Page 2
Quick Guide MMI communications cable Cable holder Floating cable Floating cable handle Power supply Impeller cover Caddy MMI communications cable Wave power supply Floating cable connected to Wave power supply Fuse Main power supply Cable First Pool Cleaning Sessions This section explains how to proceed to the default setting for a cleaning session. The robot is preset in the factory with certain configurations that enable you to commence pool cleaning immediately.
Page 3
4. Position the Caddy with robot about 0.5–1.0m (1.5-3ft) from the pool's edge with its sloping edge facing the swimming pool ensuring that the floating cable is facing the direction of the Dolphin Wave power supply unit. 5. According to the pool's size, release the appropriate length of cable.
Page 4
Everyday operation After you have set up the Dolphin Wave and configured it for the first time, the device is set for everyday operation. When performing your next cleaning session, proceed as follows: 1. Position the Caddy with robot about 0.5–1.0m (1.5-3ft) from the pool's edge with its sloping edge facing the swimming pool ensuring that the floating cable is facing the direction of the Dolphin Wave power supply unit.
Page 5
Useful Operation Tips Avoid changing the Wave's setting and parameters unless necessary. After each cycle: Roll the floating cable on the floor, in large circles; place the rolled cable on the Caddy. Clean with water the inner side of top cover, around the lock mechanism. Clean inner body of the Wave if necessary.
