Asus Rampage V Extreme Manual page 80

•
•
* LAN ports LED indications
Activity Link LED
Status
Off
Orange
Orange (Blinking) Data activity
Orange (Blinking
then steady)
You can disable the LAN controllers in BIOS. Due to hardware design, the LAN1 port's
LEDs may continue to blink even when disabled.
** Bluetooth and Wi-Fi module LED indications
Wi-Fi LED
Status Description
Off No link
Green Linked
The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc. and any use of such
mark by ASUSTeK Computer Inc. is under license. Other trademarks and trade names are
those of their respective owners.
*** Audio 2, 4, 6 or 8-channel configuration
Headset
Port
2-channel
Light Blue Line In
Lime Line Out
Pink Mic In
Orange –
Black –
2-16
We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance for your USB 3.0 devices.
When using the external SATA port, ensure to use a compatible connector.
Description Status
No link Off
Linked Orange 100 Mbps connection
Green
Ready to wake up
from S5 mode
Bluetooth LED
Status
Off No link
Blue Linked
Blinking Data activity
4-channel
Line In
Front Speaker Out
Mic In
–
Rear Speaker Out
Speed LED
Description
10 Mbps connection
1 Gbps connection
Description
Wi-Fi LED
Wi-Fi 802.11 a/b/g/n/ac,
Bluetooth v4.0
6-channel
Line In
Front Speaker Out
Mic In
Center/Subwoofer
Rear Speaker Out
ACT/LINK SPEED
LED LED
LAN port
8-channel
Side Speaker Out
Front Speaker Out
Mic In
Center/Subwoofer
Rear Speaker Out
Chapter 2: Basic Installation
