XXX XXX/XXXXX/25MM9481
USE AND CARE GUIDE
ELECTRIC FIREPLACE
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
Thank You
We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!

Advertisement

Table of Contents
loading

Related Manuals for Home Decorators XXX XXX/XXXXX/25MM9481

Summary of Contents for Home Decorators XXX XXX/XXXXX/25MM9481

  • Page 1 Thank You We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...

  • Page 2: Table Of Contents

    Table of Contents Maximum Load Warning ........... 2 Package Contents .............. 6 Safety Information ............. 3 Assembly ..............7 Warranty ..............4 Operation ..............13 Pre-Assembly ............. 5 FCC/IC Information ............15 Hardware Included ........... 5 Care & Cleaning ............15 Product Specifications ............

  • Page 3: Safety Information

    Safety Information Important Safety Instructions Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 1-800-986-3460, 8 a.m.-6 p.m., EST, Monday-Friday. When using electrical appliances, always follow basic precautions to WARNING: Under no circumstances should this fireplace be reduce the risk of fire, electrical shock, and injury to persons, including...

  • Page 4: Warranty

    Warranty 1 Year Limited Warranty: The manufacturer warrants this product to be free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations: Install and operate this Electric Fireplace in accordance with the installation and operating instructions furnished with the product at all times.

  • Page 5: Pre-Assembly

    Pre-Assembly HARDWARE INCLUDED Part Description Part Number Quantity 2 Hole Plastic Connector Block PH-PCBBLK001 3 Hole Plastic Connector Block PH-PCBBLK002 Flathead Screw Short Bolt PH-BLTBLK002 Wood Dowel PH-DWLNTL001 Washer Head Screw PH-SCRBLK001 Medium Bolt PH-BLTBLK001 Leveler (Pre-Attached) Magnet Latch PH-MTLBLK001 Strike Plate Metal Plate (Pre-Attached) PH-PLTBLK001...

  • Page 6: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS NOTE: All panels are labeled left and right as viewed from the front of unit. Part Description Quantity Base Assembly Left Front Panel Center Left Side Panel Right Front Panel Center Right Side Panel Center Front Panel Center Top Assembly Center Shelf Center Front Lower Panel...

  • Page 7: Assembly

    Assembly Preparing the Center Side Panels Attaching the Center Front Panels Screw the Short Bolt (DD) through the 2 Hole Plastic Screw the Short Bolt (DD) through the 2 Hole Plastic Connector Block (AA) on the Center Left Side Panel (C) Connector Block (AA) onto the edge of the Center Left to the edge of the Left Front Panel (B).
  • Page 8 Assembly (continued) Attaching the Center Front Panel Attaching the Center Shelf Attach the Center Front Panel (F) to the Center Shelf (H) Attach the Center Shelf (H) assembly to the Center Right using the Short Bolt (DD). Side Panel (E) and Center Left Side Panel (C) using the Short Bolt (DD).
  • Page 9 Assembly (continued) Preparing the Center Front Attaching the Center Front Lower Lower Panel and the Support Panels Panel Screw the Short Bolts (DD) through the the 2 Hole Plastic Using the Short Bolt (DD) attach the Center Front Lower Connector Block (AA) to the Center Front Lower Panel (I). Panel (I) to the bottom of the completed assembly from Step 6.
  • Page 10 Assembly (continued) Preparing the Upper Center Attaching the Support Panels Front Panel Attach the Support Panels (J) to the Base Assembly (A) by Screw the Short Bolts (DD) through the 2 Hole Plastic screwing the Short Bolts (DD) through the 3 Hole Plastic Connector Block (AA) to the Upper Center Front Panel (K).
  • Page 11 Assembly (continued) Installing the Center Top Assembly Installing the Center Back Panel Attach the Center Top Assembly (G) to the assembly from Attach the Center Back Panel (L) to the completed Step 12 using Short Bolts (DD). assembly from Step 13 using the Washer Head Screws (FF). Preparing the Left &...
  • Page 12 Assembly (continued) Preparing the Inner and Preparing the Left and Right Front Outer Side Panels Panels Screw the Short Bolts (DD) through the 3 Hole Plastic Screw the Short Bolts (DD) through the 2 Hole Plastic Connector Block (BB) to the Left Lower Front Panel (O) and Connector Blocks (AA) onto the edge of the Inner Right...
  • Page 13 Assembly (continued) Attaching the Left and Right Base Attaching the Outer Back Panels & Top Assemblies Attach the Outer Back Panels (V) to the completed Attach the Outer Base Assembly (U) and Left Top assemblies from Step 19 using the Washer Head Screws Assembly (T) to the left assemblies from Step 18 using (FF).
  • Page 14 Assembly (continued) Installing the Strike Plates Installing the Adjustable Shelves Attach the Strike Plates (JJ) to the top of the Glass Insert the Shelf Pins (OO) into the desired shelf height holes Doors (W). on the Inner Left Side Panel (R) and the Outer Side Panels (Q). Make sure to insert the Shelf Pins (OO) evenly on both panels.
  • Page 15 Assembly (continued) Attaching the Assemblies Removing the Brackets The Left and Right Assemblies can be mounted flush in Remove the screws from the pre-attached Brackets (NN). the front (A) or flush in the back (B). Set the Brackets (NN) and screws aside. Insert the 2-Piece Connector Bolt (QQ) into the appropriate holes in the Side Panels and tighten.

  • Page 16: Operation

    Operation Operation NOTE: The control panel can be accessed at the upper-right corner of the insert. When a function is changed from the control panel or remote control there will be a corresponding indicator (see Figure 1) on the upper-right of the projection screen.

  • Page 17: Replacing The Remote Control Battery

    Operation (continued) Replacing the Remote Control Battery Disposing of Used Batteries When the remote control stops operating or its range The battery may contain hazardous substances that seems reduced, it is time to replace the batteries with could endanger the environment and human health. new ones.

  • Page 18: Fcc/Ic Information

    FCC/IC Information This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer- ence to radio or television reception, which can be determined by turning the equipment off and on.

  • Page 19: Troubleshooting

    Troubleshooting PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Unplug the fireplace, remove the back panel of the fireplace and check that the thermo- The thermostat sensor is stat is plugged into the main circuit board. The display shows “E1”. broken or disconnected. If this does not solve the problem contact customer service for a replacement thermo- stat sensor.

  • Page 20: Replacement Parts

    Replacement Parts For replacement parts, call our customer service department at 1-800-986-3460, 8 a.m.-6 p.m., EST, Monday-Friday. Part Description Qty. Heater/Blower Assembly Main Circuit Board Flame Generator/ Spinner Flame Generator Drive Motor LCD Display Front Projection Screen Flame Circuit Board Emberbed with Log Control Panel Circuit Board Control Panel Buttons...
