BETCO GS15 User Manual

Automatic scrubber
Hide thumbs Also See for GS15:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
E8900 0 0‐00

G
S
S
1
5
5

G
S
S
1
5
5



15" Gr
rout
Autom
A
matic S S crubber

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS15 and is the answer not in the manual?

Questions and answers

Related Manuals for BETCO GS15

Summary of Contents for BETCO GS15

  • Page 1 E8900 0 0‐00     15” Gr rout   Autom matic S S crubber    ...

  • Page 2: Modifications And Improvements

    1.0 NOTES FOR THE CLIENT This manual provides information concerning use, maintenance and safety of Dirt Dragon machine designed and constructed to guarantee maximum performance, comfort and ease of use in a variety of circumstances. We invite you to read it with attention in order to avoid mistakes and obtain the best results. In addition, we suggest you refer to it if problems should arise.

  • Page 3: Machine Identification Data

    11. After you have replaced a component, make sure all electrical connections are fixed in order to ensure sufficient resistance to cable pulling. 12. Do not leave the machine unattended when it is plugged in. 13. DO NOT ALLOW THE SOLUTION PUMP TO RUN DRY for more than 5 minutes. 5.0 MACHINE IDENTIFICATION DATA 6.0 SERIAL NUMBER AND EC MARK Make sure the machine is fitted with its serial number and CE...

  • Page 4: Technical Specifications

    7.0 TECHNICAL SPECIFICATIONS Cleaning width ....14.8 in. Floor wiper length ....16.9 in. Brush diameter .

  • Page 5: Contents Of The Package

    8.0 TRANSPORT 8.1 UNPACKING Unpack the machine taking care to avoid any movements which could damage it. Check that all parts are integral. If this is not the case, DO NOT use the machine and consult your dealer. 8.2 CONTENTS OF THE PACKAGE •...

  • Page 6: Preparation Of The Machine

    10.0 PREPARATION OF THE MACHINE 10.1 LIFTING a. Your machine should have the handle in T position (see FIG. 4). b. Grip both arms of the handle at the middle (A) (see FIG. 4). c. Lift the machine after checking that the articulation coupler is firmly fastened (try lifting the machine a few times).
  • Page 7 11.0 CONTROLS AND FUNCTIONAL PARTS 11.1 CONTROLS (FIG. 5) 1. Main switch Start/Stop switch for the current input. 2. Mains light Light that comes on when the plug is connected to the socket. 3. Handle release Operates the releasing of the handle articulation (give half a turn counter-clockwise).
  • Page 8 11.3.2 ASSEMBLY 1) Put the floor wiper back by pushing it into its guides. 2) Insert the lateral lock in the special swallow tailed slide of the squeegee support and press it down. N.B. refit the squeegees back in the same position. 11.4 BRUSH The brush ensures removal of dirt thanks to its mechanical action on the floor.

  • Page 9: Squeegee Adjustment

    11.5 SQUEEGEE ADJUSTMENT The floor wipers are fitted with pressure adjustment devices so as to suit different types of surface. To regulate the pressure of the rubber lips turn the adjustment device (1 FIG. 8) clockwise to increase pressure or counter-clockwise to reduce it.

  • Page 10: Electrical Connections

    12.0 ACCESSORIES THIS OPERATION MUST BE CARRIED OUT WITH THE MACHINE OFF. 1. Connect the accessory pipe (1) to the relevant fitting (2). 2. Turn the suction inlet (2) counter-clockwise to activate suction. 3. Fit the water pipe (3) with the snap coupling (4). 4.
  • Page 11 15.0 STARTING UP 15.1 RULES FOR THE OPERATOR 1) Do not pour trichloroethylene, petrol, benzol, oil, acetone, hydrochloric acid, turpentine or other solvents into the tanks as these would damage the plastic or inflammable materials. 2) During use make sure that the power supply cord stays clear of the machine’s operating radius and, in particular, that it does not get caught under the spinning roll.

  • Page 12: Cleaning The Water Filter

    16.0 PRACTICAL ADVICE FOR USE 1) With very dirty floors or floors which are particularly difficult to clean, the following washing and drying operations can be performed: Pre-washing: switch on the main (1), brush (5) and water pump (7) switches, but not the suction motor one.

  • Page 13: Changing The Squeegee Blades

    17.3 CHANGING THE SQUEEGEE BLADES If the squeegees are worn and their action is insufficient (even after they have been washed by hand), we recommend you replace them. 1) Remove the floor wiper (see par. 11.3.1). 2) Remove the drying blade and the counter-blade from the support. 3) Install the new blades making sure that the drying blade (without teeth) is placed on the open side of the support and that the counter-blade is on the opposite side.

  • Page 14: Wiring Diagram

    20.0 WIRING DIAGRAM BROWN Water pump switch Water pump button BLACK Main switch LIGHT BLUE Suction/brush switch BLUE Fuse 20A Main bulb GROUNDING Filter...

  • Page 15: Troubleshooting

    21.0 TROUBLESHOOTING Trouble Cause Remedy The machine does not turn on....The ON/OFF switch is broken........Replace. The fuse has blown.............Replace. The power cord is unplugged........Plug in. The roll brush doesn’t work....The main switch is off..........Turn on main switch. There is an electrical or mechanical fault....Check the motor, condensator, and the drive belt.
  • Page 17 Ref. Part No. Description Qty. Ref. Part No. Description Qty. 1105606 Spring cotter, 4x16 din 1481 1105794 Self tapping screw + uni 6954 3.9x16 2 1105182 Screw, iso 7380 6x22 zb 21902001 Brush hooking lever 1105121 Nut, uni 5588 M4 23502008 Brush, dia.
  • Page 18 Ref. Part No. Description Qty. Ref. Part No. Description Qty. 1105494 Screw, 4x16 INOX 1255028 1/8" 6x8 union elbow 22602010 Pump support bracket 1255034 1/4" 6x8 union elbow 1108807 Washer, uni 6593 4x16 25002023 Supplementary pipe 13802018 Thermal protection for pump 25002022 Water pipe for brush 22602017...
  • Page 19 Ref. Part No. Description Qty. 1105802 Screw, TCTC 4x30 INOX 1105330 Washer, uni 6593 4x12 INOX 21202039 Suction accessory connection 21602009 Gasket for accessory connection 1105806 M4 split threaded rivet 21102023 Bushing 25002008 FLEX pipe, 120 mm 1105793 Self tapping screw 3.9 x 13 Cover 1160048 3137 O-ring...
  • Page 20 Ref. Part No. Description Qty. 23102005 Suction box 21602010 MAPPYSIL deadening gasket 1105807 Washer, uni 6592 4x16 1105494 Screw, 4x16 INOX 13402003 Vacuum motor 21202088 Motor guard 21202043 Motor cooling manifold 1105123 Nut, uni 5588 M6 1105324 Washer, uni 6593 6x18 13802017 Capacitor 16pF 13402002...
  • Page 21 Ref. Part No. Description Qty. Ref. Part No. Description Qty. 169112008 Dashboard label 21252006 Sheath for the left handle cable 222002005 Black handle 21202100 Dashboard 13802015 Filter 13802003 Bipolar switch with orange light 13802008 Core hitch, PA 238 RO 13802005 Bipolar switch with double red-green light 1 1105805 Screw, 3.5 x 14.5...
