Sirocco Fire Royal 1000 User Manual

Decorative fuel effect appliance
Hide thumbs
Table of Contents

Advertisement

Quick Links

eco
"Fire Royal"
Models 1000 & 600
DECORATIVE FUEL EFFECT APPLIANCE, THIS IS A
NATURAL GAS (G20) APPLIANCE FOR USE IN GB AND IE
.
ONLY AT A SUPPLY PRESSURE OF 20mbar
USER'S, INSTALLATION
AND SERVICE MANUAL REMOTE
PLEASE KEEP THESE INSTRUCTIONS IN A SAFE
PLACE FOR FUTURE REFERENCE
Our policy is constant development and improvement.
Strict accuracy of illustrations and specifications is not guaranteed.
Modifications to design and materials may be necessary subsequent to
publication.
WINTHER BROWNE
75 Bilton Way, Enfield, London, EN3 7ER
Tel.0845 612 1893 Fax 0845 612 1894
V-11-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fire Royal 1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sirocco Fire Royal 1000

Summary of Contents for Sirocco Fire Royal 1000

  • Page 1 “Fire Royal” Models 1000 & 600 DECORATIVE FUEL EFFECT APPLIANCE, THIS IS A NATURAL GAS (G20) APPLIANCE FOR USE IN GB AND IE ONLY AT A SUPPLY PRESSURE OF 20mbar USER’S, INSTALLATION AND SERVICE MANUAL REMOTE PLEASE KEEP THESE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE Our policy is constant development and improvement.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT NOTES___________________________________________ 3 USER’S SECTION _____________________________________________ 4 FUEL EFFECT ________________________________________________ 4 GAS CONSUMPTION __________________________________________ 4 OPERATING INSTRUCTIONS - __________________________________ 4 _______________________________________________ 4 ANUAL ERSION TO LIGHT THE FIRE _________________________________________________4 SELECT THE BURNER FLAME LEVEL _________________________________4 TO TURN OFF _______________________________________________________4 CLEANING _________________________________________________________4...

  • Page 3: Important Notes

    IMPORTANT NOTES SOFT WALL COVERINGS, (e.g. EMBOSSED OF THE HEARTH MUST BE 650mm FOR THE VINYLS etc.) WHICH HAVE A RAISED 16” VERSION AND 700mm FOR THE 18" PATTERN, ARE EASILY AFFECTED BY HEAT VERSION. A N D SCORCH BECOME DISCOLOURED WHEN CLOSE THE FIRE MUST NOT BE FITTED AGAINST A...

  • Page 4: User's Section

    USER’S SECTION FUEL EFFECT NOTE: When first turned on the flames will appear predominately blue. The ceramic bed will take time to warm up. This fire in certain models is supplied with ceramic fuel effect pieces to simulate a real fire and a granular bed to provide flame distribution across After lighting the pilot as described above, the bed.

  • Page 5: Operating Instructions - Remote Control Version

    inspected and serviced by a competent person TO TURN OFF before further use. To turn your fire off, point the handset at the sensor and push the top left button. The fire will go OPERATING INSTRUCTIONS - out. Remote Control Version OXYGEN DEPLETION SYSTEM If the Oxygen Depletion System (ODS) operates, i.e.

  • Page 6: Installation Section

    INSTALLATION SECTION NO COMPONENT IS MANUFACTURED FROM accordance with the current edition of ASBESTOS OR ASBESTOS RELATED PRODUCTS. I.S.813 “Domestic Gas Installations” and the current building regulations. THE APPLIANCE DATA BADGE IS LOCATED ON THE PLATE UNDER THE BURNER The appliance can be used in the following openings: GENERAL DATA Gas Type:...

  • Page 7: Check Carton Contents

    rugs or carpets over it. The appliance can be fitted to a purpose made proprietary class CHECK CARTON CONTENTS “O” – 100°C or 150°C surround. Fire Royal Burner Unit.  In particular the finished hearth level MUST Set of fuel ceramic pieces ...

  • Page 8: Check For Gas Soundness

    burner assembly by removing the four CHECK FOR GAS SOUNDNESS screws and disconnecting the nut as shown in Fig 5. Decide on the best Turn on the gas supply and check for gas position for the gas supply to enter the fire soundness with a suitable leak detection fluid (see box and remove a knock out hole for the BS 6891).

  • Page 9: Final Check And Customer Breifing

    Move the smoke match across the interruption of the evacuation of opening. The installation is satisfactory if combustion products i.e. a blocked all the smoke is drawn into the chimney. chimney etc. (b) Describe the restart procedures. If all the smoke is not drawn into the (c) Point out that on operation of the chimney, leave the fire alight for a further ODS system they must seek...

  • Page 10: To Remove The Pilot Burner Assembly

    Remote control box VAL-RC-ROY-1-SO-4-A Remote control pilot assembly VAL-RC-ROY-1-SO-5-A Remote control receiver VAL-RC-ROY-1-SO-6-A Manual valve VAL-CV-ROY-1-SG--A Please contact SIROCCO if other parts are required. FAULT FINDING FAULT CAUSE / POSSIBLE REMEDY Pilot will not light. See Ignition Functional Check 1. V-11-07...
  • Page 11 No spark. See Ignition Functional Check 2. Pilot will not stay lit or fire goes See Flame Failure Functional Check. out in use. Uneven flame pattern e.g. flame 1. The fuel effect may need adjusting to even the flame pattern. at one side only.
  • Page 12 IGNITION FUNCTIONAL CHECK 2 NO SPARK Ensure there is no debris around the pilot assembly, e.g. coal, soot, etc. which could short the spark, clean the area. Operate the valve to light the pilot. Does the valve click? Is the valve being Is the gap between operated correctly? electrode and tpilot burner...
  • Page 13 FIG 6 FLUE ADAPTER (OPTION NOT INCLUDED) GATHER HOOD SCREWS SUPPLIED CANOPY SCREWS SUPPLIED V-11-07...
