FMI LVF43NR Owner's Operation And Installation Manual

Unvented (vent-free) gas fireplace

Advertisement

PFS
MODELS (V)LVF43NR AND
(V)LVF43PR
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
For more information, visit www.fmiproducts.com
®
US
UNVENTED (VENT-
FREE) GAS FIREPLACE
OWNER'S OPERATION
AND INSTALLATION
MANUAL
