Design and function
TIG welding
As an example the process is shown with HF ignition. Arc ignition with lift arc is also possible, however-
See 5.11.8 Arc ignition chapter.
Sequence:
•
Press and hold torch trigger 1.
•
The gas pre-flow time elapses.
•
HF ignition pulses jump from the electrode to the workpiece, the arc ignites.
•
The welding current flows and immediately assumes the value set for the ignition current I
•
HF is switched off.
•
The welding current increases in the adjusted up-slope time to the main current AMP.
The process ends when the set spotArc time elapses or if the torch trigger is released
prematurely.
spotArc/pulse variants table:
Process
TIG DC
68
Pulse variants
(lights up in green)
(lights up in red)
No pulses
Figure 5-32
Automated pulses (factory setting)
Pulses (thermal pulses)
kHz pulse (metallurgic pulses)
.
start
