659 257/85811Y/23DE9448-PT85
659 258/85804Y/23DE9448-NE01
USE AND CARE GUIDE
CHARLES MILL ELECTRIC FIREPLACE
QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE,
CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE
8 A.M. - 7 P.M., EST, MONDAY - FRIDAY, 9 A.M. - 6 P.M., EST, SATURDAY
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
imporvement needs. Thank you for choosing Home Decorators!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHARLES MILL 659 257 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Home Decorators CHARLES MILL 659 257

Summary of Contents for Home Decorators CHARLES MILL 659 257

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...

  • Page 2: Table Of Contents

    Table of Contents Maximum Load Warning ........... 2 Package Contents .............. 7 Safety Information ............. 3 Assembly ..............8 Warranty ..............5 Operation ..............16 Pre-Assembly ............. 6 FCC/IC Information ............18 Hardware Included ........... 6 Care & Cleaning ............18 Product Specifications ............

  • Page 3: Safety Information

    Safety Information Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any question regarding the product, please call customer service at service at 1-800-986-3460, 8 a.m.-7 p.m., EST, WARNING: Under no circumstances should this fireplace be Monday-Friday, 9 a.m.
  • Page 4 Safety Information (continued) NOTE: Use care in assembling your new fireplace. Take your time and use the hardware provided and a quality Phillips head screwdriver. Never overtighten bolts. • Do not sit on any part of the mantel. NOTE: To avoid injury from unexpected starting or electrical shock, do not plug the power cord into a source of power during unpacking and assembly.

  • Page 5: Warranty

    Warranty Warranty 1 Year Limited Warranty: The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of puchase, subject to the following conditions and limitations. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times.

  • Page 6: Pre-Assembly

    Pre-Assembly HARDWARE INCLUDED Plastic Connector 19PCS Block PH-PCBBLK001 16PCS Ø4*12mm BOLT Part Description Part Number Quantity 2 Hole Plastic Connector Block PH-PCBBLK001 3 Hole Plastic Connector Block PH-PCBBLK002 Short Flathead Screw Bolt PH-BLTBLK002 Floor Glide (Pre-attached) PH-GLDBRW001 Knob (with Screw) Long Flathead Screw Metal Plate (Pre-attached) PH-PLBLK001...

  • Page 7: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS NOTE: All panels are labeled left and right as viewed from the front of unit. Part Description Quantity Base Assembly Left Front Panel Left Partition Right Front Panel Right Partition Middle Front Panel Top Assembly Left Side Panel Right Side Panel Center Shelf Divider...

  • Page 8: Assembly

    Assembly Preparing the partitions Preparing the partitions Attach 2 Hole Plastic Connector Blocks (AA) to the Left Attach the Small Plastic Connector Blocks (II) to the Partition (C) using Bolts (DD). Right Partition (E) using Short Flathead Screws (CC). Repeat this process for the Right Partition (E). Repeat this process for the Left Partition (C).
  • Page 9 Assembly (continued) Preparing the middle front panel Attaching the middle front panel Screw the Bolts (DD) through the 2 Hole Plastic Insert the Wood Dowels (MM) into the pre-drilled holes Connector Blocks (AA) into the Middle Front Panel (F) on the ends of the Middle Front Panel (F). and tighten.
  • Page 10 Assembly (continued) Attaching the center shelf Preparing the side panels Screw the Bolts (DD) through the 2 Hole Plastic Screw the Bolts (DD) through the 2 Hole Plastic Connector Blocks (AA) into the Center Shelf (J) Connector Blocks (AA) onto the edge of the Left to secure.
  • Page 11 Assembly (continued) Attaching the side panels Attaching the base assembly Attach the Left Side Panel (H) and the Right Side Panel Insert the Wood Dowels (MM) into the pre-drilled holes (I) to the assembly from the step 7. on the completed assembly from Step 10. Secure using the Bolts (DD) through the 2 Hole Plastic Using the Long Flathead Screw (GG) attach the Base Connector Blocks (AA).
  • Page 12 Assembly (continued) Attaching the divider Attaching the top assembly Insert Wood Dowels (MM) into the pre-drilled holes in Attach the Top Assembly (G) to the completed assembly the Divider (K). from Step 13. Secure the Divider (K) to the Center Shelf (J) with the Secure using the Bolts (DD) through the Large Flathead Screw (GG).
  • Page 13 Assembly (continued) Preparing the doors Attaching the knobs Attach the Hinges (L-2) to the Right Door (O) using the Remove the preassembled screws from the Knobs (FF), Short Washerhead Screws (NN). then attach the Knobs (FF) to the Left Door (N) and Right Repeat for the Left Door (N).
  • Page 14 Assembly (continued) Installing the fireplace insert into Installing the adjustable shelves the mantel assembly Choose desired height of the Adjustable Shelf (P) and Lift the Fireplace Insert (T) carefully into the back of the place the four Shelf Pins (KK) in the corresponding unit and center in the fireplace insert opening.
  • Page 15 Assembly (continued) Preparing the corner extension Assembling the corner extension Place the Corner Extension (R) face down on a scratch Attach the Corner Brace (S) to the Corner Extension (R) free surface. by inserting Bolts (DD) through the holes in the 2 Hole Attach 2 Plastic Connector Blocks (AA) to the Corner Plastic Connector Block (AA) and tighten.

  • Page 16: Operation

    Operation Operation NOTE: The control panel can be accessed at the upper-right corner of the insert. Powering the fireplace Adjusting the flame Push the Power button to supply power to all There are 6 brightness levels that can be selected: functions of the fireplace and put the insert in a standby mode.
  • Page 17 Operation (continued) Replacing the remote control battery Disposing of used batteries The battery may contain hazardous substances that When the remote control stops operating or its range could endanger the enviroment and human health. seems reduced, it is time to replace the battery with new ones.

  • Page 18: Fcc/Ic Information

    FCC/IC Information WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 19: Troubleshooting

    Troubleshooting PROBLEM ROOT CAUSE CORRECTIVE ACTION Unplug the fireplace, remove the back panel of the fireplace and check that the The thermostat sensor is thermostat is plugged into the main circuit Display shows " " broken or disconnected. board. If this does not solve the problem contact customer service for a replacement thermostat sensor.
  • Page 20 Troubleshooting (continued) PROBLEM ROOT CAUSE CORRECTIVE ACTION Flame effect works but heater With the power on press and hold the POWER function does not and the emberbed button on the control panel for 10 seconds. The heater is disabled. flashes when the heater button is Once re-enabled the emberbed lights will pressed.

  • Page 21: Replacement Parts

    Replacement Parts For replacement parts, call our customer service department at 1-800-986-3460, 8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. Part Description Qty. Remote Control Flame Circuit Board Blue LED Circuit Board Flame Generator Drive Motor Thermostat Sensor Blower/ Heater Assembly Control Panel Circuit Board...
  • Page 22 Questions, problems, missing parts? Before returning to the store call Home Decorators Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS RETAIN THIS MANUAL FOR FUTURE USE.
