Elation Rayzor Q7 User Manual page 23

PERSONALITY - Display Setting – Display Reverse
Rotate (Flip) the Control Panel display 180
PERSONALITY - Display Setting – Key Lock
Lock the Control Panel buttons automatically after exiting main menu for 15
seconds. Unlock by keeping the MODE/ESC button pressed for 3 seconds,
default is OFF.
PERSONALITY - Display Setting – Disp Flash
Control Panel flashes if NO DMX signal is detected, default is OFF.
PERSONALITY – Temperature C/F
Display the temperature in Celsius or Fahrenheit, default is Fahrenheit.
PERSONALITY – Initial Status
Display the initial effect position for DMX functions.
PERSONALITY – Reset Default
Restore factory settings function (ON or OFF), the default is OFF.
RESET FUNCTION
Reset fixture function (Reset All or Reset Pan^Tilt).
EFFECT ADJUST – Test Channel
Test each DMX function.
EFFECT ADJUST – Manual Control
Manual control of each DMX function.
EFFECT ADJUST – Calibrate Values
Adjust PAN and TILT to desired positions. A correct password must be entered
in order to make adjustments. The Password is (=050). A technician familiar
with the operations of this fixture should only perform this function. This
function allows small adjustments to be made to the motor alignments to
compensate for wear.
Improper use of this function can result in undesired operation!
Please contact Elation Customer Support for further instructions.
w w w . e l a t i o n l i g h t i n g . c o m
w w w . e l a t i o n l i g h t i n g . c o m
°
, default is OFF.
23
RAYZOR Q7™ User Manual ver 1
