use two spanners to tighten the connection. Regulator cover Gasket...
  • Page 18 STEP 5 Assemble the extension pipe + pressure regulator group to the range manifold interposing the gasket supplied. The regulator cover must be ordiented toward the front side of the range. IMPORTANT: use two spanners to tighten the connection. Gasket Fig.
  • Page 19 PRESSURE REGULATOR INSTALLATION To range Range manifold Manifold male pipe fitting 1/2” G cylindrical (ISO 228-1) male Gasket 1/2” G cylindrical (ISO 228-1) female Extension Extension pipe female pipe female pipe fitting pipe fitting To mains connection Extension pipe Pressure Extension Gasket regulator...

  • Page 20: Flexible Connections

    c) Any conversion required must be performed by your dealer or a qualified licensed plumber or gas service company. Please provide the service person with this manual before work is started on the range. (Gas conversions are the responsibility TEST POINT ADAPTER of the dealer or end user.) The Test Point adapter is available from d) This range can be used with NATURAL or LP/PROPANE gas.

  • Page 21: Setting The Pressure Regulator

    CONVERSION TO LP/PROPANE GAS (OR CONVERSION BACK TO THE ORIGINAL GAS - NATURAL GAS) Every range is provided with a set of injectors for the various types of gas. Select the injectors to be replaced according to the “INJECTORS TABLE”. The nozzle diameters, expressed in hundredths of a millimetre, are marked on the body of each injector.

  • Page 22: Injectors Table

    INJECTORS TABLE LP/PROPANE NATURAL GAS 11" W.C.P. 4" W.C.P. NOMINAL POWER REDUCED POWER BURNERS BTU/hr BTU/hr Ø injector Ø injector [1/100 mm] [1/100 mm] Semi-rapid (SR) 8000 1500 Triple ring (TR) 12000 5000 2800 ( 1 ) 1100 ( 1 ) Inner crown (no.
  • Page 23 SETTING THE BURNER MINIMUM When switching from one type of gas to another, the minimum flow rate must also be correct: the flame should not go out even when passing suddenly from maximum to minimum flame. To regulate the flame (fig. 2.7) follow the instructions below: Triple-ring and semirapid burner •...

  • Page 24: Electrical Connection

    electrical connection ELECTRICAL REQUIREMENTS • This appliance must be properly installed and grounded by a qualified technician in WARNING accordance with the National Electrical Code ANSI/NFPA No.70 (latest edition) and local electrical code requirements. IN CANADA: Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical Codes Part1 and/or local TO AVOID ELECTRICAL SHOCK codes.
  • Page 25 3-Wire Power Cord Installation Fig. 3.1 (See figures 3.1, 3.2 and 3.3) 1. Remove the Terminal Block Access Plate on the back of the range by unscrewing the 6 fixing Screws (fig. 3.1). 2. Insert the Power Cord through the hole in the Power Cord Bracket;...
  • Page 26 3-Wire Conduit Installation Fig. 3.5 (See figures 3.1, 3.5 and 3.6) 1. Remove the Terminal Block Access Plate on the back of the range by unscrewing the 6 fixing Screws (fig. 3.1). 2. Feed 1/2” (1.3 cm) trade size Conduit through the hole in the Conduit Bracket and secure to the Conduit Bracket with a Conduit Clamp.

  • Page 27: Wiring Diagram

    WIRING DIAGRAM P-E61(1) P-E61(2) P-PR ST-CF P8(2) P8(1) P-PR E61(1) E61(2) EARTH L1 - L2 = 240V L1 - N = 120V L2 - N = 120V P-E61(1) P-E61(2) Cod.0422408 ELECTRIC DIAGRAM KEY Electronic programmer E61(1) Left oven relay E61(2) Right oven ralay P-E61(1) Left oven relay contact P-E61(2) Right oven relay contact...
  • Page 28 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances.
