After finishing all the settings here, please click OK to save the configuration.
3 . 1 0 . 6 L A N t o
3 . 1 0 . 6 L A N t o
Here you can manage LAN-to-LAN connections by maintaining a table of connection profiles.
You may set parameters including specified connection direction (dial-in or dial-out),
connection peer ID, connection type (VPN connection - including PPTP, IPsec Tunnel, and
L2TP by itself or over IPsec) and corresponding security methods, etc.
The router supports up to 32 VPN tunnels simultaneously. The following figure shows the
summary table.
Available settings are explained as follows:
Item
Set to Factory Default
Vigor2760 Series User's Guide
with IPsec Policy when you specify the remote node. Check
the Medium, DES, 3DES or AES box as the security
method.
Medium-Authentication Header (AH) means data will be
authenticated, but not be encrypted. By default, this option
is invoked. You can uncheck it to disable it.
High-Encapsulating Security Payload (ESP) means
payload (data) will be encrypted and authenticated. You
may select encryption algorithm from Data Encryption
Standard (DES), Triple DES (3DES), and AES.
Local ID (Optional)- Specify a local ID to be used for
Dial-in setting in the LAN-to-LAN Profile setup. This item
is optional and can be used only in IKE aggressive mode.
L A N
L A N
Description
Click to clear all indexes.
264
