Install CardWizard

1
2
3
4
5
6
7
8
9
10

Set Up the PC Card

1
2
3
4
If CardWizard was already installed before you began installing the PC Card, the
installation skips this portion and proceeds directly to "Set Up the PC Card".
When the computer restarts, if the 3Com 11 Mbps WLAN Menu appears, click Exit.
At the prompt to install CardWizard, click Yes.
If you click No and you do not have CardWizard installed, the installation stops.
In the CardWizard window, click Next.
In the CardWizard Welcome page, click Next.
Read the CardWizard Software License Agreement and click Yes.
When prompted to remove the PC Card, eject the card and click Yes.
In the Select Type of Platform window, select your computer type and click Next.
If your computer type is not listed, select Other Notebook and click Next.
Respond to the prompts to install CardWizard.
When the CardWizard installation finishes, click the Restart the computer radio
button and click Finish.
Insert the PC Card.
After the computer restarts, the 3Com 11 Mbps Wireless LAN Client Setup
window opens. In this window, you can specify the PC Card configuration.
In the 3Com 11 Mbps Wireless LAN Client Setup window, select Typical and
click Next.
Typical configures the PC Card with the following default values:
WLAN Service Area—Attach to any WLAN Service Area automatically
Security Setting—No security (Open system)
If you want to customize the PC Card configuration, for example, to add security,
select Custom. See "Custom Installation Options" on page 34 for details on
custom settings. For the fastest installation, it is recommended that you use the
typical settings. You can customize the configuration later as described in
"Configuring the Wireless Client" on page 43.
In the Summary window, review the PC Card setup and click Finish.
When prompted to run the Setup program, click OK.
Run the Setup program:
a From the Windows Start menu, select Run.
In the Run dialog box, enter a path to the Setup program on the 3Com CD. For
b
example, d:\srsetup.exe.
The 3Com 11 Mbps Wireless LAN Setup program starts.
Installation Under Service Pack 5 and Above 59
