Model
SCENIC
Also known as Spirit, RS1000, RS600, RS400,
Liberty Frameless, Lux and Edge
Model options
Remote
Installation and User Instructions
All instructions must be handed to
user for safekeeping
This is not a DIY product and must be
installed by a Gas Safe registered
installer
Edition D 10/11
Country(s) of destination - GB/IE
1
Advertisement
Table of Contents
Related Manuals for Sirocco SCENIC Spirit
Summary of Contents for Sirocco SCENIC Spirit
- Page 1 Model SCENIC Also known as Spirit, RS1000, RS600, RS400, Liberty Frameless, Lux and Edge Model options Remote Installation and User Instructions All instructions must be handed to user for safekeeping This is not a DIY product and must be installed by a Gas Safe registered installer Edition D 10/11 Country(s) of destination - GB/IE...
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS These Notes Must Be Read Before Installation This appliance is an Inset Live Fuel Effect appliance that provides radiant or combined radiant and convected heat; it cannot and should not be used as the main heating source within a property. The appliance is designed to fit most types of fireplaces with a natural draught flue as listed in the Installation Requirements. - Page 3 OPENING THE APPLIANCE Stand the carton the right way up, open the box from the top. Read all the instructions before continuing to unpack or install this appliance. Remove the bags containing ceramic components such as coals or gravel etc. Remove the cardboard packing pieces, and any other bags or boxes containing fittings or other parts.
-
Page 4: Table Of Contents
INSTRUCTIONS CONTENT Section Contents Page No Important Notes Installation requirements Appliance Information Ventilation Site Requirements Pre-Fabricated Flue box Debris Space Installation of appliance Preparing the Opening 12/13/14 Fitting the Burner Tray Fuel Bed 19/20/21 Commissioning the Appliance Operating the Appliance Remote Control 10.1 Spark Failure Setting Pressure... -
Page 5: Important Notes
Section 1: IMPORTANT NOTES These fires are Inset Live Fuel Effect Gas Fires providing radiant warmth. It is designed to operate on Natural Gas only. It is the LAW that all gas appliances and fittings are installed by a competent person such as a Gas Safe Registered fitter and in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards for Installation, Codes of Practice and in accordance with the manufacturers’... -
Page 6: Installation Requirements
Section 2: INSTALLATION REQUIREMENT This appliance MUST NOT be installed into a bathroom or shower room, or where steam may be present. An extractor fan must not be fitted in the same room or space as the appliance as this can affect the safety of the appliance. -
Page 7: Appliance Information
Section 3: APPLIANCE INFORMATION SCENIC 400 Models 600 Models 1000 Models G20 Natural Gas CAT G20 Natural Gas CAT G20 Natural Gas CAT Gas Group Inlet Pressure 20 mbar 20 mbar 20 mbar Max Input (gross) 12.5 Min Input (gross) Setting Pressure 20 mbar 20 mbar... -
Page 8: Ventilation
SECTION 4: VENTILATION The 400 and 600 models do not normally require purpose provided ventilation. The 1000 model does require purpose made ventilation to an outside area in accordance with current regulations. However, if a second appliance operating within the same room or space must be taken into consideration when assessing ventilation. - Page 9 The appliance can be used in a no hearth application if the installation complies to BS 5871-3:2005 and appliance is installed so that the height from the base of the fireplace opening to the floor is no less then 300mm. As with all heating appliances, any decorations, soft furnishings, and wall coverings (i.e.
- Page 10 Flue Adaptor for 600 and 1000 Models Optional Extra Gather hood comes with 600 and 1000 Models must be installed. Main Firebox Front fascia panel when removing always ensure that the fascia is refitted the correct way up as this may result in the appliance not working correctly.
-
Page 11: Debris Space
It is important that the sealing requirements of the appliance are met at all times and that the flue box is sealed to any back or infill panel. Section 6: DEBRIS SPACE In accordance with BS 5871 part 2, minimum debris collection volumes are required behind the installed appliance. - Page 12 The tray is now free and may be lifted away from the box. If this is the Remote controlled version of the this fire then care is needed when removing the burner not to damage the wiring system of the fire, you will need to remove the connections to the control box from the valve thermocouple and spark generator lead.
- Page 13 Removing the Burner on the 400 Model. Remove the burner from the assembly by removing the three screws holding the inspection cover over the isolation valve, and undo the connecting nut to the isolation tap. Remove the four screws two on each side of the burner tray and undoing the connecting nut to the isolation tap.
-
Page 14: Preparing The Opening
Remove front grill and then lift the burner tray free. SECTION 7.1: PREPARING THE OPENING Before installing the fire, check the flue for correct operation using a smoke pellet, all of the smoke should be drawn up the flue and exit correctly from the terminal. If problems are found DO NOT fit the fire until corrective measures have been completed. - Page 15 With the fire box in place and the burner tray removed fix the gather hood into place where required by lifting into position through the fire box opening securing in place with self- tapping screws supplied, to ensure air tight seal you can seal with aluminium gas tap (not supplied).
-
Page 16: Fitting The Burner Tray
You will need to remove the plaster from the wall around the fire enough to be able to fix a sheet of master board or non- combustible board over the fire box when in place to be able to be plastered to a finish ready to be decorated. SECTION 7.2 FITTING THE BURNER TRAY Temporarily fit the burner tray and ensure a suitable gas route can be achieved. -
Page 17: Fuel Bed
400 Models SECTION 8: FUEL BED LAYOUT Place the filtration granules (the smaller ones supplied) in to the channel levelling out the granules equally... -
Page 18: Commissioning The Appliance
Next place the larger chippings Grey or Black all over the burner, place these by the handful do not pour as the dust could block the pilot assembly. Leave the area around the pilot assembly clear to allow for good cross-lighting. Place any further pebbles or twigs over the chippings to the desired look. -
Page 19: Operating The Appliance Remote Control
Section 10: OPERATING THE APPLIANCE (Remote control) See Section 18 Users Instructions Section 10.1: SPARK FAILURE The gap between the spark electrode and the pilot should be 3.5 - 4.5mm to produce a good spark. There should be no need to adjust this. If under any circumstances the electric spark fails, the pilot may be lit manually by proceeding with the ignition sequence as previously described, and after turning the control knob through the spark position, the knob should be held in and the pilot lit with a taper. -
Page 20: Spillage Monitoring System
After a further 3 minutes turn the gas supply ON again, if the gas has stopped flowing, the Flame Supervision Device (FSD) is operating correctly. Always check that the gas has stopped flowing even if you hear the FSD valve close within the 3-minute period. -
Page 21: Testing For Spillage
SECTION 13: TESTING FOR SPILLAGE Close all doors and windows to the room containing the appliance. Let the fire run on HIGH for five minutes. Take a smoke match, light it, and using a smoke match tube, hold it at the top edge of the fire opening, 25mm down and 25mm in. -
Page 22: Servicing
Advise that the fire will emit a “newness” smell for a time after initial commissioning and that extra ventilation may be needed during this time. Advise that the fire is fitted with a spillage safety device (O.D.S.). If the fire shuts down, this system may be in operation. -
Page 23: Cleaning The Ceramics
SECTION 16: CLEANING THE CERAMICS Remove the ceramic components. Gently clean in the open air using a dry paint brush. Be careful not to create dust from the coals. Where necessary replace damaged components with genuine spares. Seal scrap ceramic components in plastic bags and dispose at proper refuse sites as directed. Re-fit the fuel bed by referring to the relevant sections of these instructions SECTION 17: TROUBLESHOOTING GUIDE Fire sparks but pilot Flame does not light? - Page 24 Pilot flame shrinks when fire is on high? Poor gas flow to fire, check pressure with fire on high. If pressure is low, remove any restriction in pipe work or valve. Check all isolators are adequately sized and fully open. Check meter pressure is adequate.
-
Page 25: User Instructions
SECTION 18: USER INSTRUCTIONS IMPORTANT NOTES The installation of this fire MUST only be carried out by a competent person (such as a Gas Safe registered fitter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturers’... - Page 26 A combustible shelf may be fixed to the wall above the fire, providing that it complies with the dimensions given in section 3 site requirements. No purpose provided ventilation is normally required for this appliance. The requirements of other appliances operating in the same space or room, and the results of a spillage test must be taken into consideration when assessing ventilation requirements, this will have been carried out by your Gas Safe registered installer.
- Page 27 To turn down the fire, point the handset to the sensor on your fire then push and hold the minus button (small flame), if you release immediately the flame will go to low if you keep holding the flame will lower slowly and you can release the button to your desired position.
- Page 28 Note: Fitting the batteries incorrectly could lead to damaging your control box. Different types of batteries or old and new batteries are not to be mixed. Only batteries of the same or equivalent type as recommended are to be used. Batteries are to be inserted with the correct polarity.
- Page 29 BEFORE CONTACTING SIROCCO FOR SERVICE PLEASE READ THE FOLLOWING; Sirocco is committed to customer care and service. To ensure we provide the best service we can we have a policy to charge for all none warranty home visits so that all customers with a genuine manufactures fault can be dealt with swiftly, if your appliance has recently been installed and you are experiencing any of the following;...
-
Page 30: List Of Spares
SECTION 20: LIST OF SPARES 400 models... - Page 31 Royal 600 Remote Control...
- Page 32 Royal 1000 Remote Control...
- Page 33 400 Ceramics 600 Ceramics 1000 Ceramics...
- Page 34 400 MODEL CODE SPARE PART DESCRIPTION PARTNUMBER GRAVEL GREY ROYAL 400 GRAVEL BLACK ROYAL 400 BURNER GRANUALS ROYS ENGINE EXCLUDING CERAMICS ENGINE RECEIVER HT LEAD DUMMY SWITCH EDB LP VER.5 CONTROL BOX REMOTE HAND SET ACS2 LP VALVE BATTERY LEAD BATTERY HOLDER PILOT REMOTE NG ROYS...
- Page 35 08432 89 0102 Mon to Fri 9:00 to 16:00 Contact our spares department by email spareparts@siroccofire.pl Purchase spare parts direct from our website www.siroccofires.com Spare parts are managed by our UK partner company Lodestar-Delta Ltd Lodestar-Delta Ltd T/A Sirocco Unit 1, 11 Weir St, Blackburn, Lancashire BB2 2AN...
-
Page 36: Contact Details
Nad Lasem 8, Zabia Wola 96-321 Zelechow Poland TECHNICAL HELP LINE Speak to a Sirocco trained engineer 0904 084 3473 (0904 084 FIRE) This is a premium rate number charged at 1.00 plus vat per minute from BT lines Mon to Fri 9:00 to 17:00... -
Page 37: Warranty Statement
CONDITIONS OF GUARANTEE Sirocco (hereinafter referred to as the company) will, at its option, repair or replace free of charge any product or part thereof which is shown to the satisfaction of the company to be defective due to faulty materials or workmanship within 12 months from the date of purchase, subject to the conditions set out below: 1. - Page 38 29 It is essential that your Sirocco appliance is serviced, by a suitably qualified Gas Safe engineer or a Sirocco authorised appointed engineer to carry this out at least every twelve months, as part of your 5 year warranty...
