Digicast Media Router S2 Receiver CMR-5995 (MR-S2-ASI)
Configuring and Controlling the Digicast CMR‑ 5975 Media Router with SNMP
MIB-II
Type Sub Type
Number
icmpInAddrMaskReps
icmpOutMsgs
icmpOutErrors
icmpOutDestUnreachs
icmpOutTimeExcds
icmpOutParmProbs
icmpOutSrcQuenchs
icmpOutRedirects
icmpOutEchos
icmpOutEchoReps
icmpOutTimestamps
icmpOutTimestampReps 1.3.6.1.2.1.5.24 ICMP Out TimeStamp Reps
icmpOutAddrMasks
icmpOutAddrMaskReps
mib-II 6 tcp
tcpRtoAlgorithm
tcpRtoMin
tcpRtoMax
tcpMaxConn
tcpActiveOpens
tcpPassiveOpens
tcpAttemptFails
tcpEstabResets
tcpCurrEstab
tcpInSegs
tcpOutSegs
tcpRetransSegs
tcpConnTable
tcpInErrs
tcpOutRsts
mib-II 7 udp
udpInDatagrams
udpNoPorts
udpInErrors
udpOutDatagrams
OID Description
1.3.6.1.2.1.5.13 ICMP In Address Mask Reps
1.3.6.1.2.1.5.14 ICMP Out Messages
1.3.6.1.2.1.5.15 ICMP Out Errors
1.3.6.1.2.1.5.16 ICMP Out Dest Unreachable
1.3.6.1.2.1.5.17 ICMP Out Time Exceeds
1.3.6.1.2.1.5.18 ICMP Out Parm Problems
1.3.6.1.2.1.5.19 ICMP Out Source Quench
1.3.6.1.2.1.5.20 ICMP Out Redirects
1.3.6.1.2.1.5.21 ICMP Out Echoes
1.3.6.1.2.1.5.22 ICMP out Echo Reps
1.3.6.1.2.1.5.23 ICMP Out Time Stamps
1.3.6.1.2.1.5.25 ICMP Out Addr Masks
1.3.6.1.2.1.5.26 ICMP Out Address Mask Rep
1.3.6.1.2.1.6 Tracks TCP (Transmission Control
Protocol) aspects
1.3.6.1.2.1.6.1 TCP Retrans Algorithm
1.3.6.1.2.1.6.2 TCP Retrans Min
1.3.6.1.2.1.6.3 TCP Retrans Max
1.3.6.1.2.1.6.4 TCP Max Conn
1.3.6.1.2.1.6.5 TCP Active Conn Open
1.3.6.1.2.1.6.6 TCP Passive Conn Open
1.3.6.1.2.1.6.7 TCP Attempts Failed
1.3.6.1.2.1.6.8 TCP Established Resets
1.3.6.1.2.1.6.9 TCP Current Connections
1.3.6.1.2.1.6.10 TCP In Segments
1.3.6.1.2.1.6.11 TCP Out Segments
1.3.6.1.2.1.6.12 TCP Retransmitted Segments
1.3.6.1.2.1.6.13 TCP Connection Table
1.3.6.1.2.1.6.14 TCP In Errors
1.3.6.1.2.1.6.15 TCP Out Resets
1.3.6.1.2.1.7 Tracks UDP (User Diagram
Protocol) aspects
1.3.6.1.2.1.7.1 UDP In Datagrams Received
1.3.6.1.2.1.7.2 UDP No Ports Available
1.3.6.1.2.1.7.3 UDP In Errors
1.3.6.1.2.1.7.4 UDP Out Datagrams Sent
E–7
Revision 1
MN-CMR5995-IOM
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
