FOR GM
'07 and up Cadillac, Chevrolet, GMC vehicles
1 |
P a g e
th
100 NW 11
Street, Boca Raton, FL 33432
Street, Boca Raton, FL 33432 TEL 561-955-9770 FAX 561-955-9760
www.nav-tv.com
Chevrolet, GMC vehicles (29-Bit GMLAN)
Barracuda Features
Barracuda Features:
• Control in Motion
Control in Motion:
XM Category Scrolling
ONSTAR Phone Keypad
DVD Menu control
Navigation Programming
• Video in Motion
Video in Motion
• FLIR control
FLIR control
• Front camera input
Front camera input*
• Rear camera input/control
Rear camera input/control*
• Programmable inputs/outputs
Programmable inputs/outputs
info@nav-tv.com
Bit GMLAN)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Nav TV Barracuda
Summary of Contents for Nav TV Barracuda
- Page 1 Street, Boca Raton, FL 33432 TEL 561-955-9770 FAX 561-955-9760 www.nav-tv.com info@nav-tv.com FOR GM ‘07 and up Cadillac, Chevrolet, GMC vehicles Chevrolet, GMC vehicles (29-Bit GMLAN) Bit GMLAN) Barracuda Features Barracuda Features: • Control in Motion Control in Motion: XM Category Scrolling ONSTAR Phone Keypad DVD Menu control Navigation Programming •...
- Page 2 Attention: All Functions of the Barracuda are controlled through the vehicle’s power mirror direction pad. The Barracuda controls are only available when the left and right mirror buttons are NOT selected (LEDs OFF). Example: if the Left Mirror button is illuminated, press the illuminated Left Mirror button again to turn the LED off.
- Page 3 Barracuda Settings: The Barracuda Settings Menu supports GM’s 4 Line, 2 Line, and 1 Line instrument cluster displays. To access the Barracuda Settings Menu, press and hold the left arrow mirror button for 2 seconds. The following instructions will appear on the instrument cluster display.
- Page 4 5. and 6. PROG. OUTPUT A and B: Two +12V DC outputs controlled by the Up and Down mirror buttons, or automatically. NOTE 5: The Barracuda menu for PROG OUTPUT A and B are identical. They operate independently of each other, but can share the same control button (Up/Down).
- Page 5 10. FLIR COLORS: The Barracuda module allows you to modify the colors the FLIR camera outputs to the radio LCD. White Hot: Black and white image, with White indicating hot. Black Hot: Black and white image with Black indicating hot.
- Page 6 5. Plug the factory connectors into the supplied T-harness (not all connectors will be plugged into the supplied T-harness). 6. Once all Barracuda connections have been made, reconnect the radio. Verify the operation of the radio and all enabled features.
- Page 7 Aftermarket Back-up Camera connections Factory camera with FLIR connection Front Camera (CCD) connection P a g e...
- Page 8 2. Strip the blue wire of the plug side. 3. Connect the stripped Blue wire to Pin 11 of the Barracuda Harness (Blue). Be sure to insulate the unused wire so it doesn’t short out. Note 11: If the vehicle has a factory back-up camera, it is required to make the connections to the Rear Camera module, otherwise, forced camera will not work.
