M
y
s
t
i
q
u
e
M
y
s
t
i
q
u
e
M
y
s
t
i
q
u
e
ECO 4
REMOTE
DECORATIVE FUEL EFFECT APPLIANCE
THIS IS NOT A "DO-IT-YOURSELF" PRODUCT
THIS IS A NATURAL GAS (G20) APPLIANCE FOR USE IN GB
AND IE ONLY AT A SUPPLY PRESSURE OF 20mbar.
USER'S, INSTALLATION
AND SERVICE MANUAL
PLEASE KEEP THESE INSTRUCTIONS IN A SAFE
PLACE FOR FUTURE REFERENCE
Our policy is one of constant development and improvement.
Strict accuracy of illustrations and specifications is not guaranteed.
Modifications to design and materials may be necessary subsequent to publication.
V.11.07
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sirocco Mystique ECO 4
Summary of Contents for Sirocco Mystique ECO 4
- Page 1 ECO 4 REMOTE DECORATIVE FUEL EFFECT APPLIANCE THIS IS NOT A “DO-IT-YOURSELF” PRODUCT THIS IS A NATURAL GAS (G20) APPLIANCE FOR USE IN GB AND IE ONLY AT A SUPPLY PRESSURE OF 20mbar. USER’S, INSTALLATION AND SERVICE MANUAL PLEASE KEEP THESE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE Our policy is one of constant development and improvement.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT NOTES _________________________________ USER’S SECTION ___________________ 4 FUEL EFFECT ________________________________________ CONSUMPTION______________________________________ OPERATING INSTRUCTIONS __________________________________ TO LIGHT THE FIRE ______________________________________ TO SELECT THE REQUIRED FLAME LEVEL _______________________ 4 TO TURN OFF ________________________________________ CLEANING __________________________________________ OXYGEN DEPLETION SYSTEM _________________________________ FUEL BED ASSEMBLY _____________________________________ INSTALLATION SECTION... -
Page 3: Important Notes
IMPORTANT NOTES IMPORTANT: PLEASE READ ALL OF THE INSTRUCTIONS IN THIS BOOKLET BEFORE COMMENCING INSTALLATION AS FAILURE TO COMPLY WITH THE REGULATIONS HEREIN COULD LEAD TO PROSECUTION & INVALIDATE THE WARRANTY SOFT WALL COVERINGS, (e.g. EMBOSSED VINYLS etc.) WHICH HAVE A RAISED THE FIRE MUST NOT BE FITTED AGAINST A PATTERN, ARE EASILY AFFECTED BY HEAT COMBUSTIBLE WALL. -
Page 4: User's Section
USER’S SECTION FUEL EFFECT This fire is supplied with ceramic fuel effect pieces to simulate a real fire. These items are safe to handle and the coals are designed for easy re- TO SELECT THE REQUIRED FLAME fitting after removal LEVEL Gas consumption To turn down the fire, point the handset to the... -
Page 5: Servicing And Maintenance
OXYGEN DEPLETION SYSTEM If the Oxygen Depletion System (ODS) operates, i.e. shuts off the gas supply to the fire, WAIT FOR THREE MINUTES and follow the operating instructions on pages 4 and 5. The ODS is designed to shut off the gas supply to the burner if the oxygen content of the room falls below a certain level. - Page 6 COAL / PEBBLE LOYOUT The eco 4 is available with two different fuel effects as follows: Coal Made up of a rear ceramic, front ceramic and 9 coals. Pebbles Made up of rear ceramic, front ceramic and 9 pebbles. Place 5 coals / pebbles on the front matrix and 4 on the back row The Coals/Pebbles MUST be placed, sitting...
-
Page 7: Installation Section
INSTALLATION SECTION NO COMPONENT IS MANUFACTURED FROM accordance with the current edition of ASBESTOS ASBESTOS RELATED I.S.813 “Domestic Gas Installations” and the PRODUCTS. current building regulations. THE APPLIANCE DATA BADGE IS LOCATED The appliance can be used in a builders NEXT TO THE CONTROL KNOB. -
Page 8: Check Carton Contents
Eco 4 Burner Unit. combustible). The hearth material MUST be at least 12.5mm thick. Its top surface should Eco 4 Hotbox or Convector Box. be 50mm above the floor level to discourage Isolation Elbow with Nut & Olive. ... -
Page 9: Appliance Installation
A nut and olive is provided for the copper protect the end of the supply pipe when pipe inlet connection via the Isolation Tap. passing through walls, cavities etc, to stop brick dust and debris entering the NOTE: The supply pipe must be of rigid pipe and causing a blockage or damage durable material. -
Page 10: Check For Gas Soundness
FUNCTIONAL CHECKS Remove the pressure test point sealing screw from the isolation elbow and attach a suitable pressure gauge. RECIVER Light the pilot and check the correct operation of the burner at all the flame settings. Refer Operating instructions on pages 4 and 5. Check that the inlet gas pressure is as stated on page 8 when the fire is at its highest setting. -
Page 11: Final Check And Customer Breifing
If all the smoke is not drawn into the Recommend that the appliance and chimney, leave the fire alight for a further 10 chimney should be inspected and serviced minutes at the HIGH setting and then repeat by a competent person annually. the test. -
Page 12: To Remove The Thermocouple Assy
10.2 TO REMOVE THE 10.3 TO REMOVE THE GAS VALVE THERMOCOUPLE ASSY. Follow 10.1 above to remove the burner tray. (a) Follow 10.1 above to remove the burner Disconnect the lead from the control unit tray. Disconnect the thermocouple nut from (b) Disconnect the thermocouple connection the rear of the valve from the control unit. -
Page 13: Fault Finding
MAINTENANCE SPARE During servicing and maintenance your appliance may need some replacement parts. Here is a short list of spare parts that are available. Please contact SIROCCO if other parts are required: Eco 4 Only Supplier Ref. Description Manufacturers Part No. - Page 14 IGNITION FUNCTIONAL CHECK 1 BURNER WILL NOT LIGHT Ensure there is no debris around the spark ignitor, e.g. coal, soot, etc. which could short the spark, clean the area. Operate the valve. Is there a spark? See NO SPARK chart. Does the burner light? Is the control being SYSTEM OK...
- Page 15 FLAME FAILURE FUNCTIONAL CHECK BURNER WILL NOT STAY LIT OR FIRE GOES OUT If the appliance goes out in use continually, this may mean that the oxygen depletion sensor (ODS) has been activated. The appliance should not be used until the cause has been found and rectified. Ensure there is no debris around the pilot burner port, e.g.
