INSTALLER AND OWNER GUIDE
Brunswick
Model 910
GAS STOVE
Fitted with a Ceramic Coal fuel effect.
We trust that this guide gives
sufficient details to enable this
appliance to be installed, operated
and maintained satisfactorily.
However, if further information is
required, our
Valor Fires Technical Helpline will
be pleased to help.
Telephone 0844 879 35 88 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 01 842 8222.
INSTALLER: Please leave this guide with the owner
©
GDC Group Ltd. 2014
08/52706/0

Advertisement

Table of Contents
loading

Related Manuals for Valor 910 Brunswick

Summary of Contents for Valor 910 Brunswick

  • Page 1 However, if further information is required, our Valor Fires Technical Helpline will be pleased to help. Telephone 0844 879 35 88 (National call rates apply in the United Kingdom).
  • Page 2 THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20). WHEN CONVERTED USING CONVERSION KIT NO. 0591011 THIS APPLIANCE IS FOR USE WITH PROPANE GAS (G31). THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE). ©...
  • Page 3 INSTALLER GUIDE INSTALLER GUIDE FOR OWNER GUIDE SEE PAGES 19 TO 30 © GDC Group Ltd. 2014 Page 3...

  • Page 4: Table Of Contents

    INSTALLER GUIDE LIST OF CONTENTS Section Heading Page INSTALLER GUIDE 3 - 18 OWNER GUIDE 19 - 30 1. SAFETY 2. APPLIANCE DATA AND EFFICIENCY General information. Efficiency. 3. UNPACKING 4. STOVE SET UP Legs and lower casting cover Flue collar, diverter box, flue spigot and flue restrictor plate. Down draught deflector.

  • Page 5: Installer Guide

    Installer Valor stoves are efficient appliances giving off convected, conducted and radiated heat. All the surfaces of the stove - except the controls - are working surfaces and become hot in use. They must not be touched or have any combustible objects or materials placed on or near them.

  • Page 6: Appliance Data And Efficiency

    INSTALLER GUIDE Avoid upper body/top heavy bending. Do not lean forward or sideways whilst handling the stove. Always grip with the palm of the hand. Do not use the tips of fingers for support. Always keep the stove as close to the body as possible. This will minimise the cantilever action.

  • Page 7: Unpacking

    INSTALLER GUIDE The gross calorific value of the fuel has been used for this efficiency calculation. The test data from which it has been calculated has been certified by BSI. The efficiency value may be used in the UK Government's Standard Assessment Procedure (SAP) for energy rating of dwellings.

  • Page 8: Stove Set Up

    INSTALLER GUIDE NOTE: The door is secured with a locking bolt and Hex nut. To open the door use a 3mm Allen key to loosen the hex nut on the side of the door, being carefull not to remove it completely. Ref to Figure A below. Then select a suitably sized spanner and turn counter clockwise by approximately a quarter turn on the handle to open.

  • Page 9: Down Draught Deflector

    INSTALLER GUIDE Figure 2. Down draught deflector. The down draught deflector is secured in place using the upper front bolt and nut that secure the cast collar to the outside of the cast body. Unscrew and remove the nut and washer from inside the top of the casting body. Position the down draught deflector as in figure 3.

  • Page 10: Burner Module And Rear Burner Support Fitment

    INSTALLER GUIDE Thermal switch. The Thermal Switch should be fitted to the inside of the Diverter Box as in figure 4. Secure using the nut and bolt supplied. Never modify the fixing bracket and always ensure that the switch is fitted correctly. NEVER USE THE STOVE IF THE THERMAL SAFETY SWITCH HAS BEEN REMOVED OR IF IT IS DAMAGED IN ANY WAY.

  • Page 11: General Installation Requirements

    INSTALLER GUIDE 5. GENERAL INSTALLATION REQUIREMENTS Regulations, Standards and Law. The installation must be in accordance with these instructions. For the user’s protection, in the United Kingdom it is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety (Installation and Use) Regulations.

  • Page 12: Clearances

    INSTALLER GUIDE Clearances. Clearances from combustible and non-combustible materials must be at least those shown in figure 6. IMPORTANT: Reducing the clearance distance at the rear of the stove (especially with non-combustible surfaces) can result in the stove switching off. This occurs when the thermal switch operates due to insufficient cool air.

  • Page 13: Ventilation

    INSTALLER GUIDE ensure optimum performance we recommend 3.66 metres (12ft) or higher. The flue must be free of obstruction and any dampers must be fixed in a permanently open position. Ensure that the chimney is not closed and that it has been swept prior to the stove being installed.

  • Page 14: Fitting The Ceramic Fuel Effect

    INSTALLER GUIDE Fitting the ceramic fuel effect. The installer and owner guide for the ceramic fuel effect is supplied with the ceramic fuel effect. It is important that the installer guide for the ceramic fuel effect be placed inside or attached to this guide and handed to the customer following completion of the ‘Final review’...

  • Page 15: Inlet Pressure Check

    INSTALLER GUIDE Depress the control knob slightly and turn back (clockwise) to turn OFF. This will extinguish the pilot. Inlet pressure check. The appliance is pre-set to give the correct heat input at the inlet pressure shown in section 2 of this manual. No adjustment is necessary.

  • Page 16: Final Review And Servicing

    This monitoring system must not be adjusted, bypassed or put out of operation. This monitoring system, or any of its parts, must only be exchanged using Valor Fires authorised parts. 7. FINAL REVIEW AND SERVICING Final Review. Hand the literature pack with this guide to the customer.

  • Page 17: Servicing

    INSTALLER GUIDE any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after approximately twelve hours use. Inform the customer that the Serial number for the appliance is located on the metal plate attached to the burner at the bottom of the appliance underneath the burner module.

  • Page 18: Checking The Aeration Setting Of The Burner

    INSTALLER GUIDE Checking the aeration setting of the burner. (For LPG models refer to the conversion guide). The aeration shutter is factory set. It is important to ensure that the aeration setting is correct. Check the aeration shutter setting (See figure 10). To adjust the aeration setting, loosen the two aeration shutter screws, slide the aeration shutter to the position shown in figure 10 and tighten the fixing screws.

  • Page 19: Owner Guide

    OWNER GUIDE OWNER GUIDE © GDC Group Ltd. 2014 Page 19...
  • Page 20 OWNER GUIDE LIST OF CONTENTS Heading Page SAFETY OPERATING YOUR STOVE The Flame Sensing & Flue Blockage Safety System. Lighting the burner. Operating the burner. GAS CONSUMPTION CLEANING YOUR STOVE Cast Iron Surfaces. Opening the Door. The Glass Window. FITTING THE CERAMIC FUEL EFFECT MAINTENANCE AND SERVICING 26 - 30 Regular maintenance.

  • Page 21: Safety

    OWNER GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE. EXTINGUISH ALL NAKED FLAMES. DON’T TURN ELECTRICAL SWITCHES ON OR OFF. TURN OFF THE GAS SUPPLY AT THE METER OR TANK AS APPROPRIATE. OPEN DOORS AND WINDOWS TO GET RID OF THE GAS. IMMEDIATELY CALL THE GAS EMERGENCY SERVICE FROM A NEIGHBOURS PHONE - SEE YOUR LOCAL TELEPHONE DIRECTORY.
  • Page 22 OWNER GUIDE Do always use a fireguard complying with BS 8423 for the protection of young children, the elderly, the infirm or pet animals. The cast iron top, front, rear and sides of this stove are considered to be working surfaces and so will become very hot when in use.

  • Page 23: Operating Your Stove

    OWNER GUIDE OPERATING YOUR STOVE PLEASE NOTE When operating your stove for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after approximately twelve hours use.

  • Page 24: Operating The Burner

    OWNER GUIDE Operating the burner. When the pilot burner is operating properly, gradually turn the control knob anti- clockwise to 'HIGH' position. (Depress the knob slightly to get past the pilot ignition position). The main burner should now light. Depress the control knob slightly to release from the 'HIGH' position and turn back (clockwise) to 'LOW'.

  • Page 25: Cleaning Your Stove

    OWNER GUIDE CLEANING YOUR STOVE Turn the stove off and allow it to cool completely before attempting any cleaning. Note that it will retain heat for some time after it has been turned off. Cast Iron Surfaces. Regular dusting with a dry lint free cloth is all that should normally be necessary. If the paint needs retouching, allow the stove to cool completely.

  • Page 26: Maintenance And Servicing

    OWNER GUIDE MAINTENANCE AND SERVICING Regular maintenance. In order to achieve and maintain high levels of personal safety and performance efficiency, it is essential that the flue is kept clear of any form of obstruction. In the United Kingdom it is the law that a landlord must have any gas appliance, flue and pipework which is situated in a tenant’s premises checked for safety at least every twelve months by a competent person (In the UK a GAS SAFE REGISTER engineer, Outside of the UK a CORGI or GAS SAFE REGISTER engineer).
  • Page 27 OWNER GUIDE WARRANTY AND SERVICE Standard Warranty Terms & Conditions The warranty is for 12 months subject to contract. In the United Kingdom servicing can be carried out either by a GDC service engineer or a GAS SAFE REGISTER engineer. Outside of the United Kingdom servicing can be carried out either by a CORGI or GAS SAFE REGISTER engineer.
  • Page 28 OWNER GUIDE When calling the GDC Helpline, it would be helpful if you could have the following information to hand:- Stove serial number (The serial number can be found on the Burner unit serial number label).* Date of installation.* Your installer name and address details.* Stove make/name and burner unit model number.* Proof of purchase (if you do not have the fire serial number).
  • Page 29 OWNER GUIDE To be completed by installer: Installer Details (Block Capitals) Installer Name Gas Safe Register or Corgi Registration Number. Company Name. Company Address Company Telephone number Company Fax number © GDC Group Ltd. 2014 Page 29...
  • Page 30 Serial number (Can be found on the Burner unit Serial number label) A LABEL CONTAINING THE SERIAL NUMBER MAY HAVE BEEN PLACED INSIDE THE BURNER BOX. IF SO PLEASE STICK INTO THIS BOX FOR FUTURE REFERENCE. Brand (Please tick) Valor Other......Date of Installation © GDC Group Ltd. 2014 Page 30...
