04
Technical Specifications
Supply Voltage
Dimensions
Ventilation Capacity
Weight
Dimensions (mm)
Ø125
380
440
Performance Curve
AFTER INSTALLING THIS UNIT PLEASE PASS ONTO END USER
DO NOT THROW AWAY
230V / 50-60Hz / 70W Max / 0.5 A Max
135 l/s @ 100pa. Max 151 l/s (545m
30
H 387mm x W 440mm x D 198mm
Boxed 5.8kg | Unit 4.3kg
/h)
3
04
