- Page 1 Owner’s Manual Surface Mount Loudspeakers Atlas Sound Strategy Series ® Surface Mount Loudspeakers SM42T-B SM42T-W SM52T-B SM52T-W SM82T-B SM82T-W – 1 – AtlasSound.com Specifications are subject to change without notice.
-
Page 2: General Description
General Description All Atlas Sound Strategy Series speaker systems are designed to provide high fidelity, long life and installation convenience for com- mercial and residential applications. Because of their weather-resistant properties they are perfect for use indoors or out. The Atlas Sound Strategy Series surface mount speakers are available in 4", 5... - Page 3 To find out more about the formulas used to determine ceiling speaker spacing, check out the book Sound System Engineering by Don and Carolyn Davis. To find out more about the limits of wide dispersion loudspeakers, download the Atlas Sound white paper on the subject at http://www.atlassound.com/Support/WhitePapers.aspx .
-
Page 4: Installation
CAUTION: Suspending any object is potentially dangerous and should be attempted only by individuals who have a thorough knowl- edge of the techniques and regulations of rigging objects overhead using ONLY hardware approved for this type of installation. Atlas Sound strongly recommends that Strategy Series Surface Mount enclosures only be suspended overhead when taking into account all current national, federal, state, and local regulations. -
Page 5: Painting The Speakers
4Ω Ω speakers per channel = a 4Ω Ω loudspeakers without damaging your ampli- Input Left Right Atlas Sound PA702 Amplifier 4Ω Per Channel Figure 1 4Ω Each Channel 8Ω 8Ω 8Ω 8Ω... -
Page 6: Line Matching Transformer Connections
Figure 2 6 X 15 Watt = 90 Watts Total Load On Amplifier 15 Watt Tap 15 Watt Tap 15 Watt Tap Input Atlas Sound AA120 Amplifier 120 Watt 70.7V Output 15 Watt Tap 15 Watt Tap 15 Watt Tap AtlasSound.com... -
Page 7: Specifications
Owner’s Manual Surface Mount Loudspeakers Specifications SM42T Ω Transducer Complement ⁄ – 7 – AtlasSound.com Specifications are subject to change without notice. - Page 8 Surface Mount Loudspeakers Owner’s Manual Specifications SM52T Ω Transducer Complement ⁄ ⁄ ⁄ ⁄ AtlasSound.com – 8 – Specifications are subject to change without notice.
- Page 9 Owner’s Manual Surface Mount Loudspeakers Specifications SM82T Ω Transducer Complement ⁄ ⁄ ⁄ – 9 – AtlasSound.com Specifications are subject to change without notice.
- Page 10 Surface Mount Loudspeakers Owner’s Manual Notes AtlasSound.com – 10 – Specifications are subject to change without notice.
- Page 11 Owner’s Manual Surface Mount Loudspeakers Notes – 11 – AtlasSound.com Specifications are subject to change without notice.
-
Page 12: Limited Warranty
Atlas Sound will solely, at its discretion, replace at no charge or repair free of charge defective parts or products when the prod- power, altered, serviced or installed in other than a workmanlike manner. - Page 13 Available in Black or White • Five-Year Warranty SM82T-WH Applications Specifications Use Atlas Sound Surface Mount loudspeaker systems for commercial, professional, and residential applications or where high-fidelity sound and Model SM82T(-B)(-WH) weather-resistance are desired. Full-range frequency response makes Power Rating (RMS)
- Page 14 27 threaded hole is provided on the C-bracket to allow the SM82T the following performance criteria: Power handling, 150 Watts RMS; speaker to be mounted on any Atlas Sound microphone stand for near- Frequency response, 65Hz – 20kHz (±3dB); Sensitivity, 92dB SPL at one field live sound applications.
