Eco-Choice WS Series Wood Burner Installation Instructions
Eco-Choice WS Series Wood Burner Installation Instructions
Model:
WS18-AU
IMPORTANT: Read all instructions carefully before starting installation. Failure to follow these
instructions may result in a fi re hazard and will void the warranty.
Fig. 3,4,5,6, 7 and Table 1,2,3,4 relate to installations with tested fl ue systems; as per AS/NZS
•
2918:2001 - Appendix F, with a ceiling angle between 0° - 30° inclusive.
For installations with a ceiling angle greater than 30°, refer to Fig. 7 & 8 and AS/NZS 2918:2001
•
4.6.3(b)
Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to
•
ordering the ceiling plate.
Heatilator Eco Choice series wood burner's are tested and approved to the N.Z. National Environ-
•
mental Standards;
Particulate Emissions = 1.3 g/kg Space Heating Effi ciency = 85%
Particulate Emissions = 1.2 g/kg Space Heating Effi ciency = 82%
Page 1
INSTALLATIONS TO COMPLY WITH AS/NZS2918:2001
AND WILL REQUIRE A BUILDING CONSENT
WS18-AU Eco-Choice Hardwood Certifi ed
WS22-AU Eco-Choice Hardwood Certifi ed
7056-153A
Model:
WS22-AU
February 7, 2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heatilator WS18-AU
Summary of Contents for Heatilator WS18-AU
- Page 1 Ceiling Plate may vary in size depending on ceiling angle. Please specify ceiling pitch prior to • ordering the ceiling plate. Heatilator Eco Choice series wood burner’s are tested and approved to the N.Z. National Environ- • mental Standards; WS18-AU Eco-Choice Hardwood Certifi ed Particulate Emissions = 1.3 g/kg Space Heating Effi...
- Page 2 Hearth & Home Technologies welcomes you to our tradi- our stoves, inserts and fi replaces. And yet we are old-fash- tion of excellence! In choosing a Heatilator appliance, you ioned when it comes to craftsmanship. Each unit is meticu- have our assurance of commitment to quality, durability, and lously fabricated and surfaces are hand-fi...
- Page 3 WS Series Wood Burner Heatilator WS18 Wood Burner Dimensions 19-1/16 in. (484 mm) 25 in. (635mm) 9-5/16 in. 12-1/2 in. (236 mm) (317mm) 14-13/16 in. (376 mm) 13-13/16 in. 9-9/16 in. (350 mm) (242 mm) 29 in. (736 mm) 19-11/16 in. (500 mm) 21-11/16 in.
-
Page 4: Floor Protector
WS Series Wood Burner FLOOR PROTECTOR Heatilator WS18 does not require a insulating Floor Protector, as they are tested and comply with the minimum Floor Protector requirements of AS/NZS 2918:2001. Note: ▪ The minimum Floor Protector sizes are specifi ed in the clearance chart, see Table 1 & 2. -
Page 5: Firebox Installation
WS Series Wood Burner CORNER POSITIONING (45°) Fig. 4 FLOOR PROTECTOR Table 2 DESCRIPTION With Double Pioneer Double Flue Mounted Shield Universal Flue Shield Shall be Fitted Fitted Min. clearance from fi rebox corner to corner walls Min. distance from center of spigot to corner walls Min. - Page 6 WS Series Wood Burner Heatilator WS22 Wood Burner Dimensions 19-1/16 in. 26 in. (660mm) (484mm) 13 in. 9-13/16 in. (330mm) (249mm) 14-13/16 in. 13-13/16 in. (376mm) (351mm) 9-9/16 in. (243mm) 34 in. (864mm) 19-5/8 in. (499mm) 21-11/16 in. (551mm) Figure 29.1 - Front View Figure 29.2 -Top View...
- Page 7 WS Series Wood Burner FLOOR PROTECTOR Heatilator WS22 does not require a insulating Floor Protector, as they are tested and comply with the minimum Floor Protector requirements of AS/NZS 2918:2001. Note: ▪ The minimum Floor Protector sizes are specifi ed in the clearance chart, see Table 3 & 4.
- Page 8 WS Series Wood Burner CORNER POSITIONING (45°) CORNER POSITIONING (45°) Fig. 6 FLOOR PROTECTOR Table 4 DESCRIPTION With Double Pioneer Double Flue Mounted Shield Universal Flue Shield Shall be Fitted Fitted Min. clearance from fi rebox corner to corner walls Min.
-
Page 9: General Instructions For Flue System
WS Series Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM ▪ Flue pipe installed crimp/narrow end down ▪ Outer casings installed crimped/narrow end up. (Critical when exposed above the roof) ▪ Inner casings - direction not critical ▪ Flue pipes - seal all joints including fi rebox spigot. - fi... - Page 10 WS Series Wood Burner FLUE PENETRATION Tested flue systems, as per AS/NZS 2918:2001 Fig. 7 Fig. 5 ADD Cowl Casing Cover oversized casing cover minimum 25mm gap is necessary between flue pipe casing & Spider Bracket combustible material Non combustible material Hebel block or 12mm Promina board or similar under the flashing...
- Page 11 WS Series Wood Burner Un-tested flue systems, as per AS/NZS 2918:2001, 4.6.3(b) ADD Cowl Fig. 8 Fig. 6 AS/NZS2918:2001 Casing Cover Un-tested flue with sloped ceiling Spider Bracket penetration greater than 30° from horizontal A = 25mm Approved Flashing 4.6.3(b) Fig 4.6 = downward distance of casing and 3 x ø...
-
Page 12: Minimum Height Of Flue System Exit
WS Series Wood Burner GENERAL INSTRUCTIONS FOR FLUE SYSTEM 1. Unpack the Flue Mounted Shield, detach the three brackets and familiarize yourself with the illus- trations. 2. Using a sharp knife or razor blade, carefully cut through the plastic fi lm on the “inside face” where it meets the outer shield (refer sketch). - Page 13 WS Series Wood Burner AS/NZS 2918:2001 GENERAL NOTES WARNINGS: WARNING: THE APPLIANCE AND FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS 2918 AND THE APPROPRIATE REQUIREMENTS OF THE RELEVANT BUILDING CODE OR CODES. WARNING: APPLIANCES INSTALLED IN ACCORDANCE WITH THIS STANDARD SHALL COMPLY WITH THE REQUIREMENTS OF AS/NZS 4013 WHERE REQUIRED BY THE REGULA- TORY AUTHORITY, I.E.
-
Page 14: Service & Maintenance Log
WS Series Wood Burner SERVICE & MAINTENANCE LOG Date of Service Performed By Description of Service Page 14 7056-153A February 7, 2014... - Page 15 WS Series Wood Burner SERVICE & MAINTENANCE LOG Date of Service Performed By Description of Service Page 15 February 7, 2014 7056-153A...
- Page 16 Please contact your Heatilator dealer with any questions or concerns. For the number of your nearest Heatilator dealer log onto www.heatilatorecochoice.com CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with • Important operating and • •...
