EOC-20/21
Ethernet over Coaxial
Master/Subscriber Pair

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EOC-20 and is the answer not in the manual?

Questions and answers

Related Manuals for CTC Union EOC-20

Summary of Contents for CTC Union EOC-20

  • Page 1 EOC-20/21 Ethernet over Coaxial Master/Subscriber Pair...
  • Page 3 Tel: +886-2-26591021 Fax: +886-2-27991355 Email: info@ctcu.com URL: http://www.ctcu.com EOC20/21 User Manual Ethernet over Coaxial Master/Subscriber Pair Version 0.9a Sep 2008 (Draft) Copyright © 2008, CTC Union Technologies, Inc. All rights reserved. All specifications are subject to change without prior notice.
  • Page 4 Should the Buyer purchase or use a CTC Union product for any such unintended or unauthorized application, the Buyer shall indemnify and hold CTC Union Technologies...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION..............................7 1.1 K ..............................7 EATURES 1.2 S ..............................7 PECIFICATIONS 1.3 A ..............................8 PPLICATIONS 2. VLAN (VIRTUAL LOCAL AREA NETWORK) ....................9 2.1 S ..............................10 PECIFICATION 2.2 F ............................10 RAME PECIFICATION 2.3 A ..............................11 PPLICATION 3.

  • Page 7: Introduction

    1. Introduction The EOC-20 is Multiplexer Unit for EoCNA (Ethernet over Coax Network Alliance) solution that efficiently extends 10/100 Ethernet circuits to over 900 meters(2,952feet) at 112Mbps using existing coaxial cable. The EOC-20 will allow Ethernet connectivity in existing facilities without pulling extra cable.

  • Page 8: Applications

    Network Management Diagnostic EoCNA function Secured/Isolated Communication between devices Provision/Denial of Service CPE profile download & SNMP read/write along with Web Manager setting DHCP snooping and DHCP Option 82 support NetBIOS blocking ARP support Public IP ACL Port QoS Rate limit function for EoCNA port or LAN Port Indicators “Power”...

  • Page 9: Vlan (Virtual Local Area Network)

    2. VLAN (Virtual Local Area Network) Virtual LAN (VLAN) is defined as a group of devices on one or more LANs that are configured so that they can communicate as if they were attached to different wire, when in fact they are located on the same LAN segment.

  • Page 10: Specification

    2.1 Specification The unit supports up to 3 active VLANs with shared VLAN learning bridge out of 4096 possible VLANs specified in IEEE 802.1Q. Each port always belongs to a default VLAN with its port VID (PVID) as an untagged member.

  • Page 11: Application

    2.3 Application TRUNK CATV 3. Getting to Know Your EOC Modem This section will introduction the hardware of the EOC modem. 3.1 Front Panel 3.1 Front Panel Status Flashing DC 5V power feeding Power Not powered Provision CPE configuration file Prov./Alm.

  • Page 12: Rear Panel

    3.2 Rear Panel 3.2 Rear Panel Port Name Type Functions Connect to the power adapter DC IN plug. Connects to Ethernet port on RJ-45 PC or STB LAN port RESET button to load RESET RESET factory default Connect to TV or DVB-T/C CATV F-Type Female Coax Received signal...

  • Page 13: Configuration Via Web Browser

    4.5 Step 5: Install the EOC Modem To avoid possible damage to EOC Modem, do not turn on the EOC Modem before Hardware Installation. Connect the power adapter to the port labeled DC-IN on the rear panel of the product. Connect the Ethernet cable.

  • Page 14: Status

    The default user name and password both are admin. For system security, it is suggested to change them after configuration. Note: After changing the User Name and Password, we strongly recommend you to remember them for the next time you login. 6.

  • Page 15: Eocna-Wan Setup

    7.1 EoCNA-WAN Setup EoCNA-WAN status At the EoCNA-WAN Web page setting, can finger out the Current EoCNA – WAN IP Address , exp. 10.123.6.135 EoCNA-WAN IP setting EOC Modem had four way can setting to connect to ISP(Operation and Maintain Using) DHCP, Static IP, PPPoE, PPTP.

  • Page 16: Lan Setup

    7.2 LAN Setup In the LAN section, follow these functions. LAN default Setting Default EOC Modem LAN IP is 192.168.8.254 and Subnet mask is 255.255.255.0 LAN QoS Setting If enabling LAN QoS, can set STB/LAN port Priority Flow Control, Incoming/Outgoing Rate Limit EoC Function Setting EoC Operation Mode: default is Manager Mode.

  • Page 17: Snmp Setup

    7.3 SNMP Setup SNMP setting is for MIB Browser manager, exp.get, set, trap etc. 7.4 Provisioning Settings Provision Setting function is design for EOC Modem profile delivery method. This is the easiest way let each CPE Modems automatic download profile setting from MSO that wants to design for “no configuration required”...

  • Page 18: Tools

    8. Tools In this section, the only function is “Ping Test”. CPE can execute ping testing to make sure circuit is alive. 9. System Settings System setting has the following pull down functions:...

  • Page 19: Ntp Settings

    9.1 NTP Settings: The Network Time Protocol (NTP) is a protocol for distributing the universal time (UTC) by means of synchronizing the clocks of EOC Modem systems over packet-switched, variable-latency data networks 9.2 Language Settings: The Web GUI interface language can be changed by the operator. Currently there are three languages available;...

  • Page 20: Backup /Restore

    9.4 Backup /Restore Backup EOC Modem configuration to a file. Restore from default configurations or backup configuration file. 9.5 System Log Setting Remote site Log Server Address and port. This service lets CPE upload the system log to a Log Server. 9.6 System Operation Some EOC Modem parameters must EOC Modem save and restart can be apply.

  • Page 21: Software Upgrade

    9.7 Software Upgrade EOC Modem provide three way to remote upgrade method. 9.8 Logout...

  • Page 22: Eoc Design For Coaxial

    10. EOC Design For Coaxial 10.1 Rate vs. Attenuation rule of thumb The expected rate between Master to Slave stations is determined by various elements:  T ransmission power  T otal attenuation between transmitter and receiver  N oise floor at the receiver ...

  • Page 23: Catv Transmission Amplifiers

    10.2. CATV Transmission Amplifiers Amplifiers often do not include EoCNA in their downstream band. In cases where this type of device is installed, it should be replaced with one that has a bypass in the EoCNA band. Bypass is done by connecting a low pass filter (LPF) with a cutoff frequency of 45MHz in parallel with the amplifier as shown in Figure 1 (a).

  • Page 24: Connecting An Eocna Device To The Coax Network

    10.3. Connecting an EoCNA device to the Coax network 10.3.1 Cable video signal If there is a cable video CATV signal in the network, both the TV and EoCNA devices should be connected to the TV connector of the wall outlet. In this case a simple installation should be used as shown in Figure 2.

  • Page 25: Isolator

    10.4.2 Isolator An Isolator is required at the entrance point to the apartment (the root of the coax distribution tree). The Isolator serves 2 purposes: To block the EoCNA signal from spreading outside the apartment to avoid security and privacy issues.

  • Page 26: Topologies

    10.5.2. Topologies The topology is assumed to be MxU access over a coax distribution topology in a building (see Figure 3). The MxU access refers to the coaxial distribution cables originating from the MxU wiring cabinet which may be located in the basement and spreading up the riser through the floors of the building to the apartments.

  • Page 27: Configuration Via Tftp Provisioning

    11. Configuration Via TFTP Provisioning EOC Modem supports plain text configuration file under TFTP service. # For MAC.profile sample. #======================Network Configurations – EOC WAN interface================== #WAN type - (0:Static IP 1:PPPoE 2:DHCP) # WAN DHCP IP example. #================================================= #WAN Static IP example. NET WAN IP_TYPE 0 NET WAN STATIC IP 10.123.6.135 NET WAN STATIC MASK 255.255.255.0...
  • Page 28 #========================AUTO PROVISION================================ AUTO_PROVISION ENABLE 1 AUTO_PROVISION USES_DHCP_BOOTP_PROFILE 0 AUTO_PROVISION SERVER_IP tftp://10.123.6.99/%mac%.Profile AUTO_PROVISION START_RUN 1 AUTO_PROVISION PERIODICALLY 1 AUTO_PROVISION PERIOD_TIME 10800 #=======================SNMP========================================== SNMP ENABLE 1 SNMP GET_COMMUNITY public SNMP SET_COMMUNITY private SNMP TRAP_COMMUNITY public SNMP TRAP_HOST 10.132.6.99 #===================Log Server============================== SYSLOG ENABLE 1 SYSLOG SERVER_ADDR 10.123.6.99 SYSLOG SERVER_PORT 514...
