  • Page 1 OPERATOR'S / PARTS MANUAL Snowblowers Models PUMA-48 PUMA-54 PUMA-64 PUMA-72 PUMA-74 PUMA-84 PUMA-94 No. C870 06/07...
  • Page 2 Copyright © Les Machineries Pronovost Inc., 2007 All rights reserved. Printed in Canada.
  • Page 3: Table Of Contents

    Maintenance ......................10 Storage ........................11 Specifications ......................12 Parts List ........................13 Snowblower PUMA-48 PUMA-54 PUMA-64 PUMA-72 ......14 Snowblower PUMA-74 .................. 16 Snowblower PUMA-84 PUMA-94 ............... 18 Manual Chute Kit MD-48-94 ................. 20 Hydraulic Chute Kit HRD-48-94 ..............21 Hydraulic Orbit Chute Kit HRD-48-94 ............
  • Page 5: Introduction

    In this manual, the right and left sides are identified as shown on Figure 1. Figure 1 If you require additional information on your Snowblower, please contact your PRONOVOST MODEL: Dealer. SERIAL NO.: NOW take a moment to enter the model, serial...
  • Page 6: Safety

    SAFETY GENERAL SAFETY WHEN YOU SEE THIS SYMBOL 8) Prolonged exposure to noise may hamper hearing. Protect yourself by wearing adequate protection devices. 9) Hydraulic fluids under pressure can damage your skin. Do not use your hands to locate a leak. 10) Before the beginning of the snow season, inspect all areas where the Snowblower will be used and remove any object which may cause an accident and/or damage...
  • Page 7: Safety With Maintenance

    SAFETY (cont'd) SAFETY IN TRANSPORT 10) Do not operate in excessive inclined conditions. Be careful when turning in slopes. ) On public roads, use proper safety lights and check 11) Never operate your Snowblower with missing guards or local regulations. without protective devices in place.
  • Page 8: Decals

    DECALS SAFETY DECALS The safety decals ara affixed wherever special safety precautions are indicated. Locate them on the machine and read them carefully. If a decal is damaged, lost or illegible, install a new one. Each decal is shown and identified with a part number.
  • Page 9: Maintenance Decals

    DECALS (cont'd) Figure 6 Part no.: A 109 MAINTENANCE DECALS The maintenance decals indicate the points requiring lubrication. Refer to maintenance section for more details. Figure 7 Part no.: A104 Figure 8 Part no.: A 106 Figure 5 Part no.: A108 - 9 -...
  • Page 10: Maintenance

    MAINTENANCE 1) Wipe off all grease fittings with a clean cloth 7) Check tension of drive chain every 24 hours of before adding grease in order to avoid injecting operation and adjust if necessary. dirt and sand. 8) Check for tightness of bearing collars every 48 2) Repair or replace damaged grease fittings.
  • Page 11: Storage

    STORAGE 1) Store the Snowblower in a cool, dry place. 5) Thoroughly inspect all parts of the Snowblower. Replace or repair worn or defective parts. 2) Support the Snowblower with wooden blocks. 6) Touch-up or repaint if necessary. 3) Keep all piston rods in the retracted position. This will assure better protection against the elements.
  • Page 12: Specifications

    SPECIFICATIONS MODEL PUMA-48 PUMA-54 PUMA-64 PUMA-72 PUMA-74 PUMA-84 PUMA-94 18 - 25 Horse power recommended 16 - 25 16 - 25 18 - 25 25 - 40 40 - 75 50 - 75 Working width 48" 54" 64" 72" 74"...
  • Page 13: Parts List

    PARTS LIST - 13 -...
  • Page 14: Snowblower Puma-48 Puma-54 Puma-64 Puma-72

    SNOWBLOWERS PUMA-48 PUMA-54 PUMA-64 PUMA-72 170-02517R2 - 14 -...
  • Page 15 SNOWBLOWERS PUMA-48 PUMA-54 PUMA-64 PUMA-72 (cont'd) REF. PART # DESCRIPTION 120-04502 Frame 48" ................... 120-00543 Frame 54" ................... 120-00553 Frame 64" ................... 120-02482 Frame 72" ................... 110-03331 Pin category 1 ..................Std. Hitch pin clip 5/32" ................6550 Gear box 1" ø x 1-15 splines ..............
  • Page 16: Snowblower Puma-74

    SNOWBLOWERS PUMA-74 170-02529R2 - 16 -...
  • Page 17 SNOWBLOWERS PUMA-74 (cont'd) REF. PART # DESCRIPTION 120-00574 Frame 74" ....................... 110-03341 Pin category 1 & 2 ................... Std. Hitch pin clip 5/32" ..................300-36550 Bolt 3/8" NC x 5 1/2" lg + nylon lock nut ............6451 Gear box T281 ....................6248-EG P.T.O.
  • Page 18: Snowblower Puma-84 Puma-94

    SNOWBLOWERS PUMA-84 PUMA-94 170-02539R2 - 18 -...
  • Page 19 SNOWBLOWERS PUMA-84 PUMA-94 (cont'd) REF. PART # DESCRIPTION 120-00605 Frame 84" ...................... 120-00815 Frame 94" ...................... 110-03341 Pin category 1 & 2 ..................Std. Hitch pin clip 5/32" ..................300-40250 Bolt 1/2" NC x 1" lg + lock washer ..............8251 Gear box T27D ....................
  • Page 20: Manual Chute Kit Md-48-94

    MANUAL CHUTE KIT MD-4872, MD-74 and MD-8494 170-04301 REF. PART # DESCRIPTION 110-27702 Crank ..................... 110-28441 Crank ..................... 110-28271 Crank ..................... 110-27712 Base ....................110-28382 Base ....................110-28263 Base ....................Std. Roll pin 1/4" x 1 3/4" lg..............Std. Grease fitting 1/4"-28 straight ............
  • Page 21: Hydraulic Chute Kit Hrd-48-94

    HYDRAULIC CHUTE KIT HRD-4872, HRD-74 and HRD-8494 170-04311 REF. PART # DESCRIPTION 110-27653 Pivot ....................110-28391 Pivot ....................110-28231 Pivot ....................110-27583 Base ....................110-28401 Base ....................110-28241 Base ....................110-27613 Arc ....................110-28421 Arc ....................110-28251 Arc ....................25TR04 Cylinder 2 1/2"...
  • Page 22: Hydraulic Orbit Chute Kit Hrd-48-94

    HYDRAULIC ORBIT CHUTE KIT HMD-4872, HMD-74 and HMD-8494 170-04321 REF. PART # DESCRIPTION 110-32171 Sprocket ..................110-32891 Sprocket ..................300-38280 Bolt 7/16" NC x 1 1/4" lg + flat washer & nylon locknut ..... 160-19701 Spacer ................... 160-21091 Spacer ................... 110-32531 Base ....................
  • Page 23: Shaft 6545

    P.T.O. SHAFT # 6545 (T20) REF. PART # DESCRIPTION 6201 Quick disconnect yoke assembly ................6208 U joint + 4 retaining ring + 1 grease fitting ............... 6203 Retaining ring ......................8110 Grease fitting ......................6430 Yoke for outer tube ....................6344 Pin spring .......................
  • Page 24: Shaft 6248-Eg

    P.T.O. SHAFT # 6248-EG (T40) REF. PART # DESCRIPTION 6232-2 Safety shear yoke (2 bolts) ..................6239 U-joint + 4 retaining rings + 1 grease fitting ............. 6234 Retaining ring ......................8110 Grease fitting ......................6353 Yoke for inner tube ....................6344 Stopper for inner tube .....................
  • Page 25: Shaft 8114-Eg

    P.T.O. SHAFT # 8114-EG (T50) REF. PART # DESCRIPTION 8221 Safety shear yoke (2 bolts) ..................8073 U joint + 4 retaining ring + 1 grease fitting ............... 8061 Retaining ring ......................8110 Grease fitting ......................8079 Yoke for inner tube ....................6341 Pin spring .......................
  • Page 26: Shaft 8202

    P.T.O. SHAFT # 8202 REF. PART # DESCRIPTION 8237 Safety shear yoke (2 bolts) ..................8238 U joint + 4 retaining ring + 1 grease fitting ............... 8061 Retaining ring ......................8110 Grease fitting ......................8239 Yoke for inner tube ....................8075 Pin spring .......................
  • Page 27: Gear Box 6550

    GEAR BOX # 6550 REF. PART # DESCRIPTION 6547 Gear Z24 ....................... 6548 Outside circlip ......................6549 Parallel key 8 x 7 x 25 ..................... 6562 Shim ........................6205-2RS Bearing 6205 ......................6552 Oil seal ........................6205-2RSx1" Bearing ........................6554 Shim ........................
  • Page 28: Gear Box 6451

    GEAR BOX # 6451 (T281) REF. PART # DESCRIPTION 6414 Casing ........................6429 Side shaft (1¼" - 19 splines) ................... 6416 Spacer 35,3 x 48 ....................6207-2RS Ball bearing ......................6418 Key 10 x 8 x 30 ..................... 6419 Impeller shaft (1¼" & 1 3/8" - 6 splines) ..............6420 Seal 35 x 52 x 7 ....................
  • Page 29: Gear Box 8251

    GEAR BOX # 8251 (T27D) REF. PART # DESCRIPTION 8043 Casing ........................30208-A Roller bearing ......................8045 Inside circlip 80mm ....................8046 Oil seal 40 x 80 x 12mm ..................8047 Adjusting washer ....................8048 Gear Z18 ....................... 8049 Outside circlip 40mm ....................30207-A Roller bearing ......................
  • Page 30: Cylinder 25Tr04

    CYLINDER 25TR04 14 1/4" REF. PART # DESCRIPTION 1 See #RK25TR O-ring 1/8" x 2¼" x 2½" ................2 See #RK25TR Back-up 2½" o.d. x 3/16 ø ................. 3 See #RK25TR O-ring 3/16" x 2 1/8" x 2½" ............... 4 See #RK25TR O-ring 1/16"...
  • Page 31: Cylinder 25Tr08

    CYLINDER 25TR08 REF. PART # DESCRIPTION 1 See #RK25TR O-ring 1/8" x 2¼" x 2½" ................2 See #RK25TR Back-up 2½" o.d. x 3/16 ø ................. 3 See #RK25TR O-ring 3/16" x 2 1/8" x 2½" ............... 4 See #RK25TR O-ring 1/16"...
  • Page 32: Motor Mlh-125-250-315

    HYDRAULIC MOTOR #MLH-125, MLH-250 & MLH-315 CUSHION VALVE H110 MOTOR REF. PART # DESCRIPTION 8368 Set of seals ....................8369 Key for "Orbit" motor ................. - 32 -...
  • Page 33: Torque Chart

    TORQUE CHART TORQUE SPECIFICATION TABLE Thread UNC and UNF Grade 2 Grade 5 Grade 8* Bolt size Torque Torque Torque Pound feet Newton meters Pound feet Newton meters Pound feet Newton meters Inches min. max. min. max. min. max. min. max.
  • Page 34: Warranty

    WARRANTY PRONOVOST warrants this product to the initial All PRONOVOST spare parts purchased are covered purchaser for the period of one year from the date of by a three (3) month warranty. purchase against defects in materials and workmanship. This warranty becomes void and nul if the equipment...
  • Page 36 Ce manuel est aussi disponible en français. Veuillez téléphoner. INNOVATION - EXCELLENCE LES MACHINERIES PRONOVOST INC. 260, route 159, Saint-Tite, Quebec, Canada, G0X 3H0 Tel.: (418) 365-7551, Fax: (418) 365-7954 E-mail: info@pronovost.qc.ca Website: www.pronovost.qc.ca...
