  • Page 1 User Manual ETU01C Dual Port E1 Access Multiplexer with Sub E1 CTC Union Technologies Co., Ltd.
  • Page 3 1.0 Sept. 2005 User Manual for Dual Port E1 Access Multiplexer with Sub E1 Thank you for choosing our product. Please read this manual carefully before using the ETU01C. This manual supports the following models: ETU01C 100-240 VAC model ETU01C –48V DC model...

  • Page 5: Table Of Contents

    Table of Contents Chapter 1. Introduction 1.1 Introduction ....................7 1.2 Functional Description ................7 1.3 Typical System Applications..............8 1.4 E1 signal structure..................8 1.5 ETU01C Capabilities................10 1.6 TECHNICAL SPECIFICATIONS............12 Chapter 2. Installation 2.1 General.....................15 2.2 Site Preparation ..................15 2.3 Mechanical Assembly ................15 2.4 Electrical Installation................15...
  • Page 6 Table of Contents...

  • Page 7: Chapter 1. Introduction

    E1 recovered receive clock (main E1 link or sub E1 link), from the user data ports, or from the internal oscillator. The ETU01C provide IDLE CODE mode, you can set any time slot and insert the idle code with ‘00'-‘FF', and the default code is ‘7F'.

  • Page 8: Typical System Applications

    PABX Figure 1-1: Example; Typical Application In a typical application (Figure 1-1), the ETU01C is used to connect the synchronous data channels of two routers and the local and remote LANs over an E1 line. The fractional E1 data service is based on the assumption that the combined user data rate of all channel modules plus Sub-Link is equal to or is a fraction of the full available E1 bandwidth, in multiples of 64K.
  • Page 9 Chapter 1 Introduction E1 transmissions utilize two main types of framing: Frame Alignment Signal (FAS) and Multi-Frame Alignment Signal (MFAS). Framing is necessary in order for equipment receiving the E1 signal to be able to identify and extract the individual channels. PCM-30 (CAS) transmission systems use MFAS framing along with FAS framing.

  • Page 10: Etu01C Capabilities

    The ETU01C E1 link receive path always operates on the receive clock. The ETU01C recovers the receive clock from the received E1 link data signal. The source of the ETU01C E1 link transmit clock can be selected by the user.
  • Page 11 The ETU01C E1 link transmit clock is derived from the internal clock oscillator. This timing mode is necessary in point-to-point applications over leased line. In this case, one ETU01C must use the internal oscillator, and the others must operate from the recovered clock.

  • Page 12: Technical Specifications

    Chapter 1 Introduction 1.6 TECHNICAL SPECIFICATIONS Main E1 and sub E1 links -Unframed/Framed (sub link framed only) -FAS (PCM31) Framing -FAS+CAS (PCM30) -CRC4 ON/OFF Bit Rate 2.048 Mbps -AMI Line Code -HDB3 -Unbalanced 75 ohms Line Impedance -Balanced 120 ohms Relative Receive Level 0 to -43dB -Nominal 2.37V+/-...
  • Page 13 2 rows of 16 characters Pushbutton Switches -ESC -Left Arrow -Right Arrow -Enter LED indicators Figure1-2 ETU01C Front Panel 1. Power Dual Color LED GREEN: Power RED: Test 2. Error (Only active in BERT mode) RED: Pattern Error 3. Main E1 (include Signal loss, SYNC Loss)
  • Page 14 Chapter 1 Introduction 7. CH1-TD of Datacomm ON :DATA 1 FROM DTE OFF : DATA 0 FROM DTE flashing : DATA 0 and 1 FROM DTE 8. CH1-RD of Datacomm ON : DATA 1 FROM Main E1 OFF : DATA 0 FROM Main E1 flashing : DATA 0 and 1 FROM Main E1 9.

  • Page 15: Chapter 2 Installation

    2-4-2. Rear panel connectors The data channel interfaces are fixed on the rear panel of the ETU01C (Refer to Figure 2-1) and consist of DB25pin connectors for RS-530 and V.35. Two RJ-45 interfaces and two pairs of BNC Coax connectors for the main E1 and E1 sub-link.
  • Page 16 Chapter 2 Installation E1 Line side BNC coax connector Two BNC coax pair of connectors marked RX and TX, provide unbalanced 75 Ohm connections for the Main E1 and Sub E1 lines. RJ-45 INTERFACE Two RJ-45 connectors marked Sub E1 and Main E1, provide balanced 120 Ohm connections for the Main E1 and Sub E1 lines.
  • Page 17 Chapter 2 Installation J301 J203 J302 J201 J300 J202 J303 J200 Figure 2-2 Data port jumper settings...
  • Page 18 Chapter 2 Installation This page left blank intentionally.

  • Page 19: Chapter 3 Front Panel Operation

    3.2 CONTROLS AND INDICATORS All controls (push-button switches), LCD display and LED indicators are located on the ETU01C front panel. The momentary on pushbutton switches are used to activate menu selections and select parameter settings. Figure 3-1: ETU01C Front Panel Use the ‘LEFT' and ‘RIGHT' function keys to browse the menus and select...

  • Page 20: Menu Operation

    Menu or press ENTER to reach a sub menu. For normal transmissions, the unit must be in 'RUN' mode. >>>>>>>>>>>>>>>> When powered on, the ETU01C will work under the last saved setting. Press ESC to stop the running, and the LCD will display: < SYSTEM >...
  • Page 21 > PARAMETER Enable BERT, select channel and select pattern. < EXIT CONFIG > **************** Exit the configuration and run the ETU01C. 3.3.2 System Parameter Detail The following screens show the setup screens under the System Parameter Main Screen. SYSTEM PARAMETER...

  • Page 22: System Clock

    SAVE SET Press ENTER, the ETU01C will store all the parameters as current settings. The next time the ETU01C is powered on, all the parameters used will be those that were previously saved. NOTE: Remember to save the parameters if you want to commit the ETU01C with the current parameters.
  • Page 23 Chapter 3 Front Panel Operation For example, if the equipment connected to the Data Port 1 is set as DTE clock, the system clock of ETU01C must be set as External Clock from Data Port 1(External P1). 3.3.3 Main E1 Parameter Detail The following screens show the setup under the Main E1 Parameter.
  • Page 24 Press ENTER and the SUB E1 LINK sub-menu will be displayed. Sub E1 Link sets the LINE CODE, IMPEDANCE, LBO, TX JITTER, FRAME type IDLE CODE and CRC-4 mode for the Sub E1 of the ETU01C. < LINK CODE >...

  • Page 25: Data Port

    Chapter 3 Front Panel Operation Note: TS 00: Cannot be assigned in CCS or CAS mode of MAIN E1 LINK to anything but Framing. BERT cannot be assigned to TS 00. TS 16: Cannot be assigned in CAS mode to anything except Signalling. BERT cannot be assigned to this timeslot in CAS mode.
  • Page 26 Chapter 3 Front Panel Operation Press ENTER to select the Clock Polarity: Type1: Tx pos Rx neg Type2: Tx pos Rx pos Type3: Tx neg Rx pos Type4: Tx neg Rx neg Tx: Transmit clock Rx: Receive clock Pos: Data sync at the clock rising edge. Neg: Data sync at the clock falling edge.
  • Page 27 Chapter 3 Front Panel Operation 3.3.8 BERT Parameter Detail The following screens show the setup under the BERT Parameter. < BERT TEST > PARAMETER Press ENTER 〈 FUNCTION 〉 Use the arrow keys to browse the available options for BERT setting. By default, BERT is off.
  • Page 28 Chapter 3 Front Panel Operation 3.3.10 ETU01C LCD menu breakdown EXIT CONFIG RUN ON **************** >>>>>>>>>>>>>>> DEFAULT SAVE SET RESET SYSTEM SYSTEM INTERNAL PARAMETER EXTERNAL (P1) SYSTEM CLOCK EXTERNAL (P2) RECOVERY (M E1) RECOVERY (S E1) LINE CODE HDB3/AMI IMPEDANCE...
  • Page 29 Chapter 3 Front Panel Operation B (BERT CODE) DATA PORT DATA PORT1 CLOCK SELECT PARAMETER [V.35]/[RS530] DCE / DTE CLOCK POLARITY [ TX POS RX NEG/ TX POS RX POS/ TX NEG RX POS/ TX NEG RX NEG ] DATA PORT2 CLOCK SELECT [V.35]/[RS530] DCE / DTE...

  • Page 30: Chapter 4 Control Port Operation

    A notebook computer has become an invaluable tool of the Systems Engineer. Connection to the computer is very straight forward. The only other hardware required is a DB9-pin one-to-one, male to female cable. The ETU01C acts as a DCE to the PC's DTE communications port. A convenient application, provided with the Microsoft Windows®...

  • Page 31: Menu System Detail

    Chapter 4 Control Port Operation Note: When a terminal connection is made to the ETU01C, the front panel LCD will be locked out and display: CONTROL PORT * CONNECTED >>>>> 4.3 Menu System Detail The menu systems are displayed in the same order and with the same parameters as those in the LCD display.
  • Page 32 Chapter 4 Control Port Operation << Display System Status >> 1. System Clock 2. Main E1 Parameter 3. Sub E1 Parameter 4. Data Port1 Parameter 5. Data Port2 Parameter 6. Time Slot Mapping 7. LoopBack Test 8. BERT Test Enter 1-8 or Press "ESC" to previous menu. Enter 1 to Display System Clock Parameter <<...
  • Page 33 Chapter 4 Control Port Operation << Display System Status >> 1. System Clock 2. Main E1 Parameter 3. Sub E1 Parameter 4. Data Port1 Parameter 5. Data Port2 Parameter 6. Time Slot Mapping 7. LoopBack Test 8. BERT Test Enter 1-8 or Press "ESC" to previous menu. Enter 2 to Display Main E1 Parameter <<...
  • Page 34 Chapter 4 Control Port Operation Enter 3 to Display Sub E1 Parameter << Display Sub E1 Parameter >> Line Code : HDB3 Impedance : 120 ohm : SHORT TX Jitter : OFF RX Jitter : OFF Frame : UNFRAME CRC-4 : OFF Idle Code : 7FH Press "ESC"...
  • Page 35 Chapter 4 Control Port Operation Enter 6 to display the Time Slot Mapping << Display Time Slot Mapping >> SLOT : 00 01 02 03 04 05 06 07 TYPE : SLOT : 08 09 10 11 12 13 14 15 TYPE : SLOT : 16 17 18 19 20 21 22 23 TYPE :...
  • Page 36 Press "ESC" to previous menu. Enter ESC to return to the Display System Status menu. Then press ESC again to go to the very top menu display. ******************************************** **** CTC UNION TECHNOLOGIES CO.,LTD **** **** ETU-01B/C TERMINAL MODE **** **** SETUP MENU Ver. 1.04...
  • Page 37 Chapter 4 Control Port Operation << Define System Parameter >> 1. Save Set 2. Reset System 3. System Clock 4. Main E1 Parameter 5. Sub E1 Parameter 6. Data Port1 Parameter 7. Data Port2 Parameter 8. Time Slot Mapping Enter 1-8 or Press "ESC" to previous menu. The first selection of system parameters is the Save Set, and the second selection is Reset System.
  • Page 38 External Clock from the Data Port that is supplying the external clock. For example, the equipment connected with the Data Port 1 is set as DTE clock, the system clock of ETU01C must be set as External Clock from Data Port 1 (External P1).
  • Page 39 Chapter 4 Control Port Operation Under the display, press 1-8 to define each parameter for the Main E1. For example, to change the Main E1 Idle Code, press 8: << Define Main E1 Idle Code >> Idle Code : 7FH Press "SPACE"...
  • Page 40 Chapter 4 Control Port Operation Press 6 to Define Data Port 1 Parameter << Define Data Port1 Parameter >> TYPE : V.35 Clock : DCE Clock Polarity : TX Positive ; RX Negative 1. Clock 2. Clock Polarity Enter 1-2 or press "ESC" to previous menu. To change the Data Port1 Clock press 1 , to change the Clock Edge press 2.
  • Page 41 Press Enter to confirm. The screen will display the message "Save Set is OK!" to confirm the settings were saved successfully. Press ESC again to go to the very top menu display. ******************************************** **** CTC UNION TECHNOLOGIES CO.,LTD **** **** ETU-01B/C TERMINAL MODE **** **** SETUP MENU Ver.
  • Page 42 Chapter 4 Control Port Operation Now we will look at setting up the Test Function Parameter. To do this, enter 3. << Define Test Mode Function >> 1. LoopBack Test 2. BERT Test Enter 1-2 or press "ESC" to previous menu. To Define LoopBack Test Function, Press 1.
  • Page 43 Chapter 4 Control Port Operation To enable or disable the Loopback function, Press 1. << LoopBack Function >> Function : OFF 1. ON 2. OFF Enter 1-2 or press "ESC" to previous menu. The current setting for Loop Back is OFF. To turn on, press 1. To exit without changing, press ESC.
  • Page 44 Chapter 4 Control Port Operation << Main E1 LoopBack >> Main E1 : OFF 1. OFF 2. Local Analog 3. Local Digital 4. Local Payload 5. Remote Analog 6. Remote Payload Enter 1-6 or Press "ESC" to previous menu. Press 2-6 to initiate a loop back of the main E1 link, press 1 to stop loop back, or press ESC to return to the previous menu without any change.
  • Page 45 Chapter 4 Control Port Operation << Data Port1 LoopBack >> Data Port : OFF 1. OFF 2. Local Analog 3. Local Digital 4. Remote Loop Enter 1-4 or Press "ESC" to previous menu. Note: When Data Port Local Analog Loop Back is initiated, the DTE connected should be providing its own Clock.
  • Page 46 2. Define System Parameter. 3. Test Function Parameter. 4. Password 5. Reset Data to Default. 6. EXIT Enter 1-6 to select function. Press "SPACE" to ENTER / EXIT CONFIG ! The following is an example of Password setting for the ETU01C. Press 4.
  • Page 47 Chapter 4 Control Port Operation << Password >> 1. Set Password 2. Clear Password Enter 1-2 or press "ESC" to previous menu. Enter 1 to set the Password << Password >> Enter Password (4 Number) : Press "ENTER" to confirm, "ESC" to previous menu. Press "SPACE"...
  • Page 48 Chapter 4 Control Port Operation << Password >> 1. Set Password 2. Clear Password Enter 1-2 or press "ESC" to previous menu. To clear the password, press 2. << Clear Password >> Enter original password : Press "ENTER" to confirm, "ESC" to previous menu. Press "SPACE"...
  • Page 49 Chapter 4 Control Port Operation Press ESC back to go back to the main menu. ******************************************** **** CTC UNION TECHNOLOGIES CO.,LTD **** **** ETU-01B/C TERMINAL MODE **** **** SETUP MENU Ver. 1.04 **** ******************************************** 1. Display System Status. 2. Define System Parameter.
  • Page 50 To exit the terminal mode, press 6. The terminal connection will be dropped and the front panel LCD will return to its normal 'RUN' condition. ****IMPORTANT**** The unit will not transmit normally unless it is in RUN mode. This completes the detailed examples of terminal mode operation for the ETU01C.

  • Page 51: Chapter 5 Diagnostic Tests

    Chapter 5 Diagnostic Tests 5.1 Test Loops –Main E1 link loop back - local digital loop back Local ETU01C - local analog loop back Local ETU01C...
  • Page 52 Chapter 5 Diagnostic Tests - local payload loop back Local ETU01C - remote analog loop back Remote ETU01C Local ETU01C - remote payload loop back Remote ETU01C Local ETU01C...
  • Page 53 Chapter 5 Diagnostic Tests –Sub E1 link loop back - local digital loop back Local ETU01C - local analog loop back Local ETU01C - local payload loop back Local ETU01C...
  • Page 54 Chapter 5 Diagnostic Tests remote analog loop back Local ETU01C Remote ETU01C - remote payload loop back Local ETU01C Remote ETU01C...
  • Page 55 Chapter 5 Diagnostic Tests –Data Port loop back -Data Port1 local analog loop back Local ETU01C - Data Port1 local digital loop back Local ETU01C - Data Port1 remote loop back Local ETU01C Remote ETU01C...
  • Page 56 Chapter 5 Diagnostic Tests - Data Port2 local analog loop back Local ETU01C - Data Port2 local digital loop back Local ETU01C - Data Port2 remote loop back Local ETU01C Remote ETU01C Note: Each of the remote loop back must fit the E1 in CCS or CAS.
  • Page 57 Chapter 5 Diagnostic Tests BERT TEST: -MAIN –> MAIN: Local ETU01C -MAIN –> SUB: Local ETU01C -SUB –> MAIN: Local ETU01C...
  • Page 58 Chapter 5 Diagnostic Tests -SUB –> SUB: Local ETU01C...

  • Page 59: Appendix A

    Appendix A Appendix A RS-530 Cables, 25 conductor round, 1 to 1, 100cm. Male DB25 Male(or Female) DB25 <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════>...
  • Page 60 Appendix A V.35 Cables, multi-conductor round, 100cm. Male DB25 Male(or Female) MB34 <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> NOTE: TWISTED PAIRS; Y,AA...
  • Page 61 Appendix A RS-449 Cables, multi-conductor round, 100cm. Male DB25 Male(or Female) DB37 <═══════════> <═══════════> 19,20,37 (the following are all twisted pairs) <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════>...
  • Page 62 Appendix A X.21 Cables, multi-conductor round, 100cm. Female DB25 Male(or Female) DB15 <═══════════> <═══════════> (the following are all twisted pairs) <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> <═══════════> 15,17 <═══════════> 9,12 <═══════════>...

  • Page 63: Technical Inquiry Form

    TECHNICAL INQUIRY FORM CTC Union Technologies Inc Fax:+886-2-2799-1355 Tel:+886-2-2659-1021 E-mail:support@ctcu.com Attn : Technical Support Division Taipei Taiwan From Company: Name: Tel: ( Fax:( MODEL: ETU01C ACTIVITY: Check every setting including physical interface and system setting SYS CONFIGURATION: Question:...
  • Page 64 V.35 Data port 1 RS530 V.35 Parameters User setting; check all configurations Applications Point-to-point ETU01C to E1 Network device System Clock INTERNAL RECOVERY (M E1) / RECOVERY (S E1) EXTERNAL (P1) / EXTERNAL (P2) Main E1 link parameters Line Code...
  • Page 66 E1 Series CTC Union Technologies Co., Ltd. Far Eastern Vienna Technologies Center (Neihu Technology Park) 8F, No. 60, Zhouzi St., Neihu, Taipei, Taiwan Phone:+886-2-2659-1021 Fax:+886-2-2799-1355 E-mail: info@ctcu.com http://www.ctcu.com...
