INSTALLATION AND OPERATION MANUAL
EPA Certified
Wood-Burning
Fireplace Inserts
Retain These Instructions
For Future Reference
P/N 775,212M, Rev. A, 04/2007
A French manual is available upon request. Order P/N 775,212CF.
•
•
Ce manuel d'installation est disponible en francais, simplement en faire la demande. Numéro de la
pièce 775,212CF.
These appliances must be properly installed and operated in order to prevent the
possibility of a house fire. Please read this entire installation and operation
manual before installing and using your wood stove. Failure to follow
these instructions could result in property damage, bodily injury or
Hot! Do not touch! The glass and surfaces of this appliance will
be hot during operation and will retain heat for a while after
shutting off the appliance. Severe burns may result.
Carefully supervise children in the same room as appliance.
Wood Fireplace Inserts
Performer™ Models C/A210
even death. Contact your local building or fire officials to obtain
a permit and information on any installation requirements
and inspection requirements in your area.
WARNINGS
Performer™ C210
Performer™ CA210
