WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
]
For Outdoor Use Only
(outside any enclosure)
SSS3416TCS
Owner's Manual
Outdoor LP Gas Barbecue Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8227 (TOLL-FREE), 07:00 A.M. – 16:00 P.M.
(EST), MONDAY-FRIDAY.
Service Center: 1-877-885-8227
0
MODEL#SSS3416TCS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BBQ SSS3416TCS
Summary of Contents for BBQ SSS3416TCS
- Page 1 MODEL#SSS3416TCS Outdoor LP Gas Barbecue Grill WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these instructions could result in...
-
Page 2: Grill Operation
NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. SSS3416TCS Owner’s Manual... -
Page 3: Table Of Contents
Operating Your Grill....................... 12 Connecting Gas Cylinder ....................13 Checking for Leaks......................13 Lighting Your Grill......................14 Excess flow safety valve reset procedure ..............16 Care and Maintenance ....................17 Troubleshooting ......................18 Warranty Program ......................20 SSS3416TCS Owner’s Manual... -
Page 4: For Your Safety
Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. Safe Locations For Use Of This Outdoor Grill SSS3416TCS Owner’s Manual... -
Page 5: General Information
*** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. SSS3416TCS Owner’s Manual... -
Page 6: Package Contents
Side knob support 1 PC 1 PC 1 PC Left side panel Side knob Left door 1 PC Side burner frame 1 PC Cart front beam 1 PC Side burner grate 1 PC Back panel 1 PC SSS3416TCS Owner’s Manual... -
Page 7: Hardware Contents
Spring washer 4mm Flat Washer 4mm GG: 4 PCS HH: 6 PCS M4 Nut M4 x 12 Bolt Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). SSS3416TCS Owner’s Manual... -
Page 8: Assembly Instructions
Repeat the procedure with cart right side panel (S) and cart back panel (N). e) Go back and tighten all bolts using the screwdriver provided. M6 x 15 Bolt 2 PCS Spring washer 2 PCS Flat washer 2 PCS SSS3416TCS Owner’s Manual... - Page 9 Insert one M6 x 15 bolt (AA), one spring washer (BB) and one flat washer (CC) into the each pre-drilled hole. Tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 6 PCS Spring washer 6 PCS Flat washer 6 PCS SSS3416TCS Owner’s Manual...
- Page 10 (BB) and flat washer (CC) into pre-drilled holes, and then tighten the bolts by hand. d) Go back and tighten all the bolts using the screwdriver provided. M6 x 15 Bolt 4 PCS Spring washer 4 PCS Flat washer 4 PCS SSS3416TCS Owner’s Manual...
- Page 11 (EE) and one M4 nut (GG) into each pre-drilled holes by screwdriver provided Put the side burner grate (AB) upon the side burner frame (Z). M4 x 12 Bolt 4 PCS Flat washer 4 PCS Spring washer 4 PCS M4 Nut 4 PCS SSS3416TCS Owner’s Manual...
- Page 12 Place the gas tank on the gas holder, and then clip it using the tank clip. b) Connect the tank with regulator by screwing regulator collar onto the tank valve. Conduct the leaking test on page 13. SSS3416TCS Owner’s Manual...
-
Page 13: Operating Your Grill
Never store or use gasoline or other volatile substances in the vicinity of this grill. Never store a spare propane cylinder in the vicinity of this grill, or in the vicinity of another potential heat source. Never fill the propane cylinder beyond 80% full. SSS3416TCS Owner’s Manual... -
Page 14: Connecting Gas Cylinder
Failure to open lid while igniting the grill’s burners or not waiting five minutes to allow gas to clear if the grill does not light, may result in an explosion, which could cause serious bodily injury or death. WARNING: Never stand with your head directly over the grill when preparing to light the main burners, to prevent possible bodily injury. SSS3416TCS Owner’s Manual... -
Page 15: Lighting Your Grill
Press the control knob and rotate it counterclockwise to the ‘’HIGH’’ position. The burner should light immediately. Adjust burner to the desired cooking temperature. 2 in. 1 in. Observe flame height when lit: Flame should be a blue/yellow color between 0 in. 1 to 2 inches high. SSS3416TCS Owner’s Manual... - Page 16 Always turn the valve knob(s) clockwise to the ‘’HIGH’’ position, and then press and turn it to ‘’OFF’’. Never force the knob without pressing it. This could damage the valve. Promptly turn the gas supply to the “OFF” position at the propane cylinder. Close the lid of the grill. SSS3416TCS Owner’s Manual...
-
Page 17: Excess Flow Safety Valve Reset Procedure
DO NOT clean any grill part in a self-cleaning oven. The extreme heat will damage the finish. Cleaning Burning off the grill after every use (approx. 15 minutes) will keep excessive food residue from building up. Clean the grill before and after cooking is recommended. SSS3416TCS Owner’s Manual... - Page 18 Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. SSS3416TCS Owner’s Manual...
-
Page 19: Troubleshooting
High or gusting winds. Turn front of grill to face wind or Increase flame height. Low on propane gas. Replace or refill propane tank. Excess flow valve tripped. Refer to the Excessive flow safety SSS3416TCS valve reset procedure on page 16. Owner’s Manual... - Page 20 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Propane Models must be open a minimum of 1/8 in.. SSS3416TCS Owner’s Manual...
-
Page 21: Warranty Program
If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8227, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ CO., Ltd. Niuyang Industrial Zone, Liaobu Town, Dong Guan City, Guang Dong, China. Printed in China SSS3416TCS Owner’s Manual...
