Kobalt SGY-AIR141 Manual

3/8 in. air impact wrench
Hide thumbs
Table of Contents

Advertisement

Quick Links

®
KOBALT and the K & Design are registered
trademarks of LF, LLC. All rights reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-888-3KOBALT, 8 a.m. - 8 p.m., EST
Monday - Friday.
®
IMPACT WRENCH
Purchase Date
1
ITEM #0402536
3/8 IN. AIR
MODEL #SGY-AIR141
Français p. 15
Español p. 30
,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGY-AIR141 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kobalt SGY-AIR141

Summary of Contents for Kobalt SGY-AIR141

  • Page 1 ITEM #0402536 3/8 IN. AIR IMPACT WRENCH ® ® KOBALT and the K & Design are registered trademarks of LF, LLC. All rights reserved. MODEL #SGY-AIR141 Français p. 15 Español p. 30 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT, 8 a.m.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Product Specifications ..................3 Safety Information ....................3 Package Contents ....................8 Preparation ......................9 Assembly Instructions ..................9 Operating Instructions ..................11 Care and Maintenance ..................12 Troubleshooting ....................13 Warranty ......................13 Replacement Parts List ..................14 Tool Requirements Exigences relatives aux outils Requisitos de herramientas...

  • Page 3: Product Specifications

    PRODUCT SPECIFICATIONS COMPONENT SPECIFICATIONS SQUARE DRIVE 3/8 IN. FREE SPEED 10,000 RPM MAXIMUM TORQUE 200 FT.-LBS. AVERAGE AIR CONSUMPTION 5.8 CFM AIR INLET 1/4 IN. NPT AIR HOSE 3/8 IN. WORKING PRESSURE 90 PSI SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product.
  • Page 4 SAFETY INFORMATION WA R N I N G RISK OF EYE OR HEAD INJURY WHAT COULD HAPPEN HOW TO PREVENT IT This particular air powered tool can be Always wear ANSI approved z87.1 capable of propelling materials such as safety glasses with side shields. fasteners, metal chips, sawdust, and Never leave operating tool unattended.
  • Page 5 SAFETY INFORMATION WA R N I N G RISK OF ENTANGLEMENT WHAT COULD HAPPEN HOW TO PREVENT IT Tools which contain moving elements, Do not wear loose clothing, jewelry, or or drive other moving parts, such as anything that may get caught or tangled impact sockets, can become entangled when using tool.
  • Page 6 SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT A tool left unattended, or with the air Remove air hose when tool is not in use hose attached, can be activated by and store tool in secure location away unauthorized persons leading to their from reach of children and untrained...
  • Page 7 SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT Loss of control of the tool can lead to Keep proper footing at all times. Do not injury to self of others in the work area. overreach, as slipping, tripping, and or falling can be a major cause of serious injury and or death.

  • Page 8: Package Contents

    SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT There is a risk of bursting if the tool is Follow lubrication instructions for best damaged. and safest operation. Follow assembly and repair instructions on how to properly change accessories.

  • Page 9: Preparation

    PREPARATION Before beginning assembly of product make sure all parts are present. Compare parts with packaging contents list and diagram above. If any part is missing or damaged, do not attempt to assemble the product. Contact the 1-800 customer service number for replacement parts. Estimated Assembly Time: 5-10 minutes Tools Required for Assembly (not included): Adjustable wrench ASSEMBLY INSTRUCTIONS...
  • Page 10 ASSEMBLY INSTRUCTIONS 4. Choose the correct impact socket (not provided) as needed and mount it onto the anvil (B). (See Figure 4) WA R N I N G Only use impact sockets that have an RPM rating equal to or greater than the tool itself. 5.

  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS 1. How to install/tighten threaded fasteners. Turn torque setting switch (part D) from right to left to desired torque setting and press trigger (part C) to engage. The tool anvil (part B) runs clockwise. (See Figure 1) 2. How to install/tighten threaded fasteners. Turn torque setting switch (part D) from left to right to desired torque setting and press trigger (part C) to engage.

  • Page 12: Care And Maintenance

    OPERA TING INSTRUCTIONS NOTE This tool features a weep hole (part F) on the front protective cover. The weep hole (part F) allows excess air to be released from the impact wrench automatically while still lubricating the tool when the proper lubrication instructions are followed.

  • Page 13: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. Grit or gum in tool. 1. Flush the tool with air-tool oil or gum solvent. 2. Lubricate the tool. 2. No oil in tool. 3. Low air pressure. 3. Adjust the regulator on the tool to maximum setting.

  • Page 14: Replacement Parts List

    REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-888-3KOBALT, 8:00 a.m.-8:00 p.m., EST, Monday-Friday. Part NO. Description Qty. Part NO. Description Qty. Protector cover Rotor oil seal Anvil bushing Front end plate Socket retainer Rotor blade O-ring 4.5 ×...
