MANUAL
PIN CODE KEYPAD 3068
6.2
Description
To program the various transponders with the SimonsVoss software, please follow
the procedure described in the following (also see the SimonsVoss "Software Man-
ual"):
1.
Press the "0" button twice in order to enter the transponder programming
mode.
2.
Enter the "master PIN ".
3.
Start the Transponder programming function in the SV software
4.
For the particular transponder:
•
Transponder 1 = press the "1" button
•
Transponder 2 = press the "2" button
•
Transponder 3 = press the "3" button
5.
Please check in the user interface to see that the programming was success-
ful (yellow programmer flash must have been removed in the locking plan).
In order to be able to carry out the programming without problems, please first start
the programming command in the SV software and only then select the required
transponder using the PinCode Keypad. Otherwise it is not possible to guarantee
successful programming.
The PinCode Keypad's three integrated transponders must be located in the same
locking plan as the locking that you wish to address.
Attention: It is not possible to enter programming mode when there is a battery warn-
ing. This means that it is not possible to change or delete transponders when there is
a weak battery. Programming mode will only be available again after you have suc-
cessfully changed the battery (see the section "Battery Replacement).
11
