Interface
PWR
I / O
Factory Reset
VDSL/ADSL
USB (1-2)
LAN (1-4)
Vigor2760 Series User's Guide
Description
Connector for a power adapter.
Power switch.
Restore the default settings. Usage: Turn on the router (ACT LED is
blinking). Press the hole and keep for more than 5 seconds. When you
see the ACT LED begins to blink rapidly than usual, release the button.
Then the router will restart with the factory default configuration.
Connector for accessing the Internet.
Connector for USB storage device (Pen Driver/Mobile HD) or printer or
3G backup.
Connectors for local network devices.
6
