CUSTOMER
PROGRAMMING
SOFTWARE (CPS)
Radio to be programmed
CPS Programming Cable
Drop-in Tray Charger
Figure 1: Setting up the radio to the CPS
The easiest way to program or change features
in your radio is by using the Customer
Programming Software (CPS) and the CPS
Programming Cable(*). CPS Software is
available for free as web based downloadable
software at:
www.motorolasolutions.com/DLR
USB Ports
To program, connect the DLR Series radio via
the Drop-in Charger Tray and CPS
Programming Cable to your computer as
shown in the picture above. Prior to
programming, verify that the switch in the
Programming Cable is in the 'Digital(**)'
position.
CPS allows you to easily program features
such as Direct Call, Radio Menu Options,
Private Groups, Direct Contacts, Channel
announcements, etc. It also gives you the
flexibility to prevent radio features to be
accidentally modified by users, by providing the
option to disable functionalities like Factory
Reset, Advanced Configuration Mode, etc. It
also provides security by giving the option to
set up a password for profile radio's
management. For more information, refer to
Features Summary Chart Section at the end of
the User Guide.
Notes: (*) CPS Programming Cable P/N# is
HKKN4027_.
(**) If your CPS Programming Cable is
showing "CPS / Flash", make sure to
position it to "Flash".
