  • Page 2: Quick Reference Guide

    Quick Reference Guide Table of Contents: Radio Overview Battery – Insert and Charge Basic Operations Models: DLR 1020 – 2 channels Advanced Configuration DLR 1060 – 6 channels Special Call Features Frequency band: CPS Software ISM 900 MHz Troubleshooting and FAQ...

  • Page 3: Radio Overview

    DLR 1020/1060 Radio Overview Top Button Power Button Antenna Tx/Rx Indicator Volume/ Up- Audio Down Control accessory Button Buttons connector Battery Channel/Menu Microphone Button Speaker Holster...
  • Page 4 DLR 1020/1060 Battery – Inserting To insert or remove the battery, set the latch in the “unlocked“ position, and open the battery door. Remember to always set the latch back to the “locked” position in order to prevent Unlocked/Locked battery from falling out by accident. latch Battery door...
  • Page 5 DLR 1020/1060 Battery – Charging Multiple-unit charger To charge a battery, insert the radio or a stand-alone battery into the single or multiple unit charger. The light on the charger is red when the radio is Holster charging. It turns to green Stand-alone battery once the radio is fully...

  • Page 6: Basic Operations

    DLR 1020/1060 Basic Operations ON/OFF Power Button – long press to turn the PRIVATE REPLY device ON/OFF, short Press Top Button to press to check battery queue up for Private status. Reply* (while someone is speaking to your channel), then push PTT to call the last person speaking.

  • Page 7: Advanced Configuration

    DLR 1020/1060 Advanced Configuration The DLR Advanced Menu Mode allows you to configure special settings in your radio without the need programming cables or additional software. Choose a 4-digit number (0000 to 9999). Customize it to ensure Profile ID # interference free/private communications.
  • Page 8 DLR 1020/1060 Advanced Configuration Menu Entering Advanced Menu To enter the Advanced Menu, push Power Button together with PTT Power and [+]. Button [+] Button PTT (Push-to-Talk) Button...
  • Page 9 DLR 1020/1060 Advanced Configuration Menu Browsing Advanced Menu Options “Programming Mode. Press Menu to continue.” Press Channel/Menu Profile button to cycle Number through the Advanced Menu options. Home Voice prompt Channel Channel Gain Button Long press PTT to exit Advanced Menu Mode.
  • Page 10 DLR 1020/1060 Advanced Configuration Menu 1. Profile ID Number – current value The radio announces the current PROFILE ID number “Current Profile ID: and prompts you to change it: <Digit1, Digit2, Digit3, Digit4>; to change, press [+] or [-]” Profile Press [+] or [-] Number to enter the...
  • Page 11 DLR 1020/1060 Advanced Configuration Menu 1. Profile ID Number – changing values As you press the [+] or [-], the radio will announce the first digit value and prompt you to change it: “First digit <number>.To change, press [+] or [-].” Profile Number Press [+] or [-]...
  • Page 12 DLR 1020/1060 Advanced Configuration Menu 1. Profile ID Number – sub-menu “zero, one, two, (…), As you press [+] or [-] to change the current digit, radio will nine, zero…” announce the values. Digit1 Digit2 Digit3 Digit4 Press Channel/Menu button to set digit and proceed to the Once you set the last digit of the Profile ID Number with the next one.
  • Page 13 DLR 1020/1060 Advanced Configuration Menu 1. Profile ID Number – modification confirmation Once you’ve done setting the 4-digits profile number, the radio “Profile ID saved as: will confirm the new Profile ID value. <digit1, digit2, digit3, digit4>. Press Menu to continue.”...
  • Page 14 DLR 1020/1060 Advanced Configuration Menu 2. Maximum Channels The radio announces the current maximum number of “Max Channels channels and prompts you to change it: <number>. To change, press [+] or [-].” Profile Number Press [+] or [-] Press to change the Channel/Menu number of Home...
  • Page 15 DLR 1020/1060 Advanced Configuration Menu 3. Top Button – current feature “Programmable Button The radio announces the current Top Button feature and Top Button <Top Button Feature>. prompts you to change it: To change, press [+] or [-].” Profile Number Press [+] or [-] to change the Press...
  • Page 16 DLR 1020/1060 Advanced Configuration Menu 3. Top Button – sub-menu options Use [+] / [-] buttons to browse the Top Button functions – Top Button you will hear their names read. “<Top button feature>” Private Reply Press [+] or [-] Direct to change the Disabled...
  • Page 17 DLR 1020/1060 Advanced Configuration Menu 4. MIC Gain The radio announces the current MIC Gain setting and “MIC Gain <MIC gain prompts you to change it: level>. To change, press plus or minus.” Profile Number Press [+] or [-] to change the Press MIC Gain Home...
  • Page 18 DLR 1020/1060 Advanced Configuration Menu 5. Home Channel The radio announces the current Home Channel setting “Home Channel <Home and prompts you to change it: channel setting> to change press [+] or [-].” Profile Number Press [+] or [-] to change the Press Home Channel Home...
  • Page 19 Special Call Features...
  • Page 20 DLR 1020/1060 Special Call Features As mentioned before, the Top Button can be configured to serve different functions: Special Call Features: • Private Reply Private Reply • Direct Call • Page All Available Direct Disabled Call* • Call All Available Button Mute: instant mute function Disabled: disables the Top Button...
  • Page 21 DLR 1020/1060 Special Call Features – Private Reply Private Call feature allows you to talk privately to the person Top Button currently talking to a group after the group radio (with LED) transmission is over. This allows to free the radio channel from unnecessary back and forward chatter.
  • Page 22 DLR 1020/1060 Special Call Features – Private Reply Step by step 1. User A is talking to a group. 2. You want to talk privately to the User A (currently speaking). You push the Top button and hear a “Private Reply” prompt. The LED light begins to blink, and the private talk is in queue.
  • Page 23 DLR 1020/1060 Special Call Features – Private Reply Step by step 1. User A is talking to a group. 2. You want to talk privately to the User A (currently speaking). You push the Top button and hear a “Private Reply” prompt. The LED light begins to blink, and the private talk is in queue.
  • Page 24 DLR 1020/1060 Special Call Features – Private Reply Step by step 1. User A is talking to a group. 2. You want to talk privately to the User A (currently speaking). You push the Top button and hear a “Private Reply” prompt. The LED light begins to blink, and the private talk is in queue.
  • Page 25 DLR 1020/1060 Special Call Features – Private Reply Top Button(with LED) – During the private communication, the LED on the solid light when in Top Button illuminates a solid light. Private If any of the radio users take too long to push the PTT button (10 seconds by default*), the private communication ends with a “Private Over”...
  • Page 26 DLR 1020/1060 Special Call Features – Private Reply A tip: How to apply Private Reply in your daily job The use of this feature reduces the need for phone extensions or cell phone calls to talk privately. Simply call on the radio the name of the person you want to talk to privately.
  • Page 27 DLR 1020/1060 Special Call Features – Direct Call The Direct Call Feature allows you to call one-on-one Top Button privately another pre-determined user that has been (with LED) mapped into the radio Top Button (this feature needs to be pre-programmed*) or to any radio channel instead.
  • Page 28 DLR 1020/1060 Special Call Features – Direct Call Step by step “<User B> Name” 1. To talk directly to User B press Top Button*. Your radio plays voice prompt with the “Private Name” (as programmed in CPS, if enabled) and top LED starts blinking orange, showing you are in queue waiting to talk privately to User B.
  • Page 29 DLR 1020/1060 Special Call Features – Direct Call Step by step 1. To talk directly to User B press Top Button*. Your radio plays voice prompt with the “Private Name” (as programmed in CPS, if enabled) and top LED starts blinking orange, showing you are in queue waiting to talk privately to User B.
  • Page 30 DLR 1020/1060 Special Call Features – Direct Call Step by step 1. To talk directly to User B press Top Button*. Your radio plays voice prompt with the “Private Name” (as programmed in CPS, if enabled) and top LED starts blinking orange, showing you are in queue waiting to talk privately to User B.
  • Page 31 DLR 1020/1060 Special Call Features – Direct Call “Private Step by step Over” 4A. If any of the radio users takes too long to push the PTT and reply back, the radio will time out (“Private Hang Time“ of 10 sec) and end the private communication while a playing “Private Over”...
  • Page 32 DLR 1020/1060 Special Call Features – Direct Call “Private Step by step Over” 4A. If any of the radio users takes too long to push the PTT and reply back, the radio will time out (“Private Hang Time“ of 10 sec) and end the private communication while a playing “Private Over”...
  • Page 33 DLR 1020/1060 Special Call Features – Direct Call Step by step 4A. If any of the radio users takes too long to push the PTT and reply back, the radio will time out (“Private Hang Time“ of 10 sec) and end the private communication while a playing “Private Over”...
  • Page 34 DLR 1020/1060 Special Call Features – Direct Call Top Button (with LED) A tip: Why and how to use Direct Call: Set up your employees to be able to contact directly and privately their supervisor, the Manager on Duty or to reach a designated person for special requests. To make a Direct Call simply press the Top Button and then push the PTT button to talk.
  • Page 35 DLR 1020/1060 Special Call Features – Call All Available Radio initiates Call All Available Call All Available allows to start a group transmission to anyone not engaged in a call. This creates a Group Call in a temporary “super channel group” with a 4-second group Radios busy in private hang time.
  • Page 36 DLR 1020/1060 Special Call Features – Call All Available A tip: How Call All Available can be applied: An employee in a retail store is trying to see if anyone took the backroom scanner. He presses the Top Button, then the PTT button and asks: “Does anybody know who has the backroom scanner? “.
  • Page 37 DLR 1020/1060 Special Call Features – Page All Available Radio initiates This feature is useful if you have more than 1 Page All Available or 2 channels. It allows the ability to communicate a message to all available radio users at once, without having to change Radios busy in private One-way group conversation...
  • Page 38 DLR 1020/1060 Special Call Features – Page All Available Application examples: 6 channel radio Top Button: Private Reply Channel 1: Page All Available Example 1: An employee in a retail store is looking for anyone (in any of the group radio channels) who can come over to give him a hand in the back room.
  • Page 39 DLR 1020/1060 Customer Programming Software – CPS Customer Programming Software (CPS) allows you to program or change features in your radio. To use CPS, you need to download it from the internet and connect your radio with the computer using the CPS Programming Cable. Using CPS, you can set Private Hang Time, Group Hang Time, program all radio buttons, channels and much more.
  • Page 40 DLR 1020/1060 Customer FAQ and Troubleshooting To help you answer some of the Frequently Asked Questions and give you some Troubleshooting tips here are some useful documents. Click adequate buttons to open PDF attachments: Private Reply & Direct Call DLR Troubleshooting For more information refer to the User Guide or go to our DLR website: www.motorolasolutions.com/DLR...
