Drive Train

• Stop the engine when servicing the drive train.
• Allow the machine to cool off before servicing. The engine is very hot after
operation and may pose a burn hazard.

Tracks

• Support the machine securely on a firm, level surface with jack stands when
servicing.
• Make certain to adjust the track tension properly. Inproperly tensioned tracks
may wear or come off, resulting in property damage, serious injury or death.
NOTE
• The track stretches during its use-life. Inspect and adjust regularly.
Adjust Bolt
Swing
20 - 30mm (0.79" - 1.18")
3570M-0507-010E
Maintenance
Inspecting
1.
Lock Nut
2.
3.
-41-
Hoist one side of the machine so that the
machine is laterally parallel to the ground.
(Page 63)
Inspect the clearance between the track and
the second wheel to be between 20 and
30mm (0.79" - 1.18"). Adjust the tracks if the
clearance is not within this range.
Lower the machine.
