TI110B1 GSM/PSTN Dual Network
Ⅰ
.Overview
TI110B1 GSM/PSTN Dual Network Burglar Alarm System is ADEMCO compatibility alarm
system, which adopts the advanced security technology, American-originated chipsets and siemens
industrial-grade GSM module. And it boasts its dual networks to send alarm information out.
When something wrong is on one network, dual alarm system can switch automatically to the
other one to send the alarm information out rapidly and accurately.
This GSM alarm system is composed of the host, detector, remote control and magnetic contact.
And the large LCD and English intelligent operation window make it be user-friendly. It can be
used in the institutional groups and business units for the security purpose. When alarm happens,
if the normal telephone works well, the alarm system will send the alarm voice notification out by
telephone network and send the SMS notification through GSM network; While the normal
telephone cannot work normally, the alarm system will use GSM network to send the voice/SMS
notification out. Besides, this alarm system supports network with ADEMCO Contact ID alarm
receiving center to form a comprehensive monitoring system. When alarming, the computer of the
center can show the alarm detailed information like alarm place, address, location, time and police
resource distributor of the local police station through the electronic map, database and other so
that the police dispatch will be arranged rapidly and timely.
Ⅱ
.Main Feature
16-wireless zone;2-wired zone; 1 emergency zone
LCD Display; Keypad Operation; Perpetual Calendar
Supports PSTN/GSM Dual Network
Store/Check/Delete 6 groups of alarm receiving telephone numbers by SMS
Store/Inquiry/Delete the alarm location by SMS
Inquiry the latest 2 pieces of alarm information
Two alarm volumes (High volume and Mute) available for your optional.
Be compatible with ADEMCO Contact ID Communication Protocol
2 groups of timing arm/disarm time available
Arm Stay and Arm Away for your optional
Supports arm/disarm by remote control, cell phone and SMS
Every defense zone can be set as emergency zone freely
Learn code for easy to add the additional sensors
Enter/Exit Delay time can be adjusted freely.
20 pieces of alarm information for your optional
Supports wired interfaces for external siren and wired sensors
Build-in large capacity rechargeable battery
Burglar Alarm System
1
Advertisement
Table of Contents
Related Manuals for ADEMCO TI110B1
Summary of Contents for ADEMCO TI110B1
- Page 1 GSM network to send the voice/SMS notification out. Besides, this alarm system supports network with ADEMCO Contact ID alarm receiving center to form a comprehensive monitoring system. When alarming, the computer of the...
- Page 2 Ⅲ.GSM Module Program and Operation GSM Module Alarm Receiving Overview: When alarming, if the local telecommunication line works normally, the alarm system will send the alarm voice notification out by telephone network and send the SMS notification through GSM network; While if the normal telephone cannot works normally, the GSM module will send alarm SMS to the users’...
- Page 3 (2) Method 2: Use the program cell phone to edit “Original Password*New Password* XXXXX…X” and send it to GSM SIM card. And the new password will replace the original one. And the GSM SIM card will send the new program password to the telephone number “XXXXX…X”.
-
Page 4: Alarm Location
card. And the program cell phone will receive “7-22392288*0001/”. It means that the arming report to alarm center has been stored successfully. you use program cell phone to edit “8888*78*22392288*0001” to GSM SIM For example 2: card. And the program cell phone will receive “8-22392288*0001/”. It means that the disarming report to alarm center has been stored successfully. -
Page 5: Sms Format
program cell phone will get such a message “FFFF”, which means that the remote arming/disarming password has been deleted. 8. Check arm/disarming status by SMS If you are not sure what current status of alarm panel, you are allowed to use the following way to check the current status of alarm panel: (1) Method 1: Use the program cell phone to edit “... -
Page 6: Operation Notice
SIM card. The telephone number “XXXXX…X” will receive such a message: “Techwell Electronic Technology Co., LTD (Alarm location) -------Disarm (Status)”, which means that the alarm panel has been disarmed successfully. (Note: 3456---remote operation password; 8----function code; XXXXX…X----cell phone number) GSM Module Alarm Dispose When alarming, the “Dialing”... - Page 7 ＃ Wednesday February Hour(08) Minute 30 15th and the alarm panel sounds a long indicator with the screen displaying but no year. Month Day Hour Minute 3. Store the common alarm receiving number (1) Demonstration: supposing the first group of alarm receiving number is 22392458 Operation steps: press the key “...
- Page 8 into “Arm Stay”. When some intruders enter those zones, the detectors in those zones can send the alarm signal to the alarm panel and trigger alarm whistle. While those zones where some stayers are in will be disarmed condition and will not send the alarm signal as though intruders enter into a.
- Page 9 Aid”. Press the key “ ”, and the screen display these seven alarm types in order. (Note: all the zones will be default to be alarm type “Steal” if you don’t do this program) (2) Set the “Steal” alarm type Demonstration: set the zones from 1 to 5 , 10...
- Page 10 (1) Uncover the plastic shell of the detector, and if you want to make it match code into the PROG Zone first zone, you can press the “ ” once. And the screen displays and then you press the built-in “ code-matching” button of detector without releasing. When seeing the transmitting indicator of detector shining, you press the “...
- Page 11 11. Set Ring Times (Arm/Disarm by telephone) (1) You are allowed to arm/disarm this system by remote telephone. The alarm panel will automatically hang off after several rings and then you can arm/disarm this system by telephone. (2) If the ring times that you set are less than 10, please add “0” ahead. For example, the ring times is 5, you are required to input “05”...
- Page 12 , and then press , you can hear that a long Enter Exit delay 15s Entry dely 10s indicator voice, which implies that you have set it successfully. Cancel Entry/Exit delay time: press the“ ”,and then press , and a long indicator voice will reminds Enter you that you have cancelled it successfully.
- Page 13 cancelled. 15. Query or Check the program items： On completing the program task, you are allowed to query or check whether the program items are with accordance to you request or not. You need to turn on the “program” switch initially. And when the checking operation is over, you should make sure the switch is turn off.
-
Page 14: Emergency Alarm
Meantime, the zones will be replaced by the Characters “ Disarm” and “Emergency Zone” on the LCD display. (3) Arm/Disarm by remote-site cell phone Dialing the telephone connected to the alarm panel by remote-site telephone, and you will hear indicator voice. Several rings later, you input the 4-digit password. If the password is correct, you will hear a long prompt voice and then you can continue to input “2”... -
Page 15: Short Circuit
“transmitting” indicator light shines when the door is opened, and the host touches off the alarm, which means you have successfully install it. But when the light signal is green, it means that the battery for the magnetic contact has electricity shortage and the battery should be changed. - Page 16 negative electrodes. If you don’t want to wired sensor, please don’t take off the short circuit wire. (4) Extern Siren Wiring: there is an output terminal for external siren in the alarm panel. And when wiring , please pay attention on the electrodes of siren and alarm panel to ensure that you have a right wiring (Note: Red Line is positive and Black Line is negative) (5) Telephone Wiring: please insert the crystal plug of the telecommunication line into the “Telephone Line”...
- Page 17 Dimension: 190×190×50mm (without antenna) Ⅶ.Cautions: 1. Before the program task, please turn the “Program” switch to the “on” position for programming or checking operation. And after the operation task is completed, make sure the “Program” switch is turn off ; otherwise, the host cannot work normally or subject to the disorder or deleting operation 2.
- Page 18 Either the telephone or the local line is local line telephone line into the right in the wrong position positions Telephone fails to dial the The numbers you store are wrong or are Re-store the right numbers numbers not stored successfully There something wrong...
