Sussman SSB 12-18 Installation, Operation And Maintenance Manual

Electric boilers

Advertisement

Quick Links

Model No. SSB- __________________
Boiler Serial No. _________________
National Board No. ______________
Safety Valve Set Pressure________
Power Circuit Voltage ____________
Control Circuit Voltage ___________
Amps _____ Phase _____ HZ ______
IMPORTANT: This data file contains the National Board
Registration Certificate approving your boiler. It must be
kept near the boiler at all times.
SSB Boilers have Stainless Steel all wetted metal parts. SSB
boilers shall be operated using only deionized water, having
a maximum conductance of 1 microSiemen per cm
(1 S/cm) [minimum specific resistivity of 1 megohm per cm
(1ΜΩ/cm)].
Products covered by this manual:
Series
KW Range
Steam Rate*
______________________________________________________________________
SSB
12-180
36-542 lbs/hr 1.2-18.4 0-100 psig
*Steam Rate- Steam @ 212 F with 50 F feed water
IMPORTANT NOTE:
As you follow these instructions, you will notice warning and caution symbols. This blocked information is important for the safe and efficient
WA R N I N G
states a hazard which
may cause serious injury or death if precautions
are not followed.
PSIG
Max
BHP
Design Pres.
Work Pres.
85 psig
C A U T I O N
minor injury or product damage may occur if you
do not follow instructions.
A Division of Sussman-Automatic Corporation
43-20 34th Street, Long Island City, NY 11101 • (718) 937-4500
1-800-238-3535 • Fax: (718) 937-4676 • email: seb@sussmancorp.com
www.sussmanboilers.com
SSB Installation, Operation
and Maintenance Manual

TABLE OF CONTENTS

Component Identification . . . . . . . . . . . . . . . . . 2
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Installation
Piping. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Pre-Operation Check . . . . . . . . . . . . . . . . . . . . . . . . 8
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Blowdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Timing Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . 12
Blowdown Separator Tanks . . . . . . . . . . . . . . . . . 14
Specification Charts . . . . . . . . . . . . . . . . . . . . . . . 15
Sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Gauge Glass Installation. . . . . . . . . . . . . . . . . . . . 17
Gauge Glass Use and Care . . . . . . . . . . . . . . . . . . 18
Element Replacement . . . . . . . . . . . . . . . . . . . . . . 19
signals a situation where
. . . . . . . . . . . . . . . . 12
. . . . . . . . . . . . . 12
. . . . . . . . . . . . . 12
. . . . . . . . . . . . . . . . 13
. . . . . . . . . . . . . . . . . . . . . 13
. . . . . . . . 13
. . . . . . . . 13
IMPORTANT NOTE:
This highlights information that is especially
relevant to a problem-free installation.
M A D E I N U S A
PUR 101137SSB
2/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSB 12-18 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sussman SSB 12-18

  • Page 1: Table Of Contents

    A Division of Sussman-Automatic Corporation 43-20 34th Street, Long Island City, NY 11101 • (718) 937-4500 M A D E I N U S A 1-800-238-3535 • Fax: (718) 937-4676 • email: seb@sussmancorp.com...
  • Page 2: Dimensional Information And Component Identification

    Installation, Operation & Maintenance Manual Dimensional Information & Component Identification Model SSB _________________________________ _______________________________________ ___________________________________ WATER STEAM SYMBOL ITEM SSB12-18 SSB 24-72 SSB 100 SSB 135-180 _______________________________________ MODEL INLET OUTLET ⁄ ⁄ Steam Outlet " 10" " 9" __________________________________________________________________ SSB 12–18 37"...
  • Page 3: Dimensional & Clearing Specifications

    Installation, Operation & Maintenance Manual Dimensional & Clearance Specifications Steam Outlet Operating High Limit Pressure Safety Valve Pressure Pressure Gauge Control Control On/Off Switch Gauge Glass Liquid Level Assembly Control Height Water Feed Drain Valve Inlet Left Front Width Length Side Elevation Front Elevation Allow 24"...
  • Page 4: Wiring Diagrams

    Installation, Operation & Maintenance Manual Wiring Diagram Control Circuit 120V 1PH INPUT Control Terminal Block Pilot Light 7-Day 24 Hr Open Timer Close ES81600 Motorized Automatic Blowdown Blowdown System Time Delay Relay Valve ON/OFF SWITCH SOLENOID PILOT VALVE LIGHT PUMP MOTOR RELAY CONTACTORS OPERATING...
  • Page 5: Wiring Diagrams

    Installation, Operation & Maintenance Manual Wiring Diagram Power Circuit FIELD WIRING THREE PHASE SINGLE PHASE MAIN POWER MAIN POWER SUPPLY FACTORY WIRING SUPPLY L1 L2 TERMINAL POWER BLOCK TB 1 (see note 1) PILOT LIGHT POWER FUSES (see Note 2) 480V 120V CONTACTORS...
  • Page 6: Piping

    Installation, Operation & Maintenance Manual Installation REFER TO NATIONAL AND ALL APPLICABLE LOCAL CODES FOR SPECIFIC INSTALLATION REQUIREMENTS. 1. The boiler should be mounted on a solid, level foundation. 2. The boiler should be located with suitable clearances, refer to page 2 and 3 and Code requirements. Piping ALL PIPING SHOULD BE INSTALLED BY A QUALIFIED LICENSED PLUMBER IN ACCORDANCE WITH NATIONAL AND LOCAL CODES.
  • Page 7: Wiring

    Installation, Operation & Maintenance Manual Wiring ALL ELECTRICAL WIRING MUST BE PERFORMED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES. C A U T I O N Assure that the power voltage and phase being supplied to the boiler matches the power voltage and phase of the boiler.
  • Page 8: Pre-Operation Check

    Installation, Operation & Maintenance Manual Pre-Operation Check (All Boilers) LWCO/PUMP CONTROL OPERATION AND TESTING 1. All valves for incoming water supply are to be fully opened. Boilers equipped with an auxiliary low water cut-off Main disconnect switch is to be in the "on" position. Boiler main control with a manual re-set button (required as switch is to be in the "on"...
  • Page 9: Operation

    Installation, Operation & Maintenance Manual Operation C A U T I O N With main disconnect “OFF” 6. Boiler steam pressure will gradually increase to the tighten all electrical connections before ener- operating pressure control set point, at which time gizing boiler to prevent arcing, carbonizing of the contactor(s) will de-energize.
  • Page 10: Timing Switch

    Installation, Operation & Maintenance Manual Digital Timer - Operation Instructions ON/OFF STATUS Í TO SET TIME & DAY OF CLOCK ON symbol displayed when timer is on and OFF 1. Press Menu symbol displayed when timer is off. 2. 24h AM or PM blinking, press –...
  • Page 11: Maintenance

    Installation, Operation & Maintenance Manual 24-Hour and 7-Day Time Switches Maintenance C A U T I O N HAZARD OF ELECTRIC SHOCK. PROGRAMMING DISCONNECT ALL ELECTRICAL POWER BEFORE WORKING F or electric steam boilers ON BOILER. equipped with Automatic Blowdown Systems ussman Electric Steam Boilers are designed for years of trou- ES 81600, refer to the fol- ble-free performance.
  • Page 12: Optional Equipment

    Installation, Operation & Maintenance Manual Standard Equipment Optional Equipment AUXILIARY LOW WATER CUT OFF HIGH PRESSURE WATER FEED SYSTEM • For model SSB boilers SSB81017MR • For model SSB12-72 PN SSB38002 (with manual reset). • For model SSB100-180 PN SSB38020 Used to supply makeup water and to maintain con- Senses water level electronically using a resistance stant water level when the boiler operating pressure...
  • Page 13: Automatic Blowdown System

    Installation, Operation & Maintenance Manual Optional Equipment (cont.) MULTISTAGE LOAD PROGRESSIVE BLOWDOWN SEPARATORS (see page 14) SEQUENCERS • For models SSB12-48 PN BDT-ASME36 Accurate control is provided by automatic progressive • For models SSB60-180 PN BDT-ASME42 sequencing in the use of energy and minimizing wear on A separator accepts the flash steam and effluent electrical components.
  • Page 14: Blowdown Separator Tanks

    " 2" 18" 42" The Sussman Separator design incorporates a water Maximum Boiler Working Pressure: 250 psi seal at the outlet which permits the operator to Maximum Blowdown Separator Pressure: 65 psi introduce cold water from the bottom to mix with...
  • Page 15: Specification Charts

    Installation, Operation & Maintenance Manual Steam Gauge Specifications Pressure/ Temperature __________________________________________ Chart ________________ Boiler Lbs/Hr 3-Ph __________________________________________ Model No. KW Rating Steam** Volts*** Amps Gauge Temperature Pressure F˚ C˚ ________________ PSIG SSB-12* 1.22 36.2 __________________________________________ ________________________ ________________________ SBS-18* 1.84 54.2 ________________________ __________________________________________ ________________________...
  • Page 16: Sizing

    Installation, Operation & Maintenance Manual Sizing Use the following Table to determine KW Boiler rating when steam load and feedwater temperatures are known. _____________________________________ ____________________ Feed Water ___________________________________ ______________________ ( F˚) .3347 .3355 .3375 .3388 .3406 .3422 .3431 .3447 .3458 ___________________________________ ______________________ .3318 .3326...
  • Page 17: Gauge Glass Installation

    Installation, Operation & Maintenance Manual Gauge Glass Installation IMPORTANT NOTE: Read all warnings and instructions before performing installation or Top Gauge maintenance. Safety glasses and gloves should be Fitting worn at all times when working with or examining water gauge glass and connections. Pressure in gener- ator to be at zero before proceeding.
  • Page 18: Gauge Glass Use And Care

    Installation, Operation & Maintenance Manual Gauge Glass Installation - Use and Care DO NOTs MAINTENANCE Examine the gauge glass regularly for any signs • DO NOT use glass if it contains any scratches, chips, or of clouding, scratching, erosion, or corrosion. The any other visible signs of damage.
  • Page 19: Element Replacement

    Installation, Operation & Maintenance Manual Element Replacement READ INSTRUCTIONS COMPLETELY BEFORE STARTING WORK C A U T I O N Before Installing your new elements be sure the low water cut-off and aux. low water cutoff (if supplied) is operating 1”...
  • Page 20 A Division of Sussman-Automatic Corporation 43-20 34th Street, Long Island City, NY 11101 • (718) 937-4500 M A D E I N U S A 1-800-238-3535 • Fax: (718) 937-4676 • email: seb@sussmancorp.com PUR 101137SSB 2/12 www.sussmanboilers.com...

This manual is also suitable for:

Ssb 135-180Ssb 24-72Ssb 80-100
