User's Manual
NOTE: Ductless operation is
supported as an additional option.
For ductless operation, please
refer to the ductless kit.
For residential and indoor use only
Please read this operation manual thoroughly before
using your range hood. Store it in a safe location for
when you need to reference it in the future.
RA-60TB30SS
RA-60TB36SS
RA-60TB42SS
RA-60TB48SS
Advertisement
Table of Contents
Related Manuals for Windster RA-60TB30SS
Summary of Contents for Windster RA-60TB30SS
- Page 1 User’s Manual RA-60TB30SS RA-60TB36SS RA-60TB42SS RA-60TB48SS NOTE: Ductless operation is supported as an additional option. For ductless operation, please refer to the ductless kit. For residential and indoor use only Please read this operation manual thoroughly before using your range hood. Store it in a safe location for...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of Contents Safety Information .............. 2 – 3 Content Checklist ..............4 Measurements ................5 Preparation ................6 Installation ................7 – 8 Installation Diagram ..............9 Operation & Features ............10 – 11 Cleaning & Maintenance ............12 Troubleshooting .............. -
Page 3: Safety Information
SAFETY INFORMATION SAFETY INFORMATION TO REDUCE THE RISK OF A FIRE, ELECTRICAL SHOCK, AND/OR INJURY OBSERVE THE FOLLOWING: Unit is intended for indoor residential use only. If you should have questions, contact the manufacturer at the address or telephone number listed in the warranty. -
Page 4: Safety Information
SAFETY INFORMATION TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: Regardless of heat level, never leave any surface materials unattended while operating an open flame. Always turn hood ON when cooking at high heat or when flambéing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé). -
Page 5: Content Checklist
CONTENT CHECKLIST CONTENT CHECKLIST CONTENTS INCLUDED (1) RA-60TB series (30”, 36”, 42” or 48”) hood assembly (1) Lower duct cover (14-1/4”) (1) Upper duct cover (14-1/4”) (1) User’s manual (1) 6” – 7” transition collar (2) Baffle filters (RA-60TB 30” model only) (3) Baffle filters (RA-60TB 36”... -
Page 6: Measurements
MEASUREMENTS... -
Page 7: Preparation
PREPARATION PREPARATION BEFORE YOU START **BE SURE YOUR UNIT WILL FIT YOUR CEILING HEIGHT** Be sure you have all the content of your purchase and required tools for this installation. Installation may take at least 1 to 2 hours from start to finish. Plan to use as few elbows or turns as possible for more efficient air flow. -
Page 8: Installation
INSTALLATION INSTALLATION 1. WALL MOUNT INSTALLATION Make sure all preparation steps are completed. Determine your ceiling height to see if you need an extension. i. Hood unit height = 12-1/4” ii. Duct cover minimum height = 19” iii. Duct cover maximum height = 35-1/2” iv. -
Page 9: Installation
INSTALLATION 3. COLD WEATHER INSTALLATION (OPTIONAL) Check with your local building codes to see if a CFM reducer is an acceptable alternative to make-up air. Remove the RA-60TBCFMR (CFM reducer) and inspect for any sign of defect or damage. (ie. Cracks, broken flips) AFTER COMPLETING Step A –... -
Page 10: Installation Diagram
INSTALLATION DIAGRAM INSTALLATION DIAGRAM... -
Page 11: Operation & Features
OPERATION & FEATURES OPERATION & FEATURES EASY ACCESS CONTROL SWITCH (from left to right) Button 1 – Power ON / OFF Button 2 – Low speed Button 3 – Medium speed Button 4 – High speed Button 5 – Lights ON/OFF BAFFLE FILTERS (2) 14-7/8”... -
Page 12: Cleaning & Maintenance
CLEANING & MAINTENANCE CLEANING & MAINTENANCE WARNING!!! To prevent the possibility of a fire and explosion, do not use flammable liquids or solvents to clean the unit or any of its parts. Check to make sure all power sources are disconnected before servicing or taking unit apart for cleaning. -
Page 13: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING WARNING!!! Check to make sure all power sources are disconnected before starting any troubleshooting. Safety gloves and glasses should be worn when working on the unit. Serious injury or death may occur if safety precautions are not followed. RA-60TB Series Light issue (All not New transformer/ driver replacement is required. -
Page 14: Part List / Replacement
PART LIST / REPLACEMENT PART LIST / REPLACEMENT Description Description Duct cover bracket Control Bracket Duct cover LED transformer Duct cover holder Capacitor Hood bracket Squirrel cage motor Hood body assembly Oil collector LED lights Baffle filters c t i ”... -
Page 15: Warranty / Contact Us
For a period of one (1) year from the date of purchase, if the product is determined to be defective, Windster will attempt to repair the product, at its option, at no charge. After the warranty period, customer must pay for all labor charges. During the "labor"... - Page 16 CONTACT US Windster Hoods, Inc. 5101 Commerce Dr. Baldwin Park, CA 91706 TEL: (626) 962 – 8600 FAX: (626) 962 – 8669 Toll Free: (877) 350 – 5215 E-mail: support@windsterhood.com © Windster Hoods, Inc. Information subject to change without notice...
