MSB Technology Link DAC III User Manual page 5

I
NSTALLATION
This section describes how to install the Upsampling Upgrade in a LINK III. Dis-
regard this section if the upgrade was factory installed.
LINK III P
REPARATION
Place the LINK III on a soft surface like a tablecloth or carpet. Disconnect the
power supply. Remove the three philips screws on the back edge of the cover.
Turn the LINK over and remove the three philips screws from the front edge of the
cover. Carefully separate the base from the cover. Pick up the base and flip it over,
placing it inside the cover. Take care not to disconnect the ribbon cable to the front
panel. Place the LINK so that the RCA connectors are facing AWAY from you.
This way all the diagrams will be oriented correctly.
R
EMOVE THE JUMPERS AND INSTALL THE BOARD
Two headers can be seen in the middle of the LINK III board. They are labeled J18
and J19. Four jumpers are installed as shown. Remove these jumpers. Tape them
to the inside of the base so they will not be lost. Install the upgrade board by
U S
PSAMPLING WITCH
96K U
PSAMPLING
132K U
PSAMPLING
B I
ALANCED NPUT
5
MSB N I
ETWORK NPUT
C
C 4
H
3
C 1
H
H
C 2
H
