- Page 1 Series 6000 Installation & User Instructions Model Also known as: Ignite Pinnacle 600 Apex 600 Vola 600 All instructions must be handed to the user for safekeeping. This is not a DIY product and must be installed by a Gas Safe registered installer. Edition E 03/23...
-
Page 2: Table Of Contents
Contents Installation Instructions ............................3 Opening the appliance ............................3 Legislation ................................4 Installation requirements ............................4 Appliance Information ............................5 Ventilation ................................5 Site Requirements ..............................6 Shelves ..................................6 Site Requirements ..............................7 Suite Option ................................7 Frameless Option ..............................7 Prefabricated Flue Boxes ............................ - Page 3 Restoring a lost pairing – Pairing the handset to the fire control ................ 18 Cleaning the fuel bed ............................18 General cleaning ..............................19 Warranty ................................19 Contact details..............................20...
-
Page 4: Installation Instructions
Dispose of packaging responsibly. ▪ Check contents correspond with the following table. If they do not then do not continue with the installation, instead call Sirocco Fires on 012 502 2233 and report the discrepancy: Quantity Description Manufacturers fitting instructions... -
Page 5: Legislation
Legislation This appliance is an Inset Live Fuel Effect Gas Fire providing radiant and convection warmth, designed to operate on Natural Gas. It is law that all gas appliances are installed by a Gas Safe Registered fitter and in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant British Standards for Installation, Codes of Practice and be in accordance with the manufacturers’... -
Page 6: Appliance Information
A suitable terminal may be fitted as regulations allow. GC1 terminals are not recommended for use with this appliance, Sirocco Fires recommend the colt top gas cowl or similar be used. Depending on the flue construction, on occasions the temperature reached can cause cracking of the surface plaster through no fault of the appliance. -
Page 7: Site Requirements
Air Vents fitted under or within the immediate vicinity of the appliance must not be used as adverse effects to the operation of the Flame Safety Device (FSD) may occur. Spillage detected during commissioning is almost always a result of poor flue performance that cannot be corrected by any amount of ventilation. For Republic of Ireland ventilation may be required, see IS 813, ICP3, IS 327, and any other rules in force. -
Page 8: Site Requirements
Site Requirements As with all heating appliances, any decorations, soft furnishings, and wall coverings (i.e., flock, blown vinyl and most wallpaper) positioned too close to the appliance may discolour or scorch. Possible cracking of the plaster may occur with this type of appliance, combined with the variations of plaster conditions and thicknesses from property to property. -
Page 9: Clearance/Debris Space
If a false chimney breast is required for the appliance to be housed in, this will need to be constructed of a non- combustible material or any combustible material within 350mm must be clad with a non-combustible board. The correct clearances to combustible materials (i.e., false chimney breast etc.) must be adhered to. A flue box may be used if conforming to the correct clearances. - Page 10 ▪ Remove the ceramic boards from the burner tray. The boards are fragile and are best removed by lifting them gently with a flat edged tool such as a paint scraper. Do not bend the boards as they are fragile. Place the boards on a flat surface. ▪...
-
Page 11: Preparing The Opening
Preparing the opening Before installing the fire, check the flue for correct operation using a smoke pellet. All of the smoke should be drawn up the flue and exit correctly from the terminal. If this is not the case, then DO NOT fit the fire until corrective measures have been completed. -
Page 12: Use Of A Flue Liner
Use of a flue liner The fireplace opening will be required to have a sealing plate fitted/horizontal register plate fitted. This is not supplied and should be sourced from your flue supplier. The plate will need to be sealed at the base of the flue with the liner fixed and sealed within it. -
Page 13: Pilot Disturbance
The aeration hole of the pilot must be carefully cleaned out on each annual service to ensure continued function of the ODS. Pilot disturbance Pilot disturbance can cause the fire to cut out for no apparent reason. Pilot disturbance often occurs when a door or window has been opened, causing a stronger than usual draught. -
Page 14: User Instructions
▪ Scratches and other superficial damage to the matt black paintwork of the appliance can be covered with matching heatproof spray. Paint only when the fire is OFF and cold. Always mask off the surrounding area to prevent contamination with overspray. Ventilate the room during the use of the spray. -
Page 15: Operating The Remote-Control Valve And Handset
Operating the remote-control valve and handset The Remote Control with this appliance has already been paired to the appliance during production. The pairing is unique to the appliance it is supplied with and will not operate another appliance without first being re-paired to the new valve. -
Page 16: The Remote Control
The remote control The handset is fitted with a safety device to minimise accidental ignition of the appliance. To unlock the handset grasp it as shown in the picture. The green unlock light will illuminate to show the handset is unlocked and ready to accept commands. -
Page 17: Setting The Time
Setting the time Press + or – button to change the hour value and SET to store, then do the same for minutes. Press SET to store and move to next page. Setting the temperature to Celsius or Fahrenheit Press and release the + or - button to toggle between C and F. When the display shows the desired symbol, press the SET button to store and move to the next page. -
Page 18: The Display Screen
The display screen. Mode Man = Manual Zzz = Snooze Therm = Thermostat In Range of the fire Timed If missing out of range or fire switched off Day of the Week Time (12 or 24hr) Room Temperature Fire Status Battery Indicator Handset Unlocked if RC = Handset... -
Page 19: Restoring A Lost Pairing - Resetting The Handset
Restoring a lost pairing – Resetting the handset If the display is not as above, it is possible that the handset may need to be reset before pairing. Press and Hold “Set” Button, to enter Programming menu. When SETUP is flashing, press and release SET to enter SETUP Mode. -
Page 20: General Cleaning
Hotspot or Peek can be used to remove stubborn particles Warranty You have purchased a Sirocco Fires appliance that has been made to the highest standards. When properly maintained and used the appliance will perform perfectly for many years and is warranted for 5 years from the date of purchase for parts, provided that such parts have been subjected to normal conditions of use. -
Page 21: Contact Details
– expressed or implied – with respect to the product, its components and accessories or any obligations or liabilities on the part of Sirocco Fires are hereby expressly excluded. Sirocco Fires neither assumes nor authorises any third party to assume on its behalf any other liabilities with respect to the sale of this Sirocco Fire appliance.
