- Page 1 Owner`s Manual...
-
Page 2: Table Of Contents
Contents Precautions ············································································································· 1 Features of This Unit ································································································ 2 Names and Functions ······························································································ 4 Connections ·········································································································· 12 Operations ············································································································· 16 How to Use Remote Control ·················································································· 18 Block Diagram ······································································································· 20 Specifications ········································································································ 21 Before Asking for Repair Services ·········································································· 22... -
Page 3: Precautions
Precautions INTEGRATED AMPLIFIER L-550AX Installation place Cautions in connecting speakers This unit shall be installed in a well-ventilated and effectively When making speaker system connections, exercise extra heat-released place because this unit is an A-class amplifier care not to short-circuit between ! and @ of the speaker ter- and generates considerable heat. -
Page 4: Features Of This Unit
Features of This Unit LECUA-WM - LUXMAN Electric Controlled High-inertia power supply Ultimate Attenuator - Waiting Matrix High-inertia electronic circuit that combines a large-capacity EI-core-type power transformer with customizable 10,000μF Application of the system to obtain attenuation by combin- × 4 capacitor blocks. - Page 5 This unit is equipped with a phono amplifier that is compat- ible with the MM/MC cartridge to achieve analog record re- This unit has been manufactured based on LUXMAN's new production in a high-grade level without adding a dedicated standard size (440mm wide, common with a series of sepa- phono amplifier.
-
Page 6: Names And Functions
