Code Alarm ca5554 PROFESSIONAL SERIES Installation Manual page 8

11 VIOLET/BLACK
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
To activate refer to the transmitter button configuration chart. Please refer to the
selectable options for timing.
3 Pin Parking Light Harness
1 BLACK
Connect the BLACK wire to a solid chassis ground point using a ring terminal and
self tapping screw (not supplied). Scrape away paint from the grounding point to
ensure a good connection. The recommended grounding point is a metal surface in
the driver's side kick panel area.
NOTE: Do not ground the BLACK wire with any other vehicle components.
2 WHITE/RED
3 WHITE
Locate the parking light output wire at the vehicle's light switch.
Verification: This wire registers positive voltage when the parking lights are
turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15 Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
8
AUX 1
GROUND
PARKING LIGHT INPUT
PARKING LIGHT OUTPUT
ca5554 Install rev A
