MANUAL
PIN CODE KEYPAD 3068
Attention: It is not possible to enter programming mode when there is a battery warn-
ing. This means that it is not possible to change or delete PINs when there is a weak
battery. Programming mode will only be available again after you have successfully
changed the battery (see the section "Battery Replacement).
5.2

Procedure

Input "1"
(for PIN 1)
6.0

Programming the Transponder Data Records with the

Simons Voss Software
6.1

Assignment of PINs and Transponders

• PIN1 ⇒ Transponder 1
• PIN2 ⇒ Transponder 2
• PIN3 ⇒ Transponder 3
Each integrated transponder has its own transponder ID (TID); the TIDs are saved in
the SimonsVoss lockings when there is an access if the lockings have the time con-
trol function (i.e., access control). In this way, you can tell precisely which PIN was
granted access and when.
Input "0"
Input "master PIN"
Input "2"
(for PIN 2)
Input PIN length "0"
Input "3"
(for PIN 3)
10
