Yealink SIP-T42G Quick Installation Manual

Configuring Your Phone
Configuring via web user interface
Accessing the web user interface:
1. Press the OK key when the phone is idle to obtain the IP address of the phone.
2. Open the web browser on your computer, enter the IP address into the address bar (e.g.,
"http://192.168.0.10" or "192.168.0.10"), and then press the Enter key.
3. Enter the user name (default: admin) and password (default: admin) in the login page
and click Confirm.
Network Settings: Click on Network->Basic->IPv4 Config
You can configure the network settings in the following ways:
DHCP: By default, the phone attempts to contact a DHCP server in your network to obtain its valid
network settings, e.g., IP address, subnet mask, gateway address and DNS address.
Static IP Address: If your phone can not contact a DHCP server for any reason, you need to
configure the IP address, subnet mask, gateway address, primary DNS address and
secondary DNS address for the phone manually.
Note: The wrong network settings may result in the inaccessibility of your phone and may have an impact on the
network performance. Contact your system administrator for more information.
Account Settings: Click on Account->Register->Account X (X=1,2,3)
Parameters of the account:
Register Status: It shows the register status of the current account.
Line Active: You can select Enabled/Disabled to enable/disable the account.
Label: It is shown on the LCD to identify the account.
It is shown as Caller ID when placing a call.
Display Name:
Register Name: It is an authenticated ID for authentication provided by ITSP (required).
It is provided by ITSP for registration (required).
User Name:
It is provided by ITSP for registration (required).
Password:
Server Host: It is provided by ITSP for registration (required).
Register status icons on the LCD screen:
Registered Register Failed
Note: Check with your system administrator if any error appears during the registration process or a specific
configuration is required for your registration.
Configuring via phone user interface
Network Settings:
Press the Menu soft key when the phone is idle, select Settings->Advanced Settings (password: admin)
->Network->WAN Port/VLAN/Webserver Type/802.1x Settings/VPN to configure the network.
Account Settings:
Press the Menu soft key when the phone is idle, select Settings->Advanced Settings (password: admin)
->Accounts to configure the account.
Note: For more informantion on account parameters, refer to Configuring via web user
For more information, refer to the User Guide available online:
http://www.yealink.com/SupportDownloadfiles_detail.aspx?CateId=312&flag=142
c
Copyright 2014 YEALINK NETWORK TECHNOLOGY CO.,LTD.
Ultra-elegant Gigabit IP Phone
Registering
interface.
www.yealink.com
Quick Installation Guide
Applies to firmware version 72.1 or later.
SIP-T42G
(V72.4)
