eco
DECORATIVE FUEL EFFECT APPLIANCE
THIS IS NOT A "DO-IT-YOURSELF" PRODUCT
THIS IS A NATURAL GAS (G20) APPLIANCE
FOR USE IN GB AND IE ONLY AT A SUPPLY
PRESSURE OF 20mbar.
USER INSTALLATION & SERVICE MANUAL
FOR: -
REMOTE
ECO 1& 2
PLEASE KEEP THESE INSTRUCTIONS IN A
SAFE PLACE FOR FUTURE REFERENCE
Our policy is one of constant development and improvement.
Strict accuracy of illustrations and specifications is not guaranteed.
Modifications to design and materials may be necessary subsequent to publication.
Tel: (01282) 441 771
VII-11-09
Advertisement
Table of Contents
Related Manuals for Sirocco REMOTE ECO 1
Summary of Contents for Sirocco REMOTE ECO 1
- Page 1 DECORATIVE FUEL EFFECT APPLIANCE THIS IS NOT A “DO-IT-YOURSELF” PRODUCT THIS IS A NATURAL GAS (G20) APPLIANCE FOR USE IN GB AND IE ONLY AT A SUPPLY PRESSURE OF 20mbar. USER INSTALLATION & SERVICE MANUAL FOR: - REMOTE ECO 1& 2 PLEASE KEEP THESE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE Our policy is one of constant development and improvement.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT NOTES___________________________________________ 3 USER’S SECTION ___________________________________ 4 FUEL EFFECT ________________________________________ CONSUMPTION______________________________________ OPERATING INSTRUCTIONS __________________________________ TO LIGHT THE FIRE ___________________________________________ 4 SELECT THE BURNER FLAME LEVEL ____________________________ 4 TO TURN OFF ________________________________________________ 4 CLEANING___________________________________________________ 4 OXYGEN DEPLETION SYSTEM _________________________________ FUEL BED ASSEMBLY _____________________________________... -
Page 3: Important Notes
IMPORTANT NOTES IMPORTANT: PLEASE READ ALL OF THE INSTRUCTIONS IN THIS BOOKLET BEFORE COMMENCING INSTALLATION AS FAILURE TO COMPLY WITH THE REGULATIONS HEREIN COULD LEAD TO PROSECUTION & INVALIDATE THE WARRANTY SOFT WALL COVERINGS, (e.g. EMBOSSED THE FIRE MUST NOT BE FITTED AGAINST A VINYLS etc.) WHICH HAVE A RAISED COMBUSTIBLE WALL. -
Page 4: User's Section
USER’S SECTION FUEL EFFECT TO SELECT THE REQUIRED FLAME This fire is supplied with ceramic fuel effect pieces LEVEL to simulate a real fire. These items are safe to handle and the coals are designed for easy re- To turn down the fire, point the handset to the fitting after removal sensor on your fire then push and hold the minus button (small flame), if you release immediately... -
Page 5: Oxygen Depletion System
OXYGEN DEPLETION SYSTEM If the Oxygen Depletion System (ODS) operates, i.e. shuts off the gas supply to the fire, WAIT FOR THREE MINUTES and follow the operating instructions on pages 4 and 5. The ODS is designed to shut off the gas supply to the burner if the oxygen content of the room falls below a certain level. - Page 6 Figure 2A FRONT MATRIX REAR MATRIX (eco 1,2&3) Place 5 coals / pebbles on the front ceramic, 5 on the middle row of the floor matrix and 4 on the back row. As shown in figure 2A The Coals/Pebbles MUST be placed, sitting on-top of the front ceramic resting between the pillars of the floor matrix.
- Page 7 CANOPY INSTALLATION The canopy is available in two different styles. ‘E-Type’ Canopy and ‘S-Type’ Canopy. Either of these canopies can be installed prior to, or after, installation of the appliance, this is due to a series of holes tailored in the hotbox top and canopy fixing face allowing fixture via two self tapping screws. Figure 2c.
-
Page 8: Installation Section
INSTALLATION SECTION NO COMPONENT IS MANUFACTURED FROM accordance with the current edition of ASBESTOS ASBESTOS RELATED I.S.813 “Domestic Gas Installations” and the PRODUCTS. current building regulations. THE APPLIANCE DATA BADGE IS LOCATED NEXT TO THE CONTROL KNOB. The appliance can be used in a builders opening or fireplace conforming to the sizes GENERAL DATA below: -... -
Page 9: 3 Check Carton Contents
Remove the contents carefully checking that appliance can be fitted to a purpose made proprietary class “O” – 100°C or 150°C all the listed parts are present and in good surround. condition. In particular the finished hearth level MUST extend 300mm in front of the vertical face of the THE FIREPLACE fireplace. -
Page 10: Check For Gas
The burner tray should be removed from the fire first. To do this first remove the battery then HAVE YOU PURGED THE GAS remove the two screws from the base of the SUPPLY PIPES? This is essential to control panel beneath the control knob. Then expel any foreign matter that might be disconnect the compression nut on the top of blown into the valve assembly,... -
Page 11: Oxygen Depletion System
Supervision Device (FSD) is operating FINAL CHECK AND CUSTOMER correctly. Always check that the gas has BREIFING stopped flowing even if you hear the FSD valve close within the 3-minute period. Instruct the customer on the full operation of the appliance. Turn OFF the appliance and the gas supply and refit the pressure test point sealing screw. - Page 12 10.1 TO REMOVE THE BURNER Follow 10.1 above to remove the burner tray. UNIT Disconnect the lead from the control unit Disconnect the thermocouple nut from (a) Remove the fender and ash pan cover the rear of the valve together with all the fuel effect pieces. Disconnect the pilot tube from the valve (b) Disconnect the appliance from the gas- Remove the injector tube...
-
Page 13: Fault Finding
MAINTENANCE SPARES During servicing and maintenance your appliance may need some replacement parts. Here is a short list of spare parts that are available. Please contact SIROCCO if other parts are required: Eco 1,2 & 3 Only Supplier Ref. Description Manufacturers Part No. - Page 14 IGNITION FUNCTIONAL CHECK 1 BURNER WILL NOT LIGHT Ensure there is no debris around the spark ignitor, e.g. coal, soot, etc. which could short the spark, clean the area. Operate the valve. Is there a spark? See NO SPARK chart. Does the burner light? Is the control being SYSTEM OK...
- Page 15 FLAME FAILURE FUNCTIONAL CHECK BURNER WILL NOT STAY LIT OR FIRE GOES OUT If the appliance goes out in use continually, this may mean that the oxygen depletion sensor (ODS) has been activated. The appliance should not be used until the cause has been found and rectified. Ensure there is no debris around the pilot burner port, e.g.
