CTC Union Technologies Co.,Ltd.
Far Eastern Vienna Technology Center
(Neihu Technology Park)
8F, No. 60 Zhouzi St., Neihu, Taipei 114,
Taiwan
T +886-2-26591021
F +886-2-26590237
E sales@ctcu.com
info@ctcu.com
marketing@ctcu.com
H www.ctcu.com
2011 CTC Union Technologies Co., LTD.
All trademarks are the property of their respective owners.
Technical information in this document is subject to
change without notice.
Advertisement
Table of Contents
Related Manuals for CTC Union FRM220-FOM01
Summary of Contents for CTC Union FRM220-FOM01
- Page 1 8F, No. 60 Zhouzi St., Neihu, Taipei 114, Taiwan T +886-2-26591021 F +886-2-26590237 E sales@ctcu.com info@ctcu.com marketing@ctcu.com H www.ctcu.com 2011 CTC Union Technologies Co., LTD. All trademarks are the property of their respective owners. Technical information in this document is subject to change without notice.
- Page 2 100M Ethernet trunk, constructed as a one slot wide 1-CH E1/T1 + 100M Ethernet Fiber Multiplexer card for FRM220 series. When FRM220-FOM01 card is placed in FRM220 FRM220-FOM01 and FRM220-FOM01-SFP rack with NMC, the management can view the multiplexer card's status, type, version, fiber link status and alarms.
- Page 3 CE (EMC&LVD), FCC, RoHS Management Features FRM220-FOM01 has no jumpers or DIP Switches, making it completely software configurable. When placed in a stand-alone chassis, this device supports a text based serial terminal with an easy to use menu system for...
- Page 4 Baud Rate: 38,400 Data bits: 8 Parity bits: none Stop bits: 1 Flow Control: none Figure 3. Panel LED indicators of FRM220-FOM01 Emulation: VT-100 Connect the serial cable directly to CH01M's DB9F. Run the terminal State Status emulation program. With power on, press [ESC] or [Enter] to display the...
- Page 5 <1> Device Status – under this menu will be the device service status. <2> Fiber – this menu provides access to the fiber optical related functions **************************************** including link status, port activation, loop back tests and viewing of SFP DD CTC UNION TECHNOLOGIES CO.,LTD FRM220-FOM01 Manager Ver:1.00 functions. **************************************** <3>...
- Page 6 From the main menu, select item number 3 to access the E1/T1 status From the main menu, select item number 4 to access the LAN status menu. menu. **************************************** CTC UNION TECHNOLOGIES CO.,LTD [Local ] Version:[1.000-1.000-0.000-1.200] [ FOM01-SFP ] [CH01M FRM220-FOM01 Manager Ver:1.00 **************************************** <<...
- Page 7 SDH alternative In a point-to-point application where only a single E1 or T1 plus full 100M Ethernet over a single fiber pair are required, FRM220-FOM01 is a cost effective alternative to expensive SDH or SONET equipment. - 10 - - 11 - w w w .
- Page 8 Upgrading About SFP Units FRM220-FOM01 card may be firmware upgraded when it is placed in FRM220 FRM220-FOM01-SFP accepts any SFP unit that complies with the MSA with NMC management card. The user may use a local console connection to standard and supports an OC3/STM-1 data rate, which in FOM01 is the NMC, a remote Telnet (IP) connection, or a Web based (HTTP) connection 155.52Mbps.
