FMI The Monterey PN36 Installation And Operating Instructions Manual

3-sided, wood-burning fireplace

Advertisement

This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also contains information that will enable
you to obtain replacement parts or optional accessory items when needed. Keep it with your other important papers.
WARNING: ALWAYS LEAVE GLASS DOORS FULLY
OPENED WHEN OPERATING THE APPLIANCE
MANUFACTURED BY FIREPLACE MANUFACTURERS INC.
2701 S. HARBOR BLVD., SANTA ANA, CA 92704

INSTALLATION AND OPERATING INSTRUCTIONS

CHECK LOCAL CODES BEFORE INSTALLING THIS FIREPLACE
3-SIDED, WOOD-BURNING FIREPLACE
SAVE THIS BOOK
• Do not store or use gasoline or any other
flammable vapors or liquids in the vicinity
of this or any other appliance.
• Due to high temperatures, the appliance
should be located out of traffic and away
from furniture and draperies.
• Do not place clothing or other flammable
materials on or near the appliance.
• NEVER leave children unattended when a
fire is burning in the fireplace.
WARNING:
ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE
PROPERTY DAMAGE, OR LOSS OF LIFE.
REFER TO THIS MANUAL. FOR ASSISTANCE
OR ADDITIONAL INFORMATION, CONSULT A
QUALIFIED
DISTRIBUTOR.
WARNING: THIS FIREPLACE IS INTENDED
FOR USE WITH WOOD, DECORATIVE GAS
APPLIANCE AND VENT FREE GAS LOGS
WHICH BURNS PROPANE OR NATURAL GAS
ONLY.
The Monterey
(PENNINSULA)
MODEL PN36
FOR YOUR SAFETY
IMPROPER
CAN
CAUSE
INSTALLER
ICBO ES ER-3507
INSTALLATION,
INJURY,
OR
LOCAL
P/N 55059
REV B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the The Monterey PN36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FMI The Monterey PN36

  • Page 1: Installation And Operating Instructions

    The Monterey (PENNINSULA) MODEL PN36 3-SIDED, WOOD-BURNING FIREPLACE INSTALLATION AND OPERATING INSTRUCTIONS SAVE THIS BOOK This book is valuable. In addition to instructing you on how to install and maintain your appliance, it also contains information that will enable you to obtain replacement parts or optional accessory items when needed. Keep it with your other important papers. WARNING: ALWAYS LEAVE GLASS DOORS FULLY FOR YOUR SAFETY OPENED WHEN OPERATING THE APPLIANCE...
  • Page 2: Table Of Contents

    C O N T E N T S 8. CHIMNEY PIPE INSTALLATION....PG .6 1. INTRODUCTION........PG. 2 9. FINISHING YOUR CHIMNEY SYSTEM..PG.8 2. SELECTING LOCATION......PG. 3 10. TERMINATIONS........PG. 10 3. CLEARANCES........PG. 3 11.FINISHING YOUR FIREPLACE....PG. 11 4. FRAMING..........PG. 3 12. OPERATING GUIDELINES AND MAINTENANCE 5.
  • Page 3: Introduction

    YOU MAY CAUSE A will make installation easier. FIRE HAZARD! The FMI warranty will be voided by, and FMI disclaims any 4. If an outside air kit is to be installed, accessibility to outside responsibility for the following actions: combustion air must be considered.
  • Page 4: Selecting Location

    9 inches of the effective opening of this fireplace. 1. Do not connect this fireplace to a chimney system other than an FMI chimney system. *The effective opening is considered the opening 2. Install in an area providing ventilation and where actual heat output may occur adequate combustion air.
  • Page 5: Hearth Extensions

    Figure 5 Figure 8 Proceed to secure fire- place to prepared framing at nailing flanges located at the sides of the fire- place as shown in figure Figure 6 Figure 9 HEARTH EXTENSIONS A hearth extension is required to protect combustible floor surrounding fireplace.
  • Page 6: Outside Air Kit Installation

    Figure 10 Figure 12 CAUTION: AIR INLET DUCTS MUST NOT TERMINATE IN ATTIC SPACE. Avoid installing outside air eyebrow in areas where inlet opening may be blocked by snow, bushes or other obstacles. It should also be located beyond the reach of small children. The maximum height for the air inlet above platform of fireplace is within 3 feet below the termination flue gas outlet.
  • Page 7: Chimney Pipe Installation

    FOR UNVENTED ROOM HEATERS, ANZI\IAS\AGA Z21.11.2, ARE TO BE INSTALLED IN THIS FIREPLACE. NOTE: An appropriate FMI hood (as shown in page 13) must be installed when using an unvented gas log set. This appliance shall also be installed in accordance with the Na- tional Fuel Gas code, ANSI Z223.1-1988...
  • Page 8 Figure 15 Figure 17 SUPPORT SECTIONS It is important to assure that the joint between the chimney sections is fully locked. Check by pulling chimney upward The chimney support section is a 4 strap, 12-inch length of after locking. pipe. A chimney support is required every 30 feet above the The chimney should not come apart if properly locked.
  • Page 9: Finishing Your Chimney System

    To achieve desired offset, you may install combinations of 12,18,36, or 48 inch lengths of double wall pipe (see figure 20 and Rise and Offset Chart). All Joints between offset should be secured with two screws, only on the outer pipe, and shall not penetrate the inner stainless.
  • Page 10: Minimum Chimney Height

    MAXIMUM CHIMNEY HEIGHT The maximum height approved for any chimney run with this fireplace system is 50 feet measured from bottom of fire- place to flue outlet-end of pipe. CHIMNEY MAINTENANCE Have your chimney system cleaned and inspected regularly to ensure safe and efficient operation. Refer to your Owners Manual for further guidelines on maintenance and operation.
  • Page 11: Terminations

    The terminations approved for this fireplace are RTL-10D, FLASHING INSTALLATION which can be used for flashing or chase and ETL-10D for chase style termination only. Figure 27 shows an RTL-10D Determine the flashing to be used with the roof-opening round top termination. chart.
  • Page 12: Finishing Your Fireplace

    When placing facing at the upper edge of the effective open- FINISHING YOUR FIREPLACE ing of the fireplace, provide an “L” shaped piece of metal ex- tending the full width of the opening. CABINET DOOR INSTALLATION Secure with sheet metal screws at a distance high enough from the edge as to not interfere with the operation of doors.
  • Page 13: Operating Guidelines And Maintenance Instructions

    WARNING: RISK OF FIRE! REPLACE GRATE WITH The damper control lever is located inside the fire chamber FMI MODEL 36PN GR GRATE ONLY. (see figure 33). Make sure lever is cool before handling. Pull down to CLOSE, push up to OPEN. The damper must be Never obstruct the flow of combustion and ventilation air.
  • Page 14: Replacement And Accessory Parts

    * The model name or number of your fireplace may be found on the rating plate located inside the fireplace (see figure 1). *Refer to the parts list and diagrams when ordering replacement parts for your fireplace. * Repair parts or accessory items may be bought from your distributor/dealer or directly from FMI. *All product specifications are subject to change without notice.
