WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
]
For Outdoor Use Only
(outside any enclosure)
SSS3416TBSN
Owner's Manual
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8227 (TOLL-FREE), 07:00 A.M. – 16:00 P.M.
(EST), MONDAY-FRIDAY.
Service Center: 1-877-885-8227
0
MODEL#SSS3416TBSN
Advertisement
Table of Contents
Related Manuals for BBQ SSS3416TBSN
Summary of Contents for BBQ SSS3416TBSN
- Page 1 MODEL#SSS3416TBSN WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these instructions could result in fire or explosion that could cause property damage, personal injury or death.
-
Page 2: Grill Operation
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to use this gas barbecue grill to prevent possible bodily injury or property damage. NOTE: This grill must be used with natural gas only. Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. SSS3416TBSN Owner’s Manual... -
Page 3: Table Of Contents
Assembly Instructions..................... 7 Operating Your Grill....................... 12 Natural gas connection....................12 Checking for Leaks......................13 Lighting Your Grill......................13 Excess flow safety valve reset procedure ..............15 Care and Maintenance ....................15 Troubleshooting ......................16 Warranty Program ......................18 SSS3416TBSN Owner’s Manual... -
Page 4: For Your Safety
DANGER: Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational vehicle to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation. SSS3416TBSN Owner’s Manual... -
Page 5: General Information
*** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. SSS3416TBSN Owner’s Manual... -
Page 6: Package Contents
1 PC 1 PC Left cooking grid Side knob support Heating plate 3 PCS Side knob 1 PC Left side panel 1 PC Side burner frame 1 PC Left door 1 PC Side burner grate 1 PC SSS3416TBSN Owner’s Manual... -
Page 7: Hardware List
Spring washer 4mm Flat Washer 4mm GG: 4 PCS HH: 6 PCS M4 Nut M4 x 12 Bolt Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). SSS3416TBSN Owner’s Manual... -
Page 8: Assembly Instructions
Repeat the procedure with cart right side panel (R) and cart back panel (N). e) Go back and tighten all bolts using the screwdriver provided. M6 x 15 Bolt 2 PCS Spring washer 2 PCS Flat washer 2 PCS SSS3416TBSN Owner’s Manual... - Page 9 Insert one M6 x 15 bolt (AA), one spring washer (BB) and one flat washer (CC) into the each pre-drilled hole. Tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 2 PCS Spring washer 2 PCS Flat washer 2 PCS SSS3416TBSN Owner’s Manual...
- Page 10 Repeat the same procedure with the left side shelf (B) and body assembly. d) Go back and tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 4 PCS SSS3416TBSN Owner’s Manual...
- Page 11 Put the left cooking grid (I) and right cooking grid (H) upon the heating plates. Put the left warming rack (F) and right warming rack (G) on the side walls of firebox. d) Close the top lid. SSS3416TBSN Owner’s Manual...
-
Page 12: Operating Your Grill
Pipe sealing compound or pipe thread tape of the type resistant to the action of natural gas must be used on all male pipe threads. Apply compound or tape to at least the first three to four threads when making connections. Never store or use gasoline or other volatile substance in the vicinity of this grill. SSS3416TBSN Owner’s Manual... -
Page 13: Natural Gas Connection
Failure to open lid while igniting the grill’s burners or not waiting five minutes to allow gas to clear if the grill does not light, may result in an explosion, which could cause serious bodily injury or death. SSS3416TBSN Owner’s Manual... - Page 14 Remove the lighting stick then insert a match into the end of lighting stick. Light the match. Once lit, place the flame to reach the burner ports. Press the control knob and rotate it counterclockwise to the ‘’HIGH’’ position. The burner should light immediately. Adjust burner to the desired cooking temperature. SSS3416TBSN Owner’s Manual...
- Page 15 Controlling the intensity of the flare-ups is necessary, however, in order to avoid burned or unevenly cooked foods and to prevent the possibility of accidental fire. SSS3416TBSN Owner’s Manual...
-
Page 16: Excess Flow Safety Valve Reset Procedure
Recommended cleaning materials Mild dishwashing liquid detergent Hot water Nylon cleaning pad Wire brush Paper clip Putty knife/scraper Compressed air DO NOT use cleaners that contain acid, mineral spirits or xylene. SSS3416TBSN Owner’s Manual... -
Page 17: Troubleshooting
Tighten by hand ONLY - do not use tools. Obstruction of gas flow. Clear burner tubes. Check for bent or kinked hose. Disengagement of burner to valve. Reengage burner and valve. Spider webs or insect nest in Clean venturi. venturi. Clean burner ports. SSS3416TBSN Owner’s Manual... - Page 18 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Natural Gas Models must be open a minimum of 1/16 in. *Propane Models must be open a minimum of 1/8 in.. SSS3416TBSN Owner’s Manual...
-
Page 19: Warranty Program
If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8227, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ Co., Ltd. Niuyang Industrial Zone, Liaobu Town, Dong Guan City, Guang Dong, China. Printed in China SSS3416TBSN Owner’s Manual...
