  6. Manual & remote installation and user instructions

Sirocco Royal Solo Apex Manual & Remote Installation And User Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Model
Royal Solo
Model options
Apex, Spirit, R1000, R600, R400, Ignite,
Pinnacle, Liberty and Lux
Manual & Remote
Installation and User Instructions
All instructions must be handed to
user for safekeeping
This is not a DIY product and must be
installed by a Gas Safe registered
installer
Edition H 02/14
Country(s) of destination - GB/IE
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Royal Solo Apex and is the answer not in the manual?

Questions and answers

Related Manuals for Sirocco Royal Solo Apex

Summary of Contents for Sirocco Royal Solo Apex

  • Page 1 Model Royal Solo Model options Apex, Spirit, R1000, R600, R400, Ignite, Pinnacle, Liberty and Lux Manual & Remote Installation and User Instructions All instructions must be handed to user for safekeeping This is not a DIY product and must be installed by a Gas Safe registered installer Edition H 02/14...

  • Page 2: Installation Instructions

    INSTALLATION INSTRUCTIONS These Notes Must Be Read Before Installation This appliance is an Inset Live Fuel Effect appliance that provides radiant or combined radiant and convected heat; it cannot and should not be used as the main heating source within a property. The appliance is designed to fit most types of fireplaces with a natural draught flue as listed in the Installation Requirements.
  • Page 3 OPENING THE APPLIANCE Stand the carton the right way up, open the box from the top. Read all the instructions before continuing to unpack or install this appliance. Remove the bags containing ceramic components such as coals or gravel etc. Remove the cardboard packing pieces, and any other bags or boxes containing fittings or other parts.

  • Page 4: Table Of Contents

    INSTRUCTIONS CONTENT Page Section Contents Important Notes Installation requirements Appliance Information Ventilation Site Requirements 9 to 10 Pre-Fabricated Flue box Debris Space Installation of appliance Preparing the Opening 12 to 13 Fitting the Burner Tray 13 to 16 Fuel Bed Fitting The Outer Frame/ Trim Commissioning the Appliance 10.1...

  • Page 5: Important Notes

    Section 1: IMPORTANT NOTES These fires are Inset Live Fuel Effect Gas Fires providing radiant warmth. It is designed to operate on Natural Gas only. It is the LAW that all gas appliances and fittings are installed by a competent person such as a Gas Safe Registered fitter and in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards for Installation, Codes of Practice and in accordance with the manufacturers’...

  • Page 6: Installation Requirements

    Section 2: INSTALLATION REQUIREMENT This appliance MUST NOT be installed into a bathroom or shower room, or where steam may be present. An extractor fan must not be fitted in the same room or space as the appliance as this can affect the safety of the appliance.

  • Page 7: Appliance Information

    Section 3: APPLIANCE INFORMATION Royal 1000 Gas Group G20 Natural Gas CAT I2H G20 Natural Gas CAT I2H G20 Natural Gas CAT I2H Inlet Pressure 20 mbar 20 mbar 20 mbar 12.5 Max Input (gross) Min Input (gross) Setting Pressure 20 mbar 20 mbar 20 mbar...

  • Page 8: Ventilation

    SECTION 4: VENTILATION The 400 and 600 models do not normally require purpose provided ventilation. The 1000 model does require purpose made ventilation to an outside area in accordance with current regulations. However, if a second appliance operating within the same room or space must be taken into consideration when assessing ventilation.
  • Page 9 It is recommended that a tactile barrier should be place on the floor in front of the appliance to stop the elderly, infirm or Children from direct contact with the hot surfaces of the appliance. The area immediately above the outlet must form a smooth path into the flue. The appliance can be used in a no hearth application if the installation complies to BS 5871-3:2005 and appliance is installed so that the height from the base of the fireplace opening to the floor is no less than 300mm.

  • Page 10: Debris Space

    SECTION 5.1: PREFABRICATED FLUES These appliances can be fitted to a prefabricated flue system, the 400 model will require a flue box but the 600 and 1000 appliance can be fitted directly to the appliance via a flue adaptor (sold separately) All will require a false chimney breast in which to be housed and will need to be constructed of a non-combustible material or any combustible material within 300mm must be clad with a non-combustible board.

  • Page 11: Installation Of Appliance

    Section 7: INSTALLATION OF APPLIANCE Always ensure that the gas supply is isolated before commencing installation of the appliance. The fireplace opening and environment must be in compliance with specifications laid down in the appropriate sections of these instructions. Remove the appliance from its carton as described previously and stand on a dust sheet. Place the fuel bed, ceramics and fixings safely to one side.

  • Page 12: Preparing The Opening

    SECTION 7.1: PREPARING THE OPENING Before installing the fire, check the flue for correct operation using a smoke pellet, all of the smoke should be drawn up the flue and exit correctly from the terminal. If problems are found DO NOT fit the fire until corrective measures have been completed. Before running the gas supply into the opening, offer up the fire box to the fireplace to check the fit is good.
  • Page 13 The isolator tap or restrictor elbow must be fitted to the incoming supply to facilitate servicing. The gas pipe must be suitably protected where it passes through fireplace openings. Any sleeving should be sealed to the pipe at its ends. The open end of the gas supply pipe should be temporarily sealed to prevent ingress of dust and dirt during installation.

  • Page 14: Fitting The Burner Tray

    Then locate the back edge in the internal canopy as shown below Locate plate back edge in back of canopy SECTION 7.2 FITTING THE BURNER TRAY Temporarily fit the burner tray and ensure a suitable gas route can be achieved. This process is a simple reverse of the previous instructions on how to remove the burner tray.
  • Page 15 On the remote control version please take care not to pull or overstretch the electrical connections as this may cause the fire to fail on commissioning. If the fire is the manual control system, you will now need to place extension bar and bracket in place so that the fire can be operated when the fascia is in place.
  • Page 16 Fit the two securing screws through the front plate ensuring that the plate is in front of the front edge of the fire box. Secure the spindle in place by passing the spindle through the plate and securing to the valve using the two grub screws provides and attached the control knob to the other end.

  • Page 17: Fuel Bed

    Note: Please ensure that the electrode spark igniters’ gap on the manual version has not been misaligned during the handling of the burner in this installation the gap should be 4 to 5mm from thermocouple. If the fire is the remote control version then carefully place the tray into position and fit batteries as per user guide instructions.
  • Page 18 SECTION 9: FITTING THE DECORATIVE FRAME These appliances are supplied with either a Single level fascia or a dual fascia, the frame on the back has two slotted brackets at the top of the frame which hook on to the two brackets placed at the top of the firebox.

  • Page 19: Commissioning The Appliance

    Section 10: COMMISSIONING THE APPLIANCE Turn on and test the gas supply up to the fire for any leaks, in accordance with current Approved Codes of Practice (ACO Section 10.1: OPERATING THE APPLIANCE See Section 12 Users Instructions page ** Section 10.3: SPARK FAILURE The gap between the spark electrode and the pilot should be 3.5 - 4.5mm to produce a good spark.
  • Page 20 SECTION 12: FLUE SPILLAGE MONITORING SYSTEM Royal fires are fitted with a flue spillage safety device (ODS). If the fire shuts down during use for no apparent reason then several things may be suspected, if a door or window has been opened creating a draught, then pilot disturbance is the problem, and removal of the draught should resolve this.
  • Page 21 SECTION 14: BRIEFING THE CUSTOMER All instructions must be handed to the user for safekeeping. Show the customer how to light and operate the fire. After commissioning the appliance, the customer should be instructed on the safe use of the appliance and the informed for the need of regular servicing.
  • Page 22 SECTION 15: SERVICING Isolate the fire from the gas supply. Ensure that the fire is fully cold before attempting service. A suggested procedure for servicing is detailed below: 1. Lay out the dust sheet and tools required. 2. Remove the fascia, see Section 9. 3.
  • Page 23 SECTION 16: CLEANING THE CERAMICS Remove the fascia if required, see Section 9. Remove the ceramic components. Gently clean in the open air using a dry paint brush. Be careful not to create dust from the coals. Where necessary replace damaged components with genuine spares. Seal scrap ceramic components in plastic bags and dispose at proper refuse sites as directed.

  • Page 24: Remote Control

    SECTION 17: TROUBLESHOOTING GUIDE cont: Fire runs for a time and then cuts off? Excessive room draught or flue pull, rectify. Loose or faulty thermocouple, rectify. O.D.S system in operation. Firebox grommet seal not fitted, rectify. Lint in pilot aeration hole, clean thoroughly internally Pilot flame shrinks when fire is on high? Poor gas flow to fire, check pressure with fire on high.
  • Page 25 SECTION 18: USER INSTRUCTIONS IMPORTANT NOTES The installation of this fire MUST only be carried out by a competent person (such as a Gas Safe registered fitter) in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards, Codes of Practice, the Building Regulations and the manufacturers’...
  • Page 26 OPERATING THE APPLIANCE (Manual Control) For your safety, the fire is fitted with a Flame Supervision Device (FSD), which will shut off the Gas supply if for any reason the pilot is extinguished. This device incorporates a fixed probe, which senses heat from the pilot burner flame, if the probe is cooled, the device will prevent any gas flow.

  • Page 27: Operating The Appliance Remote Control

    OPERATING THE APPLIANCE (Remote control) IMPORTANT USER INFORMATION – AFTER INSTALLATION BY THE ENGINEER , READ THIS BEFORE ATTEMPTING TO OPERATE THE FIRE Insert the batteries in the TESC Control and handset as show inside the battery cover and slide isolation switch to the I position of gas control Hold the handset and the green unlock light will illuminate allowing the buttons to work.
  • Page 28 Press and hold in the power symbol button and release immediately when the word pilot appears at the bottom left of the display( after about 1-2 seconds). The fire will light. To Adjust the flame hold the handset to enable the buttons to work and press and the - button to reduce the flame.
  • Page 29 Quick start user instructions Fire Control This control is situated on your fire. The drawing shows the main features of the control. The control required 3 x AA size alkaline batteries to be inserted under the battery compartment cover. The orientation of these is shown moulded into the battery compartment. After fitting the batteries and replacing the cover the fire can now operate.
  • Page 30 The Valve and Handset Have Already Been Paired First set up the hand set, cup the handset the green unlock light will illuminate. Keep it held to keep the control unlocked, to enable operation of the buttons. 3) Setting the time the display will be as shown, as the time is not set yet and will progress automatically to the next screen shown below.
  • Page 31 4) Setting the display for 12 or 24 Hour display As always when pressing the remote control buttons keep the control held to keep the green light on and therefore handset safety feature, unlocked. The H indicates that it is time to set the timer to either 24 hour display or 12 Hour (AM or PM) display.
  • Page 32 Setting the temperature display to Celsius or Fahrenheit. Press and release the + or - button to toggle between C and F. When the display shows the desired symbol, press and releases the “SET” button to store. As the important settings above have now been done. Press and hold (not releasing straight away) the “SET”...
  • Page 33 Mode In Range of the fire Man = Manual If missing out of Zzz = Snooze range or fire Therm = Thermostat switched off Timed Day of the Week Room Time (12 or 24hr) Temperature Fire Status Handset Battery Indicator Unlocked if RC = Handset Illuminated...
  • Page 34 Operating instruction (Detailed) 1) Upon successful insertion of the batteries in the Handset (if the handset has not previously paired) the display will be as shown if it has been paired already then go to No 3. 1a) If display is not as above the handset may well need to be reset before pairing. Press and Hold “Set”...
  • Page 35 Hold the handset in one hand so your fingers wrap around the back of the operating buttons area of the handset. A green unlock light will illuminate when the handset has detected your hand. The green light must be illuminated in this way for any of the command buttons to accept commands to operate the fire control.
  • Page 36 BEFORE CONTACTING SIROCCO FOR SERVICE PLEASE READ THE FOLLOWING; Sirocco is committed to customer care and service. To ensure we provide the best service we can we have a policy to charge for all none warranty home visits so that all customers with a genuine manufactures fault can be dealt with swiftly, if your appliance has recently been installed and you are experiencing any of the following;...

  • Page 37: List Of Spares

    SIROCCO Sp. Zo.o Nad Lasem 8, Zelecow, 96-321 Zabia Wola, Poland. Tel 0048 22 425 8681, Fax 0048 46 857 8559. Further information, contact details and email facilities are available through our website;...
  • Page 38 SECTION 20: LIST OF SPARES Royal 600 Manual Controls...
  • Page 39 SECTION 20: LIST OF SPARES Royal 1000 Manual Controls...
  • Page 40 Royal 400 Remote Control...
  • Page 41 Royal 600 Remote Control...
  • Page 42 Royal 1000 Remote Control...
  • Page 43 Royal 400 Ceramics Royal 600 Ceramics Royal 1000 Ceramics...
  • Page 44 Code ROYAL400 SPARE PART DESCRIPTION PART NUMBER Manual Burner Unit c/w extended control Remote Burner unit c/w remote handset and battery holder 8mm Gas Inlet tube ROY4 4mm Pilot inlet tube ROY4 8mm Main burner Inlet tube ROY4 8mm Burner pipe ROY4 PILOT NG Thermaco NG OXI-PG-82-460 Therm...
  • Page 45 Ceramic black chippings twigs N stix Filtration granules for 1000 model SECTION 21: CONTACT DETAILS SIROCCO HEAD OFFICE Telephone number for all departments 0843 289 4268 (charged at BT national rate) Mon to Fri 10:00 to 15:00 Contact us by email adminuk@siroccofire.pl...

  • Page 46: Warranty Statement

    CONDITIONS OF GUARANTEE Sirocco (hereinafter referred to as the company) will, at its option, repair or replace free of charge any product or part thereof which is shown to the satisfaction of the company to be defective due to faulty materials or workmanship within 12 months from the date of purchase, subject to the conditions set out below: 1.
  • Page 47 In Addition to the above the following terms and conditions apply to extended 5 year warranty; 25 Extended 5 year parts warranty has to be issued by an appointed Sirocco Premier stockiest, no other stockists are authorised to issue these warranties...
  • Page 48 29 It is essential that your Sirocco appliance is serviced, by a suitably qualified Gas Safe engineer or a Sirocco authorised appointed engineer to carry this out at least every twelve months, as part of your 5 year warranty...
