Biamp IWA 250 User Manual

TABLE OF CONTENTS
Front Panel Features
Applications
Specifications & Block Diagram
Warranty
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not block any of the ventilation openings.
Install in accordance with the manufacturers instructions.
WARNING - To reduce the risk of electric shock, do not expose
this apparatus to rain or moisture.
Unplug this apparatus during lightning storms or when unused
for long periods of time.
Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
Explanation of safety related markings and symbols which appear on the outside of the apparatus.
Lightning Bolt: Hazardous Live voltages present when this unit is in operation. Do not touch terminals marked with this
symbol while the unit is connected to live power.
Exclamation Point: Replace components (i.e. fuses) only with the values specified by the manufacturer. Failure to do so will
compromise safe operation of this unit.
CAUTION
RISK OF ELECTRICAL SHOCK.
DO NOT OPEN.
IWA 250 - USER MANUAL
INTRODUCTION
The IWA 250 In-Wall Powered Mixer provides an 8 input/2 output mixer plus
pgs. 2 & 3
emergency page interrupt, a 9-band graphic equalizer, and a 250 Watt power
amplifier with outputs for standard and distributed speaker systems. Optional
pgs. 4 & 5
VCA remote control cards may be added for controlling mixer input/output
levels. Designed for in-wall or surface mounting, with integral security cover,
pg. 6
the IWA 250 is UL/C-UL listed and is covered by a five-year warranty.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
IMPORTANT SAFETY INFORMATION
CAUTION: Opening the unit enclosure will place operator at risk of injury due to electric shock.
six balanced microphone/line level mixer input channels
two balanced/summing line level mixer input channels
high & low tone controls on each mixer input channel
independent main & aux level controls on each channel
trim control & peak indicator on each mic/line input channel
additional balanced line input for emergency page interrupt
main & aux mixer outputs with master level controls
mixer functions provided on screw-driver adjustable controls
optional VCA cards for remote control of input/output levels
9-band graphic equalization integrated at amplifier input
patch points provided for mixer outputs & equalizer input
mixer inputs & outputs on front panel plug-in barrier strips
output taps for standard and distributed speaker systems
+48 Volt phantom power selectable for microphone inputs
"in-wall" or "surface-mount" chassis with security cover
UL and C-UL listed
covered by Biamp Systems' five-year warranty
Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. When the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete
outlet.
Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
1
