SECTION 1 SPECIFICATIONS
' ' GENERAL
• Frequency coverage
• Type of emission
• Antenna impedance
• MIC impedance
• Audio impedance
• Power supply requirement
• Current drain (approx.)
• Frequency stability
• Usable temperature range
• Dimensions (projections not included)
• Weight (approx.)
' ' TRANSMITTER
• RF output power
(with supplied battery pack)
• Modulation system
• Maximum frequency deviation
• Spurious emissions
• Adjacent channel power
• Transmitter audio distortion
• Residual modulation
• Audio frequency response
' ' RECEIVER
• Receive system
• Intermediate frequencies
• Sensitivity
• Squelch sensitivity
• Adjacent channel selectivity
• Spurious response rejection
• Intermodulation rejection ratio
• Hum and noise
• Audio output power
• Audio frequency response
Specifications are measured in accordance with EIA/TIA-603.
All stated specifications are subject to change without notice or obligation.
: 156.025–157.425 MHz
156.050–163.275 MHz
: 16K0G3E
: 50 Ω
: 2 kΩ
: 8 Ω
: 7.2 V DC (negative ground; supplied battery pack)
: Transmit
at High (5.0 W)
at Low (1.0 W)
Receive
max audio
: ±10 ppm
: –20˚C to +60˚C; –4˚F to +140˚F
: 61(W) × 135(H) × 41(D) mm; 2
: 360 g; 12.7 oz. (with BP-224)
: 5 W / 1 W (High / Low)
: Variable reactance frequency modulation
: ±5.0 kHz
: 68 dB
: 70 dB
: Less than 10 % at 1 kHz, 60% deviation
: 40 dB
: +1 dB to –3 dB of 6 dB octave from 300 Hz to 3000 Hz
: Double conversion superheterodyne system
: 1st
21.7 MHz
2nd
450 kHz
: 0.25 µV at 12 dB SINAD
: 0.35 µV at threshold
: 70 dB (typical)
: 70 dB (typical)
: 70 dB (typical)
: 40 dB
: 350 mW typical at 10% distortion with an 8 Ω load
: +1 dB to –3 dB of –6 dB octave from 300 Hz to 3000 Hz
1 - 1
1.5 A
0.7 A
200 mA
(W) × 5
(H) × 1
13
⁄
5
⁄
5
⁄
(D) in.
32
16
8
