Power Wave
Increase Productivity, Quality and Flexibility
The Power Wave AC/DC 1000 is the first power source to introduce Waveform Control
Technology
™
to submerged arc welding. Variable frequency and amplitude AC, DC
positive or DC negative output allows the user to control the deposition rate and penetra-
tion. An operator can increase weld speeds, yield higher quality welds and improve effi-
ciencies in a single or multi-arc environment. The phase angle and frequency of different
machines can also be synchronized to balance the interactions between multiple arcs and
minimize arc blow. Depending on the output, a welding arc may be driven by a single
machine or multiple machines in parallel for applications that require more than 1000
amps of continuous operation.
Processes
Submerged Arc
Advantage Lincoln
• Eliminate downtime with easy polarity switching –– no hardware
reconfiguration required.
• Stable and independent arc controls for multiple arc applications.
• Improved efficiency and reliability with cooler operation through
patented Coaxial Transformer Technology™.
• 95% power factor correction enables connection of more
machines on the same plant infrastructure for lower installation
costs compared to other machines.
• Remote process monitoring and control through ArcLink,
Ethernet, and DeviceNet communication.
• Consistent operation over ± 10% input voltage variation through
built-in line voltage compensation and reliable input voltage
connection.
• Manufactured under a quality system certified to ISO 9001
requirements and ISO 14001 environmental standards.
• Three-year warranty on parts and labor.
Product
Product
Name
Number
Power Wave AC/DC 1000
K2344-1
Power Wave AC/DC 1000 (1)
K2344-2 (1) 380/400/460/500/575/3/50/60
(1) External Filter is required to meet CE conducted emission requirements. The K2444-1 must be used with the K2344-2.
®
AC/DC 1000 ™
TECHNICAL SPECIFICATIONS
Rated Output
Input
Current/Voltage/
Voltage
Duty Cycle
460/500/575/3/60
1000/44/100%
1000/44/100%
AUTOMATED SOLUTIONS
Description
CC
AC
Output
CV
DC
Recommended General Options
System Interface, Interface Control Cable (22-pin), ArcLink Cable (5-pin),
Feeder Control Cable (14-pin), TC-3 Self-Propelled Travel Carriage,
(1)
CE Filter
Recommended Wire Feeders
Power Feed 10A Controller K2362-1 (requires either the K2312-1
Power Feed 10SF Wire Feed Head for fixed hard automation, or
the K2370-1 Power Feed 10S Head for mounting a Lincoln TC-3
Travel Carriage), Power Feed 10SM Motor Conversion Kit K2311-1
(Other options may apply).
Order
K2344-1
Power Wave AC/DC 1000
K2344-2
Power Wave AC/DC 1000
Input Current
Output
@Rated Output
Range
68/62/54
100-1000A
82/79/69/62/55
100-1000A
50
3
60
Input
Hz
PHASE
460/500/575/3/60
400/460/500/575/3/50/60
Dimensions
Net
H x W x D
Weight
in (mm)
lbs (kg)
43.5 x 19.2 x 33
600
(1105 x 488 x 838)
(272)
43.5 x 19.2 x 33
650
(1105 x 488 x 838)
(295)
Publication E10.96 1/05
Web Update 1/06
www.lincolnelectric.com
