GE Merlin Installation And Maintenance Manual page 8

8
Rev D
Dispensing Faucet
without Air Gap
Product - 3/8" Blue
Carbon Postfilter
Feed Water Valve
Cold Water Line Only
Inlet-1/2" Natural
Drain - 3/8" Black
1.5" Air Gap Required
Figure 2 Typical Basement Installation
Note: If a flush tank is not
installed the manifold
connection must remain
plugged. Removal of
plug will cause a system
leak.
Floor
Flush Tank
(Optional)
1/4" Blue
RO Assembly
THE BASIC REVERSE OSMOSIS SYSTEM
